IEC 61158-4-19:2010

IEC 61158-4-19 ®
Edition 2.0 2010-08
INTERNATIONAL
STANDARD
colour
inside
Industrial communication networks – Fieldbus specifications –
Part 4-19: Data-link layer protocol specification – Type 19 elements

All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form
or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from
either IEC or IEC's member National Committee in the country of the requester.
If you have any questions about IEC copyright or have an enquiry about obtaining additional rights to this publication,
please contact the address below or your local IEC member National Committee for further information.

IEC Central Office
3, rue de Varembé
CH-1211 Geneva 20
Switzerland
Email: inmail@iec.ch
Web: www.iec.ch
About the IEC
The International Electrotechnical Commission (IEC) is the leading global organization that prepares and publishes
International Standards for all electrical, electronic and related technologies.

About IEC publications
The technical content of IEC publications is kept under constant review by the IEC. Please make sure that you have the
latest edition, a corrigenda or an amendment might have been published.
ƒ Catalogue of IEC publications: www.iec.ch/searchpub
The IEC on-line Catalogue enables you to search by a variety of criteria (reference number, text, technical committee,…).
It also gives information on projects, withdrawn and replaced publications.
ƒ IEC Just Published: www.iec.ch/online_news/justpub
Stay up to date on all new IEC publications. Just Published details twice a month all new publications released. Available
on-line and also by email.
ƒ Electropedia: www.electropedia.org
The world's leading online dictionary of electronic and electrical terms containing more than 20 000 terms and definitions
in English and French, with equivalent terms in additional languages. Also known as the International Electrotechnical
Vocabulary online.
ƒ Customer Service Centre: www.iec.ch/webstore/custserv
If you wish to give us your feedback on this publication or need further assistance, please visit the Customer Service
Centre FAQ or contact us:
Email: csc@iec.ch
Tel.: +41 22 919 02 11
Fax: +41 22 919 03 00
IEC 61158-4-19 ®
Edition 2.0 2010-08
INTERNATIONAL
STANDARD
colour
inside
Industrial communication networks – Fieldbus specifications –
Part 4-19: Data-link layer protocol specification – Type 19 elements

INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
PRICE CODE
XF
ICS 25.04.40; 35.100.20; 35.110 ISBN 978-2-88912-090-1
– 2 – 61158-4-19 © IEC:2010(E)
CONTENTS
FOREWORD.7
INTRODUCTION.9
1 Scope.11
1.1 General .11
1.2 Specifications.11
1.3 Procedures.11
1.4 Applicability.11
1.5 Conformance.12
2 Normative references .12
3 Terms, definitions, symbols, abbreviations and conventions .12
3.1 Reference model terms and definitions.12
3.2 Additional Type 19 terms and definitions .12
3.3 Symbols .15
3.4 Abbreviations .16
3.5 Additional conventions .17
4 DL-protocol overview.18
5 DLPDU structure .19
5.1 Overview .19
5.2 General DLPDU identification.19
5.3 General DLPDU structure.20
5.4 DLPDU header .21
5.5 MDT DLPDU .21
5.6 AT DLPDU .32
6 DL management .42
6.1 Overview .42
6.2 Enable and disable cyclic communication .42
6.3 Hot-plug procedure.50
6.4 Status procedures .51
7 Data transmission methods .51
7.1 Overview .51
7.2 SVC .52
7.3 RTC .52
7.4 Multiplexing of real-time data with data containers .52
7.5 Multiplexing of real-time data using SMP.59
8 Telegram timing and DLPDU handling .62
8.1 Usage of real-time channel with different network topologies.62
8.2 Communication mechanisms .63
8.3 Device synchronization.69
9 Error handling and monitoring .70
9.1 Failure of telegrams .70
9.2 Response to MDT and AT telegram failure .70
9.3 Service channel error messages.71
Annex A (normative) IDN – Identification numbers .72
Annex B (normative) SCP– Classification.106
Annex C (normative) GDP (Generic Device Profile) . 118

