INTERNATIONAL STANDARD ISO 3547-2:2006(E)

Plain bearings — Wrapped bushes —
Part 2:
Test data for outside and inside diameters
1 Scope
This part of ISO 3547 specifies the test data for outside and inside diameters of wrapped bushes made of
solid and multi-layer bearing material for plain bearing applications. It also specifies test designations.
Since the wall thickness of the bush is measured in the free condition, no special test data is required for this
on the drawing (see ISO 3547-5 and ISO 3547-6).
NOTE Depending on the manufacturing method, the back of the bushes can show isolated light depressions and,
similarly, bushes with lubrication holes, grooves and bore indentations can show distortion. The wall thickness must
therefore be measured away from these areas.
2 Normative references
The following referenced documents are indispensable for the application of this document. For dated
references, only the edition cited applies. For undated references, the latest edition of the referenced
document (including any amendments) applies.
ISO 3547-1:2006, Plain bearings — Wrapped bushes — Part 1: Dimensions
ISO 3547-4:2006, Plain bearings — Wrapped bushes — Part 4: Materials
ISO 4378-1, Plain bearings — Terms, definitions and classification — Part 1: Design, bearing materials and
their properties
ISO 12301, Plain bearings — Quality control techniques and inspection of geometrical and material quality
characteristics
ISO 13715, Technical drawings — Edges of undefined shape — Vocabulary and indication
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 4378-1 apply.
© ISO 2006 – All rights reserved 1

---------------------- Page: 5 ----------------------
ISO 3547-2:2006(E)
4 Symbols and units
See Table 1.
Table 1 — Symbols and units
Symbol Description Unit
2
A
Reduced area of cross section (calculated value) of the bush mm
cal
B Width of the bush mm
C
Inside chamfer mm
i
C
Outside chamfer mm
o
D
Flange diameter mm
fl
D
Housing bore diameter mm
H
D
Inside diameter of the bush mm
i
D
Inside diameter of the bush in the ring gauge mm
i, ch
D
Outside diameter of the bush mm
o
F
Checking load mm
ch
d
Diameter of the checking block or ring gauge mm
ch, 1
d
Diameter of the setting plug or plug gauge mm
ch, 2
r
Flange radius mm
a
s
mm
Thickness of the backing layer
1
a
s
Thickness of the bearing material layer mm
2
a
s
mm
Wall thickness
3
s
Flange thickness mm
fl
Tolerance of D
∆D
mm
o
o
Elastic reduction of the outside diameter under checking load F
v mm
ch
z Distance apart of the halves of the checking block mm
Indicator reading mm
∆z
∆z
Circumference indicator reading for test D mm
D
a
For bushes which are made of a single material, s = s or s = s .
1 3 2 3

5 Presentation of data on drawing
The drawing should show either
⎯ the outside diameter, D , and the wall thickness, s , or
o 3
⎯ the outside diameter, D , and the inside diameter, D .
o i
Wall thickness, s , and inside diameter, D , shall not be specified together on the same drawing.
3 i
See Figure 1.
2 ©
...
