INTERNATIONAL STANDARD ISO 7870-7:2020(E)
Control charts —
Part 7:
Multivariate control charts
1 Scope
This document describes the construction and use of multivariate control charts in statistical process
control (SPC) and establishes methods for using and understanding this generalized approach to
control charts where the characteristics being measured are from variables data.
The use of principal component analysis (PCA) and partial least squares (PLS) in the field of multivariate
statistical process control is not presented in this document
NOTE The document describes the current state of the art of multivariate control charts that are being
applied in practice nowadays. It does not describe the current state of scientific research on the topic.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 3534-2, Statistics — Vocabulary and symbols — Part 2: Applied statistics
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 3534-2 apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at http:// www .electropedia .org/
3.1
multivariate characteristics
multivariate quantity where the set of features consists of d quantities that are alone or combined with
the quality of a product
Note 1 to entry: Following ISO 7870-2, these quantities are denoted as quality characteristics X where i = 1, 2, …,d.
i
Note 2 to entry: The  observation of  multivariate characteristics  can  be expressed  as  the vector
T
x=(x , x , …, x ) . Thus, a multivariate quantity can be considered as a feature vector of a product. The value of the
1 2 d
multivariate quantity is represented by a point in the d-dimensional feature space.
Note 3 to entry: All single quantities combined in the multivariate vector can be measured in the same product
or object.
Note 4 to entry: If the multivariate quantity is described by means of statistics, the vector is considered as a
random vector following a d-dimensional multivariate distribution.
© ISO 2020 – All rights reserved 1

---------------------- Page: 6 ----------------------
ISO 7870-7:2020(E)

3.2
confidence region
d-dimensional region for a multivariate characteristics of d-dimension and defined for a specified
confidence level
Note 1 to entry: The region is limited by lines, surfaces or hyper-surfaces in the d-dimensional space.
Note 2 to entry: Form and size of the region are defined by one or more parameters.
4 Abbreviated terms and symbols
4.1 Abbreviated terms
SPC statistical process control
MSPC multivariate statistical process control
PCA principal component analysis
PLS partial least squares
UCL upper control limit
LCL lower control limit
ARL average run length
EWMA exponential weighted moving average
MEWMA multivariate exponential weighted moving average
4.2 Symbols
B the 1 − α quantile of beta distribution with degree of freedom ν and ν
1 2
1−αν,,ν
12
d number of dimensions for multivariate characteristics
2 2
the statistic plotted of a phase IIχ control chart
D
j
E(|S|) mean of |S|
F the 1 − α quantile of F distribution with degree of freedom ν and ν
1 2
1−αν,,ν
12
h upper control limit of MEWMA control chart
L lower control limit
CL
m number of subgroups
n size of each subgroup
N (μ,Σ) d-dimensional normal distribution with μ and Σ
d
s covariance between the a-th and b-th quality characteristics with n=1
ab
s covariance between the a-th and b-th quality characteristics in the j-th subgroup
abj
with n>1
2
variance of the i-th quality characteristic with n=1
s
i
2 © ISO 2020 – All rights reserved

---------------------- Page: 7 ----------------------
ISO 7870-7:2020(E)

2
variance of the i-th quality characteristic in the j-th subgroup with n>1
s
ij
2 2
s average of s over all m subgroups for the i-th quality characteristic with n>1
i ij
s average of s over all m subgroups for the covariance between the a-th and b-th
abj
ab
quality characteristics with n>1
S sample variance-covariance matrix with n=1
S sample variance-covariance matrix with n>1
|S| determinant of the sample variance-covariance matrix S
2 2
the statistic plotted of a phase I T -chart.
T
j
2
2
the statistic plotted of a phase II T -chart
T
f
tr trace operator
U upper control limit
CL
V(|S|) variance of |S|
x the j-th observation on the i-th quality characteristic with n=1
ij
x the k-th observation in the j-th subgroup on the i-th quality characteristic with n>1
ijk
x mean of the i-th quality characteristic in the j-th subgroup with n>1
ij
x average of x over all m subgroups for the i-th quality characteristic with n>1
i ij
x an observation vector
x vector of j-th observation with n=1
j
x vector of a future individual observation with n=1
f
x
sample mean vector with n=1
x mean of the j-th rational subgroup with n>1
j
x mean of a future rational subgroup with n>1
f
x sample mean vector with n>1
{}x i-th element of the vector x
i
2
the statistic plotted of MEWMA control chart.
Y
j
Z MEWMA statistic
j
2
2
the 1 − α quantile of χ distribution with degree of freedom ν
χ
1−αν,
δ shift size of the mean vector
λ MEWMA moving parameter vector
λ EWMA moving parameter, 0 < λ ≤ 1
μ mean vector of multivariate characteristics
© ISO 2020 – All rights reserved 3