61158-4-19 © IEC:2010(E) – 3 –
Bibliography.140

Figure 1 – Valid MDT and AT telegram combinations .19
Figure 2 – Offsets within MDT payload.26
Figure 4 – Communication phase transitions.43
Figure 6 – Block diagram of master and slave.63
Figure 7 – Telegram sequence.65
Figure 8 – Beginning of telegram .66
Figure 9 – Access to the medium .66
Figure 10 – Timing diagram of CP0.68
Figure 11 – Timing diagram of CP1 and CP2 with 2 MDT/AT .69
Figure 12 – Timing diagram of CP1 and CP2 with 2 MDT/AT .69
Figure 13 – Synchronization timing .70
Figure 14 – Synchronization signal generation.70
Figure A.1 – Lengths of MDTs (example) .80
Figure A.2 – Lengths of ATs (example) .82
Figure A.3 – Structure of MAC address.87
Figure A.4 – Structure of IP address .88
Figure A.5 – Structure of subnet mask .88
Figure A.6 – Structure of gateway address .89
Figure B.1 – Technical Profiling in Type 19.106
Figure C.1 – Type 19 state machine .121

Table 1 – Ethernet DLPDU identification .20
Table 2 – Data structure in a DLPDU .20
Table 3 – DLPDU payload header.21
Table 4 – DLPDU type .21
Table 5 – MDT MST header .22
Table 6 – MDT MST fields to be considered by the slave .22
Table 7 – MDT phase.22
Table 8 – MDT0 structure in CP0 .23
Table 9 – Communication version .23
Table 10 – MDT0 in CP1 and CP2 .24
Table 11 – MDT1 in CP1 and CP2 .24
Table 12 – MDT2 in CP1 and CP2 .25
Table 13 – MDT3 in CP1 and CP2 .25
Table 14 – MDT data field.26
Table 15 – MDT hot-plug field in HP0 and HP1 .27
Table 16 – Device address field .27
Table 17 – HP control field (in HP0 and HP1) .28
Table 18 – MDT service channel field .29
Table 19 – MDT SVC (for each slave) .29
Table 20 – SVC control word (DLL).29

– 4 – 61158-4-19 © IEC:2010(E)
Table 21 – MDT real-time data field .30
Table 22 – MDT real-time data (device control).30
Table 23 – MDT real-time data (connection data).30
Table 24 – Device control field.31
Table 25 – Connection control .31
Table 26 – Structure of a configured connection .32
Table 27 – AT MST header .32
Table 28 – AT MST fields to be considered by the slave .33
Table 29 – AT0 structure in CP0 .33
Table 30 – AT0 in CP1 and CP2 .34
Table 31 – AT1 in CP1 and CP2 .35
Table 32 – AT2 in CP1 and CP2 .35
Table 33 – AT3 in CP1 and CP2 .36
Table 34 – AT data field.36
Table 35 – AT hot-plug field in HP0 and HP1 .37
Table 36 – HP status field (in HP0 and HP1).38
Table 37 – AT service channel field .38
Table 38 – AT SVC (for each slave).38
Table 39 – AT SVC status description (DLL) .39
Table 40 – AT real-time data field .39
Table 41 – AT real-time data (device status).40
Table 42 – AT real-time data (connection data).40
Table 43 – Device status field .41
Table 44 – MDT hot-plug field in CP3 and after ring recovery .47
Table 45 – Structure of the Session Control Header.60
Table A.1 – List of relevant communication-related IDNs .72
Table A.2 – Attributes of IDN S-0-1000 .75
Table A.3 – Attributes of IDN S-0-1002 .76
Table A.4 – Attributes of IDN S-0-1003 .76
Table A.5 – Attributes of IDN S-0-1005 .77
Table A.6 – Attributes of IDN S-0-1006 .77
Table A.7 – Attributes for IDN S-0-1007.78
Table A.8 – Attributes for IDN S-0-1008.79
Table A.9 – Attributes of IDN S-0-1009 .79
Table A.10 – C-Dev Offset in MDT .80
Table A.11 – Attributes of IDN S-0-1010 .80
Table A.12 – Attributes of IDN S-0-1011 .81
Table A.13 – S-Dev Offset in AT .81
Table A.14 – Attributes of IDN S-0-1012 .82
Table A.15 – Attributes of IDN S-0-1013 .83
Table A.16 – SVC Offset in MDT.83
Table A.17 – Attributes of IDN S-0-1014 .84
Table A.18 – SVC Offset in AT.84

