TECHNICAL REPORT ISO/TR 22770:2019(E)
Preparation of steel substrates before application of paints
and related products — Analytical colorimetry method to
support visual assessment of surface preparation grades
1 Scope
This document provides guidance on the usage of analytical colorimetry to support visual assessment
of surface preparation grades described in ISO 8501-1:2007, Clause 4.
This document provides examples of applications where the use of a colorimeter or spectrophotometer
can enable a quick and objective assessment of the preparation grade of the substrate.
NOTE The data given in this document was obtained using the methodology described in Annex A.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 8501-1, Preparation of steel substrates before application of paints and related products — Visual
assessment of surface cleanliness — Part 1: Rust grades and preparation grades of uncoated steel substrates
and of steel substrates after overall removal of previous coatings
3 Terms and definitions
For the purposes of this document, the terms and definitions given in in ISO 8501-1 and the
following apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https: //www .iso .org/obp
— IEC Electropedia: available at http: //www .electropedia .org/
3.1
CIELAB colour space
CIE 1976 L* a* b* colour space
three-dimensional L *, a*, b* colour space
3.2
colour difference
difference between two colour stimuli defined as the Euclidean distance between the points
representing them in the L* a* b* space and calculated as follows
2 2 2 1/2
ΔE* = [(ΔL*) + (Δa*) + (Δb*) ]
3.3
illuminant
radiation with a relative spectral power distribution defined over the wavelength range that influences
object colour perception
© ISO 2019 – All rights reserved 1

---------------------- Page: 6 ----------------------
ISO/TR 22770:2019(E)

3.4
standard illuminant
illuminants (3.3) by the CIE defined in terms of relative spectral power distributions
Note 1 to entry: These illuminants are intended to represent the following:
a) Planckian radiation at a temperature of about 2 856 K;
b) direct solar radiation (obsolete);
c) average daylight;
d) daylight.
The 2-digit number associated to D illuminant denotes the correlated colour temperature.
3.5
observer
CIE 1931 standard colorimetric observer
ideal observer whose colour-matching properties correspond to the CIE colour-matching functions
adopted by the CIE in 1931
Note 1 to entry: This standard colorimetric system is applicable to centrally-viewed fields of angular subtending
between about 1° and about 4°.
3.6
supplementary standardized observer
CIE 1964 supplementary standard colorimetric observer
ideal observer whose colour-matching properties correspond to the CIE colour-matching functions
adopted by the CIE in 1964
Note 1 to entry: This standard colorimetric system is applicable to centrally-viewed fields of angular subtense
greater than about 4°.
Note 2 to entry: When this system is used, all symbols that represent colorimetric measures are distinguished by
use of the subscript 10.
4 Symbols
L* CIELAB lightness
a*, b* CIELAB a*, b* coordinates
ΔL* CIELAB lightness difference
Δa*, Δb* CIELAB a*, b* difference
ΔE* CIELAB colour difference
ΔC* CIELAB chroma difference
ΔH* CIELAB hue difference
5 Principle
The assessment of preparation grade of the surface is done by calculation of the colour difference
components, taking as reference the colour components values of a substrate with the targeted surface
preparation grade.
2 © ISO 2019 – All rights reserved

---------------------- Page: 7 ----------------------
ISO/TR 22770:2019(E)

The surface preparation will be considered as acceptable if the colour difference is below a certain
...