---------------------- Page: 8 ----------------------
ISO 7870-7:2020(E)

μ pre-specified mean vector of multivariate characteristics
0
ρ
correlation coefficient between y and y
yy, 1 2
12
Σ variance-covariance matrix of multivariate characteristics
Σ pre-specified variance-covariance matrix of multivariate characteristics
0
Σ variance-covariance matrix of MEWMA statistic Z
Z j
j
−1
(·) inverse operator
T
(·) transpose operator
5 Purpose and classification of multivariate control charts
5.1 Purpose and applying conditions for multivariate control charts
There are many situations in which the simultaneous monitoring or control of two or more related
quality characteristics is necessary. The difficulty with using independent univariate control charts is
illustrated in Figure 1. Only two quality characteristics (y , y ) are considered for ease of illustration.
1 2
Suppose that, when the process is in a state of statistical control where only common cause variation is
present, both y and y follow a normal distribution but are correlated (ρ = −0,94) as illustrated in
1 2
yy,
12
the joint plot of y vs. y in Figure 1. The ellipse represents a contour for the in-control process, with
1 2
0,997 3-quantile, corresponding to risk of a false alarm of 0,002 7 in the Shewhart chart, and the points
represent a set of individual observations from this distribution. The same observations are also
plotted in Figure 1 as individual Shewhart control charts on y and y vs. the observation number (time)
1 2
with their corresponding upper and lower control limits (the 0,998 65-quantiles).
By looking at each of the individual Shewhartcontrol charts, the process appears to be clearly in a state
of statistical control, and none of the points give any indication of a problem. The true situation is only
revealed in the bivariate y vs. y plot where it is seen that the lot of product indicated by the ⊗ is
1 2
clearly outside the confidence region and is clearly different from the normal “in-control” population of
the product.
If the quality characteristics are not independent, which usually would be the case if they relate
to the same product, there is no easy way to measure the distortion in the joint control procedure.
Process-monitoring problems in which several related variables are of interest are sometimes called
multivariate quality control problems. This subject is particularly important, as automatic inspection
procedures make it relatively easy to measure many parameters on each unit of product manufactured.
For example, many chemical and process plants and semi-conductor manufacturers routinely maintain
manufacturing databases with the process and quality data on hundreds of variables. Monitoring or
analysing these data with univariate SPC procedures is often ineffective. Multivariate control charts
are applied for statistical process evaluation and control under consideration of dependability between
the product or process characteristics.
4 © ISO 2020 – All rights reserved

---------------------- Page: 9 ----------------------
ISO 7870-7:2020(E)

Key
y mean of y U upper control limit of y
1 2
1 CL
2
mean of y lower control limit of y
y L
2 2
2 CL
2
j
observation number point corresponding to y
1
upper control limit of y point corresponding to y
U
1 2
CL
1
L
lower control limit of y point corresponding to (y ,y )
CL 1 1 2
1
Figure 1 — Quality control of two variables
Multivariate control charts work well when the number of process variables is not too large – ten or
fewer. As the number of variables grows, however, traditional multivariate control charts lose efficiency
with regard to shift detection. A popular approach in these situations is to reduce the dimensionality of
the problem. This can be done with the use of projection methods such as principal component analysis
(PCA) or partial least squares (PLS). These two methods are based on building a model from a historical
data set, that is assumed to be in control. After the model has been built, a future observation is checked
as to whether it fits well or not in the model.
In the SPC univariate case, the normal distribution is generally used to describe the behaviour of
a continuous quality characteristic. The same approach can be used in the multivariate case. A
multivariate normal distribution is applied as the basic assumption for a multivariate characteristics.
5.2 Classification of multivariate control charts
If the multivariate characteristics is considered to be a random vector with a multivariate normal
distribution, this distribution is characterized by a mean vector μ and a variance-covariance matrix
Σ (see Annex C). Obviously from the viewpoint of the application of multivariate process control,
© ISO 2020 – All rights reserved 5