61158-4-19 © IEC:2010(E) – 5 –
Table A.19 – Attributes of IDN S-0-1015 .85
Table A.20 – Attributes of IDN S-0-1016 .85
Table A.21 – Attributes of IDN S-0-1017 .86
Table A.22 – Attributes of IDN S-0-1019 .86
Table A.23 – Attributes of IDN S-0-1020 .87
Table A.24 – Attributes of IDN S-0-1021 .88
Table A.25 – Attributes of IDN S-0-1022 .89
Table A.26 – Attributes of IDN S-0-1023 .90
Table A.27 – Attributes of IDN S-0-1024 .90
Table A.28 – Attributes of IDN S-0-1026 .91
Table A.29 – Attributes of IDN S-0-1027.0.1 .91
Table A.30 – Attributes of IDN S-0-1027.0.2 .92
Table A.31 – Attributes of IDN S-0-1028 .92
Table A.32 – Attributes of IDN S-0-1035 .93
Table A.33 – Attributes of IDN S-0-1040 .93
Table A.34 – Attributes of IDN S-0-1041 .94
Table A.35 – Attributes of IDN S-0-1044 .94
Table A.36 – Attributes of IDN S-0-1045 .95
Table A.37 – Attributes of IDN S-0-1046 .95
Table A.38 – Attributes of IDN S-0-1050.x.1 .96
Table A.39 – Attributes of IDN S-0-1050.x.2 .96
Table A.40 – Attributes of IDN S-0-1050.x.3 .97
Table A.41 – Attributes of IDN S-0-1050.x.4 .97
Table A.42 – Attributes of IDN S-0-1050.x.5 .98
Table A.43 – Attributes of IDN S-0-1050.x.6 .98
Table A.44 – Attributes of IDN S-0-1050.x.8 .99
Table A.45 – Attributes of IDN S-0-1050.x.10.99
Table A.46 – Attributes of IDN S-0-1050.x.11.100
Table A.47 – Attributes of IDN S-0-1050.x.12.100
Table A.48 – Attributes of IDN S-0-1050.x.20.101
Table A.49 – Attributes of IDN S-0-1050.x.21.101
Table A.50 – Attributes of IDN S-0-1051 .102
Table A.51 – Attributes of IDN S-0-1100.0.1 .102
Table A.52 – Attributes of IDN S-0-1100.0.2 .103
Table A.53 – Attributes of IDN S-0-1100.0.3 .103
Table A.54 – Attributes of IDN S-0-1101.x.1 .104
Table A.55 – Attributes of IDN S-0-1101.x.2 .104
Table A.56 – Attributes of IDN S-0-1101.x.3 .105
Table C.1 – List of relevant communication-related IDNs .123
Table C.2 – Attributes of IDN S-0-1300.x.1 .124
Table C.3 – Attributes of IDN S-0-1300.x.2 .125
Table C.4 – Attributes of IDN S-0-1300.x.3 .125
Table C.5 – Attributes of IDN S-0-1300.x.4 .126

– 6 – 61158-4-19 © IEC:2010(E)
Table C.6 – Attributes of IDN S-0-1300.x.5 .126
Table C.7 – Attributes of IDN S-0-1300.x.6 .127
Table C.8 – Attributes of IDN S-0-1300.x.7 .127
Table C.9 – Attributes of IDN S-0-1300.x.8 .128
Table C.10 – Attributes of IDN S-0-1300.x.9 .128
Table C.11 – Attributes of IDN S-0-1300.x.10 .129
Table C.12 – Attributes of IDN S-0-1300.x.11 .129
Table C.13 – Attributes of IDN S-0-1300.x.12 .130
Table C.14 – Attributes of IDN S-0-1300.x.13 .130
Table C.15 – Attributes of IDN S-0-1300.x.14 .131
Table C.16 – Attributes of IDN S-0-1300.x.20 .131
Table C.17 – Attributes of IDN S-0-1300.x.21 .132
Table C.18 – Attributes of IDN S-0-1300.x.22 .132
Table C.19 – Attributes of IDN S-0-1300.x.23 .133
Table C.20 – Attributes of IDN S-0-1301 .133
Table C.21 – Coding of S-1301.134
Table C.22 – Attributes of IDN S-0-1302.x.1 .134
Table C.23 – Coding of S-1302.x.1 .135
Table C.24 – Attributes of IDN S-0-1302.x.2 .135
Table C.25 – Attributes of IDN S-0-1302.x.3 .136
Table C.26 – Attributes of IDN S-0-1303.0.1 .136
Table C.27 – Attributes of IDN S-0-1303.0.2 .137
Table C.28 – Coding of S-1303.0.2 .137
Table C.29 – Attributes of IDN S-0-1303.0.3 .137
Table C.30 – Coding of S-1303.0.2 .138
Table C.31 – Attributes of IDN S-0-1303.0.10 .138
Table C.32 – Attributes of IDN S-0-1303.0.11 .139
Table C.33 – Attributes of IDN S-0-1305.0.1 .139

