TECHNICAL SPECIFICATION ISO/TS 31657-3:2020(E)
Plain bearings — Hydrodynamic plain journal bearings
under steady-state conditions —
Part 3:
Functions for calculation of tilting pad journal bearings
1 Scope
This document specifies the characteristic values for selected tilting-pad journal bearings with four or
five centrally or eccentrically supported tilting pads and with angular spans of pad sliding surfaces of
Ω = 80°, 60° and 45°.
The functions plotted and listed in table form below are required for the operationally safe design
of hydrodynamic tilting-pad journal bearings according to ISO/TS 31657-1. They are based on the
presumptions and boundary conditions indicated there and only apply to stationary operating states.
The symbols used are explained in ISO/TS 31657-1; calculation examples are also included there.
The calculation method described in ISO/TS 31657-1 can also be used for other tilting-pad journal
bearing designs, if the numerical solutions of the basic equations are available in the same manner for
these designs.
2 Normative references
There are no normative references in this document.
3 Terms and definitions
No terms and definitions are listed in this document.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at http:// www .electropedia .org/
4 Functions for calculation of multi-lobed journal bearings
4.1 General
The characteristic values for symmetrically loaded tilting-pad journal bearings with four and five
*
centrally (relative angular distance between leading edge and pivot position of pad Ω = 0,5) or
F
*
eccentrically (Ω = 0,6) supported tilting pads are indicated below in table form.
F
The characteristic values were calculated for the geometrical parameters summarised in Figure 1
(angular spans of pad sliding surface Ω, angular coordinates of pivot position of pad ϕ , profile factors
F ,1
* *
K , bearing width ratios B ) in the operating range 0,02 ≤ h ≤ 1. The following (dimensionless)
P min
characteristic values are individually listed in table form:
a) Static characteristic values
Sommerfeld number:
F⋅ψ
eff
So=
BD⋅⋅ηω⋅
eff
Relative eccentricity:
e
ε =
C
R,eff
Attitude angle β in ° .
Product of maximum lubricant film pressure parameter and Sommerfeld number:
p ⋅ψ
max eff
*
pS⋅=o
max
ηω⋅
eff
Minimum relative lubricant film thickness:
h
min
*
h =
min
C
R,eff
Friction force parameter:
f
*
F =⋅So
f
ψ
eff
Lubricant flow rate parameter due to hydrodynamic pressure build-up:
Q
*
Q =
Q
Lubricant flow rate parameter due to supply pressure:
Q
p
*
Q =
p
*
PQ⋅
en 0
Lubricant flow rate parameter at the exit of the lubricant gap:
Q
*
Q =
Q
Non-dimensional difference between maximum temperature of lubricant film and lubricant
temperature in the lubricant pocket:
ρψ⋅⋅c
p eff
*
ΔΔT = ⋅ T
max max
pf⋅
b) Dynamic characteristic values
Non-dimensional lubricant film stiffness coefficients:
2 © ISO 2020 – All rights reserved

ψ
eff
*
c = ⋅c    (i, k = 1, 2)
ik, ik,
2⋅⋅Bηω⋅
eff
Non-dimensional lubricant film damping coefficients:
ψ
eff
*
d = ⋅⋅ω d  (i, k = 1, 2)
ik, ik,
2⋅⋅Bηω⋅
eff
*
For some selected tilting-pad journal bearings (Ω = 0,6, Ω = 45°, ϕ = 36°), these characteristic
F F ,1
values are shown graphically as a function of the Sommerfeld number So and the profile factor K
P
in Annex A, Figures A.1 to A.11.
Figure 1 — Geometrical parameters of selected tilting-pad journal bearings
* *
(Ω = 0,5 and Ω = 0,6)
F F
4.2 Tilting-pad journal bearings with four tilting pads
Characteristic values for tilting-pad journal bearings with four centrally or eccentrically supported
tilting pads and angular spans of pad sliding surface of Ω = 80° or 60° are contained in Tables 1 to 34.
