This part of ISO 16049 specifies utilization guidelines and the principles to be used in tie-down/lashing
strength calculations for the use of air cargo restraint straps on board civil transport aircraft.
Throughout this part of ISO 16049, the minimum essential criteria are identified by use of the key word
“shall”. Recommended criteria are identified by use of the key word “should” and, while not mandatory,
are considered to be of primary importance in providing safe lashing arrangements. Deviation from
recommended criteria should only occur after careful consideration and thorough service evaluation
have shown alternate methods to be satisfactory.
INTERNATIONAL STANDARD ISO 16049-2:2013(E)
Air cargo equipment — Restraint straps —
Part 2:
Utilization guidelines and lashing calculations
1 Scope
1.1 This part of ISO 16049 aims to provide general utilization guidelines and calculation methods
adequate to guarantee the effectiveness and ultimate load strength of tie-down/lashing arrangements
performed to restrain cargo on board civil transport aircraft during flight:
a) cargo loaded and tied down onto airworthiness approved air cargo pallets, themselves restrained
into aircraft lower deck or main deck or upper deck cargo systems meeting the restraint requirements
of air cargo pallets approved in accordance with ISO 8097, (NAS3610) or ISO/PAS 21100, or
b) additional tie-down on aircraft structure when necessitated by pallet maximum gross mass or
centre of gravity limits, or
c) non-unitized individual pieces of cargo, or pieces of cargo placed onto an unrestrained (“floating”) pallet
into either lower deck, main deck or upper deck containerized cargo compartments of an aircraft, or
d) individual pieces of load loaded in non-containerized (bulk loaded) baggage or cargo compartments.
1.2 This part of ISO 16049 applies to cargo tie-down/lashing arrangements using exclusively air
cargo restraint straps conforming to ISO 16049-1. Its general recommendations may also be used for
tie-down arrangements using other means (e.g. steel cables, rope, other types of straps), but under the
user’s responsibility as to their adequacy and the strength calculations required.
NOTE 1 Where tie-down is performed onto aircraft structure as per 1.1 b) or c), additional restrictions can be
stated in the aircraft’s Authority approved Weight and Balance Manual.
NOTE 2 The use of chains or other rigid devices for tie-down onto civil transport aircraft floor tracks is not part
of the scope of this part of ISO 16049, since it is not recommended due to the possibility of generating excessive
stresses in the aircraft structure, except where explicitly approved in the manufacturer’s Authority approved
Weight and Balance Manual.
1.3 This part of ISO 16049 aims to provide industry recognized means of complying with Airworthiness
Authorities general regulations applicable to load securing on board civil transport aircraft (see 14 CFR
Part 25 and EASA CS-25), and aircraft manufacturers Authority approved Weight and Balance Manuals
for each aircraft type as specified therein. It is not the intent of this part of ISO 16049 to specify when
restraint straps should be used, but how they should be used. It does not, under any circumstance,
supersede the requirements of any of the above documents that take precedence at all times.
2 Normative references
The following referenced documents are indispensable for the application of this document. For dated
references, only the edition cited applies. For undated references, the latest edition of the referenced
document (including any amendments) applies.
ISO 7166, Aircraft — Rail and stud configuration for passenger equipment and cargo restraint
ISO 8097:2001, Aircraft — Minimum airworthiness requirements and test conditions for certified air cargo
1)
unit load devices
1) Endorsement of NAS 3610 revision 10, TSO/ETSO/CTSO/JTSO C-90c.
ISO 9788, Air cargo equipment — Cast components of double stud fitting assembly with a load capacity of
22 250 N (5 000 lbf), for aircraft cargo restraint
ISO 10254, Air cargo and ground equipment — Vocabulary
ISO 16049-1, Air cargo equipment — Restraint straps — Part 1: Design criteria and testing methods
ISO/PAS 21100, Air cargo unit load devices — Performance requirements and test parameters(TSO/ETSO/
CTSO/JTSO C-90d)
CAAC CCAR-25, Airworthiness Standards — Transport Category Airplanes
European Aviation Safety Agency (EASA) Certification Specification CS-25, Airworthiness Standards:
2)
transport category aeroplanes
3)
EASA European Technical Standard Order ETSO C172 — Cargo Restraint Strap Assemblies
4)
European Aviation Safety Agency (EASA) EU-OPS 1.035, Quality system
5)
Japanese Airworthiness Standard Part 3 (Civil Aeronautics Law Article 10 § 4)
USA Code of Federal Regulations (CFR) Title 14 Part 25, Airworthiness Standards: transport category
6)
airplanes. (“14 CFR Part 25”)
7)
USA Federal Aviation Administration Technical Standard Order TSO C172 — Cargo Restraint Strap Assemblies
Federal Aviation Administration (FAA) Advisory Circular AC 120-59, Air carriers internal evaluation
8)
programs
NOTE Also see other informative references in Bibliography.
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 10254 and the following apply.
3.1
tie-down
lashing
fact of restraining cargo movements in relation to an aircraft’s structure, throughout the range of
relative accelerations resulting from the allowable flight envelope, by means of an appropriate use of a
number of elementary tie-down devices against each direction of restraint
2) EASA CS-25 constitutes the European governments transport aircraft airworthiness Regulations, and can, as
well as EU-OPS, be obtained from European Aviation Safety Agency (EASA), Otto Platz 1, Postfach 101253, D-50452
Cologne, Germany, or its web site at http://www.easa.europa.eu/.

3) See footnote 2.
4) See footnote 2.
5) The Japanese Airworthiness Standard Part 3 (ISBN 4-89279-661-1) constitutes the Japanese government
transport aircraft airworthiness approval Regulations, and can be obtained from the Civil Aviation Bureau (CAB)
,
of the Ministry of Land Infrastructure, Tourism and Transport, Tokyo, Japan, or its web site at http://www.mlit.
go.jp/en.
6) The Code of Federal Regulations (CFR) Title 14 Part 25, abbreviated throughout this standard as “14 CFR Part
25”, constitutes the USA government transport aircraft airworthiness Regulations, and can be obtained from the
US Government Printing Office, Mail Stop SSOP, Washington DC 20402-9328, USA, or its website at http://www.
gpoaccess.gov/. Advisory Circulars can be obtained from the FAA at its website http://www.faa.gov/.
7) See footnote 6.
8) See footnote 6.
2 © ISO 2013 – All rights reserved

3.2
tie-down arrangement
geometric layout of an assembly of elementary tie-down devices affixed and tensioned around a piece of
cargo in order to ensure its tie
...