61158-4-19 © IEC:2010(E) – 7 –
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
INDUSTRIAL COMMUNICATION NETWORKS –
FIELDBUS SPECIFICATIONS –
Part 4-19: Data-link layer protocol specification –
Type 19 elements
FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
in the subject dealt with may participate in this preparatory work. International, governmental and non-
governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
with the International Organization for Standardization (ISO) in accordance with conditions determined by
agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence
between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
the latter.
5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity
assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any
services carried out by independent certification bodies.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
International Standard IEC 61158-4-19 has been prepared by subcommittee 65C: Industrial
networks, of IEC technical committee 65: Industrial-process measurement, control and
automation.
This second edition cancels and replaces the first edition published in 2007. This edition
constitutes a technical revision.
The main changes with respect to the previous edition are listed below:
• increasing the number of supported devices (511 instead of 254);
• introducing a communication version identification;
• adding a mechanism for remote address allocation;
• introducing enhanced parameter addressing (32 bit instead of 16 bit);
• restructuring control and status word;
• improving the redundancy and hotplug features;

– 8 – 61158-4-19 © IEC:2010(E)
• improving the error handling;
• adding a multiplexing protocol (SMP: Type 19 Messaging Protocol).
The text of this standard is based on the following documents:
FDIS Report on voting
65C/605/FDIS 65C/619/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
This publication has been drafted in accordance with ISO/IEC Directives, Part 2.
A list of all the parts of the IEC 61158 series, published under the general title Industrial
communication networks – Fieldbus specifications, can be found on the IEC web site.
The committee has decided that the contents of this publication will remain unchanged until
the stability date indicated on the IEC web site under "http://webstore.iec.ch" in the data
related to the specific publication. At this date, the publication will be
• reconfirmed;
• withdrawn;
• replaced by a revised edition, or
• amended.
NOTE The revision of this standard will be synchronized with the other parts of the IEC 61158 series.

IMPORTANT – The 'colour inside' logo on the cover page of this publication indicates that it
contains colours which are considered to be useful for the correct understanding of its
contents. Users should therefore print this document using a colour printer.