4 © ISO 2020 – All rights reserved

*
Table 1 — Characteristic values of a tilting-pad bearing with four centrally (Ω = 0,5) supported tilting pads (Ω = 80°, φ = 45°, K = 2,
F,1 P
F
B* = 0,5)
* * * *
* * * * * * * * * * *
So ε β [°] F
pS⋅ o h Q Q Q ΔT c c c c d d d d
f
max min 3 P 2 max 11 12 21 22 11 12 21 22
0,000 0,000 0,00 0,278 0,829 2,785 0,909 0,000 1,730 1,02 0,283 0,000 0,000 0,283 0,335 0,000 0,000 0,335
0,021 0,050 0,00 0,308 0,796 2,789 0,909 0,000 1,730 1,10 0,286 0,000 0,000 0,286 0,337 0,000 0,000 0,337
0,042 0,100 0,00 0,342 0,763 2,800 0,907 0,000 1,730 1,18 0,295 0,000 0,000 0,295 0,342 0,000 0,000 0,342
0,086 0,200 0,00 0,426 0,698 2,846 0,902 0,000 1,732 1,36 0,330 0,000 0,000 0,330 0,362 0,000 0,000 0,362
0,136 0,300 0,00 0,539 0,632 2,925 0,893 0,000 1,735 1,58 0,397 0,000 0,000 0,397 0,399 0,000 0,000 0,399
0,197 0,400 0,00 0,692 0,567 3,043 0,881 0,000 1,739 1,84 0,505 0,000 0,000 0,505 0,456 0,000 0,000 0,456
0,273 0,500 0,00 0,907 0,503 3,210 0,863 0,000 1,744 2,15 0,678 0,000 0,000 0,678 0,546 0,000 0,000 0,546
0,374 0,600 0,00 1,216 0,440 3,436 0,841 0,000 1,752 2,51 0,954 0,000 0,000 0,954 0,686 0,000 0,000 0,686
0,512 0,700 0,00 1,674 0,378 3,741 0,812 0,000 1,760 2,93 1,403 0,000 0,000 1,403 0,905 0,000 0,000 0,905
0,713 0,800 0,00 2,392 0,317 4,157 0,776 0,000 1,773 3,51 2,167 0,000 0,000 2,167 1,253 0,000 0,000 1,253
1,023 0,900 0,00 3,587 0,259 4,735 0,732 0,000 1,788 4,34 3,562 0,000 0,000 3,562 1,841 0,000 0,000 1,841
1,245 0,950 0,00 4,501 0,230 5,111 0,707 0,000 1,796 4,88 4,707 0,000 0,000 4,707 2,299 0,000 0,000 2,299
1,541 1,000 0,00 5,768 0,202 5,568 0,679 0,000 1,806 5,65 6,389 0,000 0,000 6,389 2,931 0,000 0,000 2,931
1,943 1,050 0,00 7,584 0,174 6,134 0,648 0,000 1,816 6,49 8,951 0,000 0,000 8,951 3,848 0,000 0,000 3,848
2,512 1,100 0,00 10,311 0,147 6,850 0,613 0,000 1,829 7,76 13,077 0,000 0,000 13,077 5,241 0,000 0,000 5,241
3,358 1,150 0,00 14,651 0,121 7,787 0,575 0,000 1,842 9,64 20,191 0,000 0,000 20,191 7,500 0,000 0,000 7,500
4,708 1,200 0,00 22,167 0,095 9,074 0,532 0,000 1,857 12,41 33,852 0,000 0,000 33,852 11,308 0,000 0,000 11,308
7,086 1,250 0,00 36,774 0,070 10,962 0,482 0,000 1,874 16,96 63,748 0,000 0,000 63,748 19,069 0,000 0,000 19,069
12,031 1,300 0,00 71,724 0,046 14,101 0,422 0,000 1,895 26,41 148,095 0,000 0,000 148,095 37,650 0,000 0,000 37,650
26,371 1,350 0,00 197,100 0,024 20,706 0,346 0,000 1,923 51,75 535,824 0,000 0,000 535,824 107,479 0,000 0,000 107,478
