IEC

IEC 60874-10:1992

(Main)

Connectors for optical fibres and cables - Part 10: Sectional specification - Fibre optic connector type BFOC/2,5

Connectors for optical fibres and cables - Part 10: Sectional specification - Fibre optic connector type BFOC/2,5

Defines the requirements for type BFOC/2,5 connector sets. Type BFOC/2,5 is a sub-family of single position optical connector sets. They are characterized by a bayonet coupling mechanism and a cylindrical ferrule of 2,5 mm typical diameter. The sub-family includes plug-adapter-plug and plug-socket configurations. The contents of the corrigendum of May 1996 have been included in this copy.

Connecteurs pour fibres et câbles optiques - Partie 10: Spécification intermédiaire - Connecteur pour fibres optiques de type BFOC/2,5

Définit les exigences pour les jeux de connecteurs de type BFOC/2,5. Le type BFOC/2,5 est une sous-famille de jeux de connecteurs optiques à position unique. Ils sont caractérisés par un mécanisme d'accouplement à baïonnette et par un embout cylindrique au diamètre typique de 2,5 mm. La sous-famille inclut les configurations fiche-raccord-fiche et fiche-embase. Le contenu du corrigendum de mai 1996 a été pris en considération dans cet exemplaire.

General Information

Status
Withdrawn
Publication Date
30-Apr-1996
Withdrawal Date
29-Jun-2002
ICS
33.180.20 - Fibre optic interconnecting devices
Technical Committee
SC 86B - Fibre optic interconnecting devices and passive components
Current Stage
WPUB - Publication withdrawn
Completion Date
05-Jul-2002
Ref Project
IEC 60874-10:1992/COR1:1996 - Corrigendum 1 - Connectors for optical fibres and cables - Released:5/1/1996IEC 60874-10:1992/COR1:1996 - Corrigendum 1 - Connectors for optical fibres and cables - Released:5/1/1996
PreviousNext
Standard
IEC 60874-10:1992/COR1:1996 - Corrigendum 1 - Connectors for optical fibres and cables - Released:5/1/1996
English and French language
10 pages
sale 15% off
Preview
sale 15% off
Preview

Standards Content (Sample)


Series IEC 874- publications
Publications de la série CEI 874-

Connectors for optical fibres and cables -
Connecteurs pour fibres et câbles optiques -

Parts 1 to 19
Parties 1 à 19
C O R R I G E N D U M 1
Sur la page de couverture, au-dessous du On the cover page, just under the publication
numéro de la publication, et partout ailleurs number, and in the text, where necessary,
dans le texte, si nécessaire, remplacer le replace the existing QC number by the new
numéro QC existant par le nouveau numéro QC number, according to the following list:
QC selon la liste suivante:
Publication de la CEI Nouveau numéro QC IEC publication New QC number
CEI 874-1 . QC 910000 IEC 874-1 . QC 910000
CEI 874-1-1 . QC 910001 à QC 910006 IEC 874-1-1 . QC 910001 to QC 910006
et QC 910099 and QC 910099
CEI 874-2 . QC 910100 IEC 874-2 . QC 910100
CEI 874-3 . QC 910300 IEC 874-3 . QC 910300
CEI 874-4 . QC 910500 IEC 874-4 . QC 910500
CEI 874-5 . QC 910400 IEC 874-5 . QC 910400
CEI 874-6 . QC 910200 IEC 874-6 .
...