61158-4-19 © IEC:2010(E) – 9 –
INTRODUCTION
This part of IEC 61158 is one of a series produced to facilitate the interconnection of
automation system components. It is related to other standards in the set as defined by the
“three-layer” fieldbus reference model described in IEC/TR 61158-1.
The data-link protocol provides the data-link service by making use of the services available
from the physical layer. The primary aim of this standard is to provide a set of rules for
communication expressed in terms of the procedures to be carried out by peer data-link
entities (DLEs) at the time of communication. These rules for communication are intended to
provide a sound basis for development in order to serve a variety of purposes:
a) as a guide for implementors and designers;
b) for use in the testing and procurement of equipment;
c) as part of an agreement for the admittance of systems into the open systems environment;
d) as a refinement to the understanding of time-critical communications within OSI.
This standard is concerned, in particular, with the communication and interworking of sensors,
effectors and other automation devices. By using this standard together with other standards
positioned within the OSI or fieldbus reference models, otherwise incompatible systems may
work together in any combination.
NOTE Use of some of the associated protocol types is restricted by their intellectual-property-right holders. In all
cases, the commitment to limited release of intellectual-property-rights made by the holders of those rights permits
a particular data-link layer protocol type to be used with physical layer and application layer protocols in Type
combinations as specified explicitly in the profile parts. Use of the various protocol types in other combinations
may require permission from their respective intellectual-property-right holders.
The International Electrotechnical Commission (IEC) draws attention to the fact that it is
claimed that compliance with this document may involve the use of patents concerning Type
19 elements and possibly other types given in this document as follows:
DE 102 37 097 [RI] Korrektur von Signallaufzeiten in verteilten
Kommunikationssystemen
DE 102 00 405 0416.4-42 [RI] Verfahren zur Synchronisation in einem redundanten
Kommunikationssystem
DE 102 00 502 4759.8-32 [RI] Verfahren zur Laufzeitkorrektur in einer Kommunikationsstruktur
DE 102 00 4056364.0-31 [RI] Verfahren zum Betreiben eines Netzwerks mit Ringtopologie
DE 103 12 907.3-31 [RI] Kommunikationssystem mit redundanter Kommunikation
IEC takes no position concerning the evidence, validity and scope of these patent rights.
The holder of these patent rights has assured the IEC that he/she is willing to negotiate
licenses either free of charge or under reasonable and non-discriminatory terms and
conditions with applicants throughout the world. In this respect, the statement of the holder of
these patent rights is registered with IEC. Information may be obtained from:
[RI] Rexroth Indramat GmbH
Bgm.-Dr.-Nebel-Str. 2
D - 97816 Lohr
Germany
Attention is drawn to the possibility that some of the elements of this document may be the
subject of patent rights other than those identified above. IEC shall not be held responsible for
identifying any or all such patent rights.

– 10 – 61158-4-19 © IEC:2010(E)
ISO (www.iso.org/patents) and IEC (http://www.iec.ch/tctools/patent_decl.htm) maintain on-
line data bases of patents relevant to their standards. Users are encouraged to consult the
data bases for the most up to date information concerning patents.

61158-4-19 © IEC:2010(E) – 11 –
INDUSTRIAL COMMUNICATION NETWORKS –
FIELDBUS SPECIFICATIONS –
Part 4-19: Data-link layer protocol specification –
Type 19 elements
1 Scope
1.1 General
The data-link layer provides basic time-critical messaging communications between devices in
an automation environment.
This protocol provides communication opportunities to all participating data-link entities
a) in a synchronously-starting cyclic manner, according to a pre-established schedule, and
b) in a cyclic or acyclic asynchronous manner, as requested each cycle by each of those
data-link entities.
Thus this protocol can be characterized as one which provides cyclic and acyclic access
asynchronously but with a synchronous restart of each cycle.
1.2 Specifications
This standard specifies
a) procedures for the timely transfer of data and control information from one data-link user
entity to a peer user entity, and among the data-link entities forming the distributed data-
link service provider;
b) the structure of the fieldbus DLPDUs used for the transfer of data and control information
by the protocol of this standard, and their representation as physical interface data units.
1.3 Procedures
The procedures are defined in terms of
a) the interactions between peer DL-entities (DLEs) through the exchange of fieldbus
DLPDUs;
b) the interactions between a DL-service (DLS) provider and a DLS-user in the same system
through the exchange of DLS primitives;
c) the interactions between a DLS-provider and a Ph-service provider in the same system
through the exchange of Ph-service primitives.
1.4 Applicability
These procedures are applicable to instances of communication between systems which
support time-critical communications services within the data-link layer of the OSI or fieldbus
reference models, and which require the ability to interconnect in an open systems
interconnection environment.
Profiles provide a simple multi-attribute means of summarizing an implementation’s
capabilities, and thus its applicability to various time-critical communications needs.

