1 Scope
Add, at the beginning of the second existing list, the following new item:

– auxiliaries intended to be built into lighting equipment;

Replace the last existing item of the list and the existing note by the following new text:

– apparatus for which the electromagnetic compatibility requirements in the radio-frequency

range are explicitly formulated in other CISPR standards, even if they incorporate a built-
in lighting function.
NOTE 1 Examples of exclusions are:
– built-in lighting devices for display back lighting and signalling;
– range hoods, refrigerators, freezers;
– photocopiers, projectors;
– lighting equipment for road vehicles.

Add, after the fourth existing paragraph of this subclause starting with "Multi-function
equipment.", the following new paragraph and new note:
For equipment outside the scope of this standard and which includes lighting as a secondary
function, there is no need to separately assess the lighting function against this standard,
provided that the lighting function was operative during the assessment in accordance with
the applicable standard.
NOTE 2 Examples of equipment with a secondary lighting function may be range hoods, fans, refrigerators,
freezers, ovens and TV with ambient lighting.

2 Normative references
Add, to the existing list, the following new references:
IEC 60061-1, Lamp caps and holders together with gauges for the control of
interchangeability and safety – Part 1: Lamp caps

IEC 60921:2004, Ballasts for tubular fluorescent lamps – Performance requirements
CISPR 16-2-1:2014, Specification for radio disturbance and immunity measuring apparatus
and methods – Part 2-1: Methods of measurement of disturbances and immunity – Conducted
disturbance measurements
3 Terms and definitions
Add, after the existing definition 3.1, the following new terms and definitions:
3.2
convertor
electrical device to transform the mains voltages, and/or current levels and/or frequency for
light sources
– 4 – CISPR 15:2013/AMD1:2015
© IEC 2015
3.3
base of the luminaire
side opposite of the optical window of the luminaire or mounting surface in normal use

3.4
optical window
side of the lighting equipment from which the light emanates

3.5
ELV
extra-low voltage
voltage which does not exceed 50 V a.c. or 120 V ripple free d.c. between conductors or
between any conductor and earth (voltage band 1 of IEC 60449).
Note 1 to entry: Ripple free is conventionally defined for sinusoidal ripple voltage as ripple content of not more
than 10 % r.m.s.: the maximum peak value does not exceed 140 V for a nominal 120 V ripple-free d.c. system.
[SOURCE: IEC 61347-1:2007/AMD1:2010, 3.27]
3.6
restricted ELV lamp
ELV lamp with specific restrictions on the type of control gear and the cable length that can
be applied to it as provided by the manufacturer
Note 1 to entry: ELV lamps without detailed description of restrictions are non-restricted.
3.7
passive circuit
electronic circuit not containing any active switching electronic components
Note 1 to entry: A passive circuit is not likely to produce any electromagnetic disturbances. E.g. a mains rectifying
diode is considered a passive component.
3.8
secondary function
any function of an equipment not being essential for fulfilling the primary function, defined by
the manufacturer
3.9
primary function
function of an equipment which is defined as such by the manufacturer
3.10
semi luminaire
devices (sometimes called adaptors) equipped, on the one side, with any IEC-standardised
lamp cap system to allow mounting in a standard incandescent lampholder and, on the other
side, with a lampholder to allow the insertion of a replaceable light source with a non-standard
cap
Note 1 to entry: A semi luminaire is to be treated as a self-ballasted lamp with a replaceable light source.

4.1 Frequency ranges
Delete the existing note of this subclause.

© IEC 2015
Table 3b – Radiated disturbance limits in the frequency range 30 MHz to 300 MHz at a

measuring distance of 10 m
Replace the existing table and title by the following new table and title:

Table 3b – Radiated disturbance limits in the frequency

range 30 MHz to 300 MHz at a measuring distance of 3 m or 10 m

Quasi-peak limits
Frequency range
a
dB(µV/m)
MHz
b,c b
3 m 10 m
30 to 230 40 30
230 to 300 47 37
a
At the transition frequency, the lower limit applies.

b
Either of the two measurement distances and the associated limits can be applied to demonstrate
compliance.
c
Care should be taken when measuring a large EUT at 3 m and at frequencies near 30 MHz due to near field
effects.
5.1 General
Replace the second existing paragraph of this subclause by the following new paragraph:
No emission requirements apply to:
• lamps, with the exception of self-ballasted lamps, double-capped self-ballasted lamps and
ELV lamps,
• auxiliaries to be built into lighting equipment (see, however, NOTE 2 of 5.3.1 in this
respect).
5.3.3.3 Independent convertors
Replace the existing text of this subclause by the following new text:
Independent electronic convertors for incandescent lamps or LED light sources shall comply
with the terminal voltage limits given in Tables 2a and 2b; and with the radiated disturbance
limits of Table 3b, and if the light is regulated by an external device with separate control
lines, the disturbance voltage at the control terminals shall comply with the terminal voltage

limits given in Table 2c.
Where the convertor has a non-detachable load supply cable, or where the manufacturer
gives strict installation instructions which define the position, type and maximum length of
cable(s) to be connected to the lamp(s), then (under these conditions) instead of the terminal
voltage limits given in Table 2b, the radiated disturbance limits given in Tables 3a shall be
complied with.
5.3.5 Semi-luminaires
Replace in the first existing paragraph of this subclause “with an Edison screw or bayonet
cap” by “with an IEC 60061-1 standardized lamp cap".

