Resilient floor coverings — Determination of dimensional
stability and curling (vertical deformation) after
exposure to heat
1 Scope
This document specifies methods for determining dimensional stability and curling (vertical deformation)
of resilient floor coverings in all forms (e.g. of sheets, tiles, panels, planks or in rolls) after exposure to heat
and/or after reconditioning.
2 Normative references
There are no normative references in this document.
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminology databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at https:// www .electropedia .org/
3.1
dimensional stability
in the context of this document, it is the ability of a resilient floor covering to retain its original linear
dimensions (no elongation or shrinking) after exposure to heat, determined by measuring the linear
dimensional change in machine direction or across machine direction.
3.2
curling (vertical deformation)
vertically concave (+) or convex (-) deformation from the horizontal
3.3
concave deformation
a type of curling (vertical deformation) appearing as uplifted top surface at the outer edge of the specimen;
given as positive value (+)
3.4
convex deformation
a type of curling (vertical deformation) appearing as uplifted/domed top surface in the centre of the
specimen; given as negative value (-)
3.5
machine direction (MD)
direction parallel to the length side of a floor covering manufactured in a continuous process
Note 1 to entry: For rectangular or squared cut specimens (e.g. tiles and planks) where the machine direction could
not be determined the direction of MD can be arbitrarily assigned for the test to enable differentiation from AMD.

oSIST prEN ISO 23999:2025
ISO/DIS 23999:2024(en)
3.6
across machine direction (AMD)
direction across to the length side of a floor covering manufactured in a continuous process
Note 1 to entry: For rectangular or squared cut specimens (e.g. tiles and planks) where the machine direction could be
unknown, the MD can be arbitrarily assigned for the test to enable differentiation from MD.
4 Principle
4.1 General
Three test specimens are initially measured and then placed in an oven at an elevated temperature which
may cause dimensional changes and curl (3.1 - 3.4). After a specific period in the oven and subsequent time of
reconditioning, dimensional stability and the stability against vertical deformation (curling) are measured
again on the same test specimens.
4.2 Dimensional stability
The relative change in linear distance between the same marks or same specific locations of the top surface
layer of a test specimen, measured after exposure to a heat treatment and reconditioning. Depending on
the size of the specimen and the structure of the surface, different measuring devices could therefore be
appropriate.
As a case for special interests, the determination of the change of linear dimensions on hot test specimens,
meaning before reconditioning. As this does not affect the normative measurement of dimensional stability
and curling, it can be determined as an intermediate result on the same test specimens (see Annex A).
4.3 Curling (vertical deformation)
Curling is measured at the highest peaks of the test specimens possibly occurring after the specified heat
treatment in an oven at an elevated temperature and reconditioning in a normal conditioned climate.
An initial vertical deformation of the test specimen (before the exposure to heat) can be measured.
5 Apparatus
5.1 Oven
An oven which shall be thermostatically controlled and ventilated, capable of being maintained at a uniform
temperature with maximum deviations of ±2 °C.
The oven must be capable to place specimens inside in a way that ensures that radiation from the heating
elements does not directly reach the test specimens or support plates (5.2). Therefore, the distance between
the support plates (5.2) and the vertical walls of the oven shall be more than 50 mm and the vertical distance
between the support plates and between the plates and the oven ceiling and base shall be more than 100 mm.
5.2 Support plates
The support plates on which the specimens will be placed for the test shall be of metal, e.g. aluminium or
stainless steel, of dimensions larger than the test specimen, 2,0 mm ± 0,5 mm in thickness. Ensure that the
support plates are kept smooth and polished so that surface friction does not interfere with free shrinkage
or growth of the test specimens. The plates shall be flat and free of convex or concave distortion and fully
support the sample (e.g. a wire rack support plate is not acceptable.).

oSIST prEN ISO 23999:2025
ISO/DIS 23999:2024(en)
6 Measuring devices
6.1 Measurement devices for determination of curling (vertical deformation)
The measuring equipment could be any appropriate apparatus or device capable of measuring small
distances vertical from the support plate (5.2) with a precision of ±0,1 mm and without influencing the test
specimens by any kind of load from the test device itself.
This could be for example:
— a laser measuring device;
— other optical measuring devices;
— tactile measuring devices (e.g. pillar-mounted drop gauge device, feeler gauges or a micrometer).
6.2 Measurement devices for determination of linear dimension changes
All used measuring equipment shall measure with a precision of at least ±0,02 mm.
The measuring equipment could be:
— an optical bench for non-contact dimensional measurements between two marks on the top surface (for
example scores which are carefully made in the surface) or;
— callipers or;
— a block and dial set-up (so-called “block and dial gauge apparatus”, see 6.2.3) as shown in Figures 2, 3 and
4 for tactile measurement at the outer edge of the specimen top layer.
NOTE 1 For many types of optical benches, ensure that the test specimen is properly seated against the base
horizontal index guide when a specific measurement is being taken, otherwise test specimens with concave or convex
edges can be read incorrectly.
NOTE 2 For ready shaped floor covering elements (e.g. tiles and planks) the block and dial gauge apparatus is
appropriate. For test specimens prepared from sheet or roll material, equipment should be used which take measures
from the top surface.
6.2.1 Scoring device
A scoring device, e.g. a single edge razor blade, scalpel or scribe point, can be used to make marks in the top
surface of test specimens made from sheet or roll material or optionally for glue down tiles and planks for
measuring with an optical bench (6.2).
6.2.2 Rigid steel plate
Optional auxiliary device to help flatten concave or convex deformed test specimens from sheet or
roll material or optionally for glue down tiles and planks. A rigid plate of steel, squared and finished, of
dimensions 240 mm × 240 mm with holes to see the measuring marks (examples are shown in Figure 1 and
6) on the top surface of the specimens. If larger format specimens are tested, then the rigid plate should be
of commensurate size and configuration.
6.2.3 Block and dial gauge apparatus (for tiles and planks)
Test device consisting of a support plate in sufficient size with a lay-on edge (block) to be used with a
measuring device (for example a dial gauge, see Figures 2, 3 and 4).
6.2.3.1 Square standard template (optionally)
Standard templates can be used together with the block and dial gauge apparatus (6.2.3) for determination
of deviations in size between the template and a product or a specimen. Figure 2 shows an example of a

oSIST prEN ISO 23999:2025
ISO/DIS 23999:2024(en)
block and dial gauge apparatus with the possible use of standard templates in 4 different sizes and possible
positions of the measuring devices to determine also straightness and squareness. A square standard
template has the nominal side length of a product or a test specimen and should be rectangular. The
deviations from the template sizes before and after heat exposure can show the linear dimensional changes
due to the heat influence.
NOTE 1 A standard template is normally calibrated for straightness, squareness, and length with regard to the
nominal sizes of a product. They can be useful for a quick measurement with always the sam
...
