INTERNATIONAL STANDARD ISO 11407:2004(E)

Commercial road vehicles — Mechanical coupling between
towing vehicles, with coupling mounted forward and below, and
centre-axle trailers — Interchangeability
1 Scope
This International Standard specifies the interchangeability requirements of the various elements and
dimensions for the mechanical coupling of towing vehicles whose coupling is mounted forward and below to
centre-axle trailers. It is applicable to road trains for the commercial transport of low-density, high-volume
cargo of the greatest possible variety. It is also applicable to corresponding equipment in cases where the
same vehicle makes up part of a road train having more than one trailer. It is not applic
...