58,756 1,380 0,00 571,372 0,012 31,042 0,284 0,000 1,945 109,29 2 141,057 0,000 0,000 2 141,055 306,671 0,000 0,000 306,670

6 © ISO 2020 – All rights reserved
*
Table 2 — Characteristic values of a tilting-pad bearing with four eccentrically (Ω = 0,6) supported tilting pads (Ω = 80°, φ = 45°, K = 2,
F,1 P
F
B* = 0,5)
*
* * * * * * * * * * * * * *
So ε β [°] F
pS⋅ o h Q Q Q ΔT c c c c d d d d
f
max min 3 P 2 max 11 12 21 22 11 12 21 22
0,000 0,000 0,00 0,443 0,664 2,789 1,572 0,000 1,542 1,07 0,473 0,000 0,000 0,473 0,459 0,000 0,000 0,459
0,025 0,050 0,00 0,481 0,643 2,792 1,572 0,000 1,542 1,14 0,477 0,000 0,000 0,477 0,461 0,000 0,000 0,461
0,051 0,100 0,00 0,522 0,622 2,803 1,570 0,000 1,544 1,23 0,486 0,000 0,000 0,486 0,468 0,000 0,000 0,468
0,106 0,200 0,00 0,623 0,582 2,844 1,567 0,000 1,545 1,42 0,528 0,000 0,000 0,528 0,496 0,000 0,000 0,496
0,166 0,300 0,00 0,752 0,540 2,916 1,561 0,000 1,546 1,64 0,605 0,000 0,000 0,605 0,545 0,000 0,000 0,545
0,234 0,400 0,00 0,925 0,496 3,016 1,544 0,000 1,553 1,91 0,728 0,000 0,000 0,728 0,621 0,000 0,000 0,621
0,320 0,500 0,00 1,159 0,450 3,164 1,533 0,000 1,556 2,25 0,920 0,000 0,000 0,920 0,735 0,000 0,000 0,735
0,440 0,600 0,00 1,491 0,402 3,381 1,527 0,000 1,556 2,65 1,222 0,000 0,000 1,222 0,902 0,000 0,000 0,902
0,595 0,700 0,00 1,982 0,352 3,666 1,512 0,000 1,560 3,14 1,707 0,000 0,000 1,707 1,150 0,000 0,000 1,150
0,819 0,800 0,00 2,751 0,300 4,066 1,494 0,000 1,564 3,77 2,533 0,000 0,000 2,533 1,529 0,000 0,000 1,529
1,164 0,900 0,00 4,056 0,246 4,649 1,474 0,000 1,567 4,81 4,052 0,000 0,000 4,052 2,134 0,000 0,000 2,134
1,412 0,950 0,00 5,059 0,219 5,042 1,463 0,000 1,568 5,45 5,296 0,000 0,000 5,296 2,623 0,000 0,000 2,623
1,737 1,000 0,00 6,449 0,192 5,527 1,449 0,000 1,571 6,18 7,103 0,000 0,000 7,103 3,316 0,000 0,000 3,316
2,175 1,050 0,00 8,424 0,166 6,132 1,434 0,000 1,573 7,14 9,848 0,000 0,000 9,848 4,311 0,000 0,000 4,311
2,791 1,100 0,00 11,376 0,140 6,905 1,416 0,000 1,576 8,33 14,237 0,000 0,000 14,237 5,801 0,000 0,000 5,801
3,700 1,150 0,00 16,040 0,115 7,920 1,395 0,000 1,580 10,23 21,778 0,000 0,000 21,778 8,167 0,000 0,000 8,167
5,133 1,200 0,00 24,049 0,091 9,305 1,372 0,000 1,583 13,00 36,003 0,000 0,000 36,003 12,305 0,000 0,000 12,305
7,634 1,250 0,00 39,539 0,067 11,327 1,343 0,000 1,588 17,56 67,340 0,000 0,000 67,340 20,207 0,000 0,000 20,207
12,774 1,300 0,00 76,100 0,045 14,616 1,308 0,000 1,594 27,05 154,291 0,000 0,000 154,291 39,597 0,000 0,000 39,597
27,474 1,350 0,00 2
...
