Introduction
Propeller cavitation is the major noise source in commercial ships. The propeller cavitation noise can be
assessed by experimental and/or numerical methods in propeller design stage. The numerical methods,
such as computational fluid dynamics (CFD) or empirical formulae, might be a good alternative to
propeller cavitation noise evaluations. However, the model tests are still used widely for research on
propeller cavitation noise.
The objective of the model test is to reduce the propeller noise in ship design by evaluating propeller
cavitation noise characteristics at the design phase. Localizing the noise sources in the design stage,
as well as predicting its noise levels, might be very helpful. ISO 20233-1 addresses the prediction of
propeller noise levels. In order to specify the location of noise source, visual observation of cavitation is
the most practical way in view of spatial resolution and efficiency, as the main source of hydrodynamic
noise in merchant ship is cavitation. In addition to this observation, noise source localization technique
[1]
using hydrophone array is under development for verifying the observed noise source location . Thus
this document devotes to the source localization method as a new part of a model test method for
propeller cavitation noise evaluation in ship design.
The estimation methods of the propeller noise via model tests were widely studied for a long time and
can be used in the shipbuilding industry nowadays. However, the noise source localization is easily
accomplished by cavitation observation. This document also serves to provide an example of protocols
for acoustic localization which is a relatively new research area.
INTERNATIONAL STANDARD ISO 20233-2:2019(E)
Ships and marine technology — Model test method for
propeller cavitation noise evaluation in ship design —
Part 2:
Noise source localization
1 Scope
This document specifies a model test method for propeller cavitation noise evaluation in ship design,
focusing mainly on the noise source localization.
The procedure comprises the model test set-up, noise measurements, data processing and source
localization. The target noise source being propeller cavitation, this document describes the test set-up
and conditions to reproduce the cavitation patterns of the ship, which is the same as in ISO 20233-1. The
noise measurements are performed using a hydrophone array for the source localizations. Therefore,
the instrumentation of the hydrophone array is also addressed, as well as a suitable array signal
processing of the measured data. Finally, a method to visualize and to interpret the results is presented.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 20233-1:2018, Ships and marine technology — Model test method for propeller cavitation noise
evaluation in ship design — Part 1: Source level estimation
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https: //www .iso .org/obp
— IEC Electropedia: available at http: //www .electropedia .org/
3.1
acoustic centre
position where all the noise sources are co-located as a single point source
Note 1 to entry: The acoustic centre is the centre of the expected cavitation extent.
3.2
background noise
noise from all sources other than the source under test
3.3
hydrophone
underwater electro-acoustic transducer
underwater microphone
device to measure acoustic pressure, including any signal conditioning electronics such as pre- or
charge amplifiers either within or exterior to it
Note 1 to entry: Piezoelectric hydrophones are usually used for the measurement of underwater sound pressure
in a test facility.
3.4
noise source
noise-generating mechanism or object
Note 1 to entry: For the purposes of this document, the main noise source is the propeller cavitation.
3.5
propeller plane
imaginary plane orthogonal to the shaft centre line and including the intersection (point) of the shaft
centre line and generator line
3.6
reference field
sound pressure field that is measured using a virtual source located at a given position, i.e. the
acoustic centre
Note 1 to entry: The reference field is used to calibrate the hydrophone array.
3.7
virtual source
artificial sound source of which the transmitting power is known a priori
4 Model test setup and conditions
In order to evaluate the propeller cavitation noise performance via model tests, it is important to
reproduce accurately the noise sources, i.e. the cavitation patterns, based on the similarity laws
between the model and the ship. Accuracy in reproducing the noise sources is required for the noise
source localization as well as for the source level estimation. The test setup and conditions described in
ISO 20233-1:2018, Clause 4, shall be applied t
...