---------------------- Page: 10 ----------------------
ISO 7870-7:2020(E)

multivariate control charts can be applied to monitor the mean shift and process dispersion separately.
Thus, for the application, multivariate control charts can be classified as follows:
a) multivariate control charts for mean shift;
b) multivariate control charts for process dispersion.
For the mean shift, multivariate control charts with unweighted averages are analogous to the Shewhart
X chart or chart for individuals. They use information only from the current sample and are relatively
insensitive to small and moderate shifts in the mean vector. Multivariate control charts with weighted
averages such as multivariate EWMA control chart can be used to overcome this problem. Just like
EWMA charts are generally used for detecting small shifts in the process mean and they usually detect
shifts of 0,5 sigma to 2 sigma much faster. Thus, multivariate control charts for mean shift can be
classified as follows:
2 2
i) multivariate control charts with unweighted averages (see Clause 6), such as χ and T chart;
ii) multivariate control charts with weighted averages (see Clause 7), such as multivariate EWMA
control chart.
Figure 2 is given to show how to select multivariate control charts.
Figure 2 — Multivariate control chart selection flow chart
6 Multivariate control charts with unweighted averages for mean shift
6.1 General
For each of the multivariate control charts, there are two distinct situations:
a) when no pre-specified process parameter values are given, and
b) when pre-specified process parameter values are given.
The pre-specified or known process parameter values can be defined by target values or by
requirements or by estimated values that have been determined by the data under the condition of a
process in control.
6 © ISO 2020 – All rights reserved

---------------------- Page: 11 ----------------------
ISO 7870-7:2020(E)

There are two distinct phases of control charting practice.
i) Phase I: control charts are used for retrospective testing of whether the process was in-control
when the first subgroups were being drawn. Once this is accomplished, the control chart is used
to define what is meant by a process being statistically in-control. This is referred to as the
retrospective use of control charts;
ii) Phase II: control charts are used for testing whether the process remains in-control when future
subgroups are drawn. In this phase, the charts are used as aids to the practitioners in monitoring
the process for any changes from an in-control state.
Another crucial matter is the subgroup size n of each rational subgroup. If n=1, then special care must
be taken. Thus, four possibilities are considered:
— phase I and n=1, working with individual observations;
— phase I and n>1, working with rational subgroups;
— phase II and n=1, working with individual observations;
— phase II and n>1, working with rational subgroups.
6.2 Control charts for the process mean (n>1)
2
6.2.1 χ control chart when pre-specified parameter values are known
Assume that the vector x follows a d-dimensional normal distribution, denoted as N (μ ,Σ ), and there
d 0 0
are m subgroups each of size n>1 available from the process. Furthermore, assume that the observation
vectors x are not time dependent. A control chart can be based on the sequence of the following statistic:
T
2 −1
Dn=−xxμμΣΣμ−μ    j = 1,2, ., m (1)
() ()
jj 00 j 0
Here x is the vector of the mean of the j-th rational subgroup, where μ and Σ are the known vector of
0 0
j
means and the known variance-covariance matrix, respectively.
2
The D statistic represents the weighted distance (Mahalanobis distance) of any point from the target
j
2
μ . If the value of the test statistic D plots above upper control limit, the chart signals a potential out-
0
j
of-control process. In general, control charts have both upper and lower control limits. However, in this
case only an upper control limit is used, because extreme values of the statistic correspond to points far
remote from the target μ , whereas small or zero values of the statistic correspond to points close to
0
the target μ .
0
2
2
The D statistic follows a χ -distribution with d degrees of freedom. Thus, a multivariate Shewhart
j
control chart for process mean, with known mean vector μ and variance-covariance matrix Σ , has the
0 0
following upper control limit:
2
U =χ (2)
CL
1−α,d
For the determination of the upper control limit α can be chosen as 0,1 %, 0,2 %, 0,5 %, or 1 % under the
consideration of a practical application. For example, the selection of 0,2 % means that there is
approximately a 0,2 % risk of a false alarm, or an average of twice in a thousand, of a plotted point
2
corresponding to the D statistic being outside of the upper control limit when the process is in-control.
j
2
This control chart is called a phase II χ control chart.
© ISO 2020 – All rights reserved 7

