INTERNATIONAL STANDARD ISO 8535-1:2016(E)
Diesel engines — Steel tubes for high-pressure fuel
injection pipes —
Part 1:
Requirements for seamless cold-drawn single-wall tubes
1 Scope
This document specifies dimensions and requirements for seamless cold-drawn single-wall steel tubes
for high-pressure fuel injection pipes used on diesel (compression-ignition) engines (class 2) and for
fuel injection pump testing (class 1).
This document applies to diesel (compression-ignition) engines.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 6507-1, Metallic materials — Vickers hardness test — Part 1: Test method
ISO 6892-1, Metallic materials — Tensile testing — Part 1: Method of test at room temperature
ISO 12345, Diesel engines — Cleanliness assessment of fuel injection equipment
3 Terms and definitions
No terms and definitions are listed in this document.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— IEC Electropedia: available at http://www.electropedia.org/
— ISO Online browsing platform: available at http://www.iso.org/obp
4 Dimensions and tolerances
4.1 Diameters
Recommended inside and outside diameters are given in Table 1. Other sizes may be used by agreement
between supplier and customer.
Tolerances on inside and outside diameters shall be as follows.
a) Inside diameter, d
d ≤ 4 mm: ±0,05 mm for class 2
   ±0,025 mm for class 1 (these tolerances are in accordance with ISO 4093)
d > 4 mm: ±0,10 mm
© ISO 2016 – All rights reserved 1

--------------
...
