1 Scope
This part of IEC 61156 describes symmetrical pair/quad cables intended for horizontal floor cabling
in class D, E, E , F and F channels (Cat 5e, Cat 6, Cat 6 , Cat 7, Cat 7 ) as defined in ISO/IEC
A A A A
11801 and ISO/IEC 24702.
NOTE Cabling for various severities of industrial environments is specified in ISO/IEC 24702. Environmental
classifications are presented in ISO/IEC 24702 with three levels of severity in four areas: mechanical, ingress, climatic,
and electromagnetic; thus, in tabular form, they are referred to as the “MICE table”.
This blank detail specification includes additional recommended environmental characteristics and
severities, which are derived from the environmental classifications that are specified for cabling
for industrial environments.
The blank detail specification determines the layout and style for detail specifications describing
symmetrical pair
...