---------------------- Page: 12 ----------------------
ISO 7870-7:2020(E)

2
6.2.2 T control chart when pre-specified parameter values are unknown
When more than 20 subgroups are already obtained, and multivariate control charts are used to
monitor the process, the sample mean vector x is estimated by the average of all subgroup means. The
sample variance-covariance matrix S is estimated by the d × d average of subgroup variance-covariance
matrices. See Annex C.1.
If μ is replaced x , and Σ is replaced by S , with n>1 and x is the mean of the j-th rational subgroup, a
0 0
j
[4]
control chart can be based on the sequence of the following statistic :
21T −
Tn=−()xx Sx()−x   j = 1, 2, ., m (3)
jj j
2
for the j-th subgroup. Then the Tc/(dm,,n) statistic follows an F distribution with d and (mn–m–
j 0
−1
d+1) degrees of freedom. Here, cd(,mn,)=−[(dm 11)(nm−−)]()nm−+d 1 .
0
Thus, a multivariate Shewhart control chart for process mean with unknown parameters has the
following upper control limit:
dm()−−11()n
U = F (4)
CL 11−−α ,,dmnm−+d
mn−−md+1
2
This control chart is called a phase I T -chart.
If μ is replaced by x , and Σ is replaced by S , with n>1 and x is the mean of a future rational
0 0
f
subgroup, a control chart can be based on the sequence of the following statistic:
2 T1−
Tn=−()xx Sx()−x (5)
f ff
2
Then the Tc/(dm,,n) statistic follows an F-distribution with d and (mn–m–d+1) degrees of freedom,
1
f
−1
where cd(,mn,)=+[(dm 11)(nm−−)]()nm−+d 1 and m is used to show the number of subgroups that
1
belong to phase I.
Thus, a multivariate Shewhart control chart for process mean with unknown parameters, has the
following upper control limit:
dm()+−11()n
U = F (6)
CL 11−−α ,,dmnm−+d
mn−−md+1
2
This control chart is called a phase II T -chart.
6.3 Control charts for the process mean (n=1)
2
6.3.1 χ control chart when pre-specified parameter values are known
For charts constructed using individual observations (n=1), a control chart can be based on the
sequence of the following statistic:
T
2 −1
D =−xxμμΣΣμ−μ    j = 1, 2, ., m (7)
() ()
jj 00 j 0
where x is the j-th, j =1, 2, …, m, observation following N (μ ,Σ ), where μ and Σ are the known vector
j d 0 0 0 0
of means and the known variance-covariance matrix, respectively. Moreover, assume that the
2 2
observations x are not time dependent. The D statistic follows a χ -distribution with d degrees of
j j
8 © ISO 2020 – All rights reserved

---------------------- Page: 13 ----------------------
ISO 7870-7:2020(E)

freedom. Thus, a multivariate Shewhart control chart for process mean with known mean vector μ
0
and variance-covariance matrix Σ has the following upper control limit:
0
2
U =χ (8)
CL 1−α,d
2
This control chart is called a phase II χ control chart.
2
6.3.2 T control chart when pre-specified parameter values are unknown
When more than 20 observed vectors on multivariate characteristics are already obtained and
multivariate control charts are used to monitor the process, the sample mean vector x and the sample
variance-covariance vector S are estimated. See Annex C.2.
If μ is replaced by x , Σ is replaced by S, and x is the j-th individual observation which is not
0 0
j
independent of the estimators x and S, a control chart can be based on the sequence of the following
statistic:
21T −
T =−()xx Sx()−x  j = 1, 2, ., m (9)
jj j
2
 
1 21()m−
2
then the Td/(m) statistic follows beta distribution with d/2 and −−d 1 degrees of
 
i 0
2 34m−
 
21−
freedom, where dm()=−()mm1 .
0
Thus, a multivariate Shewhart control chart for process mean with unknown parameters has the
following u
...
