Heat shrinkable moulded shapes - Part 1: Definitions and general requirements

IEC 62329-1:2005 is applicable to heat shrinkable moulded shapes in a range of configurations and materials suitable for insulation, environmental sealing, mechanical protection and strain relief for connector/cable terminations and multi-way transitions. It specifies the design and dimensions, test methods, material requirements and compatibility performance. The most commonly available shapes are as shown in Annex A. Keywords: heat shrinkable moulded shapes

Profilés thermorétractables - Partie 1: Définitions et exigences générales

L'IEC 62329-1:2005 s'applique aux profilés thermorétractables dans une gamme de configurations et de matériaux adaptés à l'isolement, aux éléments d'étanchéité contre les intempéries, à la protection mécanique, aux dispositifs anti-traction pour connecteurs/extrémités de câbles et aux transitions à conducteurs multiples. Elle spécifie la conception et les dimensions, les méthodes d'essai, les exigences sur les matériaux et les caractéristiques de compatibilité. Les profilés les plus courants sont présentés à l'Annexe A. Mots clés: profilés thermorétractables