– 12 – 61158-4-19 © IEC:2010(E)
1.5 Conformance
This standard also specifies conformance requirements for systems implementing these
procedures. This part of this standard does not contain tests to demonstrate compliance with
such requirements.
2 Normative references
The following referenced documents are indispensable for the application of this document.
For dated references, only the edition cited applies. For undated references, the latest edition
of the referenced document (including any amendments) applies.
IEC 61158-4-16:2007, Industrial communication networks – Fieldbus specifications –
Part 4-16: Data-link layer protocol specification – Type 16 elements
ISO/IEC 7498-1, Information technology – Open Systems Interconnection – Part 1: Basic
Reference Model: The Basic Model
ISO/IEC 7498-3, Information technology – Open Systems Interconnection – Part 3: Basic
Reference Model: Naming and addressing
ISO/IEC 8802-3, Information technology – Telecommunications and information exchange
between systems – Local and metropolitan area networks – Specific requirements – Part 3:
Carrier sense multiple access with collision detection (CSMA/CD) access method and
physical layer specifications
ISO 8601:2004, Data elements and interchange formats — Information interchange —
Representation of dates and times
3 Terms, definitions, symbols, acronyms, abbreviations and conventions
For the purposes of this document, the following terms, definitions, symbols, abbreviations
and conventions apply.
3.1 Reference model terms and definitions
This standard is based in part on the concepts developed in ISO/IEC 7498-1 and
ISO/IEC 7498-3, and makes use of the following terms defined therein.
3.2 Additional Type 19 terms and definitions
3.2.1
broadcast
transmission to all devices in a network without any acknowledgment by the receivers
3.2.2
communication cycle
fixed time period between two master synchronization telegrams in which real-time telegrams
are transmitted in the RT channel and non real-time telegrams are transmitted in the IP
channel
3.2.3
control unit
control device (for example, a PLC as specified in the IEC 61131 standard family)

61158-4-19 © IEC:2010(E) – 13 –
3.2.4
control word
two adjacent octets inside the master data telegram containing commands for the addressed
device
3.2.5
cross communication
direct multicast data transfer between devices
3.2.6
cycle time
duration of a communication cycle
3.2.7
cyclic communication
periodic exchange of telegrams
3.2.8
cyclic data
part of a telegram, which does not change its meaning during cyclic operation of the network
3.2.9
cyclic operation
operation in which devices in the communication network are addressed and queried one after
the other at fixed, constant time intervals
3.2.10
device
a slave in the communication network, (for example, a power drive system as defined in the
IEC 61800 standard family, I/O stations as defined in the IEC 61131 standard family)
3.2.11
device address field
address field (eight bits) containing the address of the device
3.2.12
device control
four adjacent octets inside the master data telegram containing commands for each device
3.2.13
device status
four adjacent octets inside the acknowledge telegram containing status information for each
device
3.2.14
DLE station identifier
network address assigned to a DLE
3.2.15
DLE station slot
unit (granularity of one) of position dependent mapping (for cyclic data field) of which a DLE
may occupy one or more, delineated by the range beginning at the DLE station identifier with
a length equal to the configured number of occupied slots
3.2.16
element
part of IDNs – each IDN has 7 elements, whereas each one has a specific meaning (for
example: number, name, data)
– 14 – 61158-4-19 © IEC:2010(E)
3.2.17
EtherType
part of the Type 19 specific telegram header
3.2.18
forwarding
mode by which a device passes on a received telegram to the other port, either changed or
unchanged
3.2.19
identification number
IDN
designation of operating data under which a data block is preserved with its attribute, name,
unit, minimum and maximum input values, and the data
3.2.20
line, line structure
network topology, in which the transmission medium is routed from station to station in the
form of a line; the information is transmitted in one direction from the master down to the last
slave in the line, and then flows back to the master via all the slaves in the reverse order
(CP16/3)
3.2.21
loopback
mode by which a device passes on a received telegram to the same port and to the other port,
either changed or unchanged
3.2.22
master
node, which assigns the other nodes (i.e., slaves) the right to transmit
3.2.23
master data telegram
MDT
telegram, in which the master inserts its data
3.2.24
master DLE
DLE that performs the functions of network master
3.2.25
master synchronization telegram
MST
telegram, or part of a telegram, in which the master inserts a time synchronization signal
3.2.26
MDT0 telegram
telegram, in which the master transmits its synchronization data, as well as parts or all of its
real-time data, to the slaves
3.2.27
participant
node
3.2.28
physical layer
first layer of the ISO-OSI reference model

61158-4-19 © IEC:2010(E) – 15 –
3.2.29
protocol
convention about the data formats, time sequences, and error correction in the data exchange
of communication systems
3.2.30
real-time data
part of the
...