– 6 – CISPR 15:2013/AMD1:2015
© IEC 2015
5.4 Self-ballasted lamps
Replace in the first existing paragraph of this subclause “with Edison screw or bayonet caps”

by “with IEC 60061-1 standardized lamp caps".

Add, at the end of the existing Subclause 5.11, the following new subclauses:

5.12 Rope lights
5.12.1 General
Rope lights (e.g. Christmas lights, lighting chains), are used for different applications both
indoor and outdoor in the areas of general and effect lighting. Depending upon the application
and construction, different light sources may be applied e.g. incandescent lamps or LED
lamps. The control gear for rope lights may be independent or integrated. Also rope lights
without control gear are feasible.
5.12.2 Rope lights without active switching electronic components
Rope lights without active switching electronic components are deemed to comply with the
disturbance requirements of this standard without testing.
5.12.3 Rope lights with active switching electronic components
Rope lights with active switching electronic components shall comply with the disturbance
voltage limits at mains terminals given in Table 2a. Where the operating frequency of the
active switching electronic components exceeds 100 Hz, the EUT shall also comply with the
radiated disturbance limits given in Table 3a and Table 3b.
If the rope light is capable of being used in different operating modes e.g. flashing, running
illumination, colour shifting etc., then measurements shall be performed in the worst case
mode of operation. The worst case shall be found by prescanning every mode of operation
over at least one repetition interval of the specific mode.
5.13 Double-capped lamp adapters, double-capped self-ballasted lamps, double-
capped semi-luminaires and double-capped retrofit lamps
Requirements and test methods for double-capped lamp adapters, double-capped self-
ballasted lamps, double-capped semi-luminaires and double-capped retrofit lamps used in
luminaires for linear fluorescent lamps are specified in Annex E.

5.14 Extra-low voltage lamps
ELV lamps shall comply with one of the following requirements:
a) Extra-low voltage (ELV) lamps without active circuit, as declared by the manufacturer, are
deemed to comply with the requirements of this standard without testing.
b) Extra-low voltage (ELV) lamps with active circuit, intended for connection to symmetrical
ELV networks, shall comply with the mains disturbance voltage limits of Table 2a plus 26
dB at the ELV terminals, measured in accordance with the method specified in 8.11, and
with the radiated disturbance limits of Tables 3a and 3b, measured in accordance with the
method specified in 9.10.
NOTE 1 The insertion loss of the applied control gear is assumed to be 26 dB based on measurements on
real configurations.
NOTE 2 Special care is taken that no overloading of the receiver occurs.
NOTE 3 The 26 dB addition shall not be applied to the assessment of radiated disturbances

© IEC 2015
c) Restricted ELV lamps with active circuit shall comply with the mains disturbance voltage

limits of Table 2a, measured in accordance with the method specified in 8.11, and with the

radiated disturbance limits of Tables 3a and 3b, measured in accordance with the method

specified in 9.10.
NOTE 4 ELV lamps with active circuit are not intended for the connection to unsymmetrical ELV networks.

8.1.1 Mains terminal voltage measurement

Replace the first existing paragraph of this subclause by the following new paragraph:

The disturbance voltage shall be measured at the mains terminals of the lighting equipment
by means of the circuits and arrangements described in Figures 5, 6 and 8 for the relevant
type of equipment.
Replace, in the second existing paragraph of this subclause, "20 %" by "0,05 m".
Add, after the second paragraph of this subclause, the following new paragraph:
In case there is a conflict between the distances indicated in Figure 5 to Figure 11 and the
cable length specified in this paragraph, then the cable length takes precedence.
8.2 Indoor and outdoor luminaires
Replace the first existing paragraph of this subclause by the following new paragraph:
The measuring circuit is given in Figure 6a and the measurement arrangements in Figure 8.
Replace the fifth existing paragraph of this subclause by the following new text:
One of the following three options for the arrangement of the luminaire can be used:
a) The luminaire shall be placed on an insulating table, such that the base of the luminaire
(the opposite side of the optical window) is on the insulating table at 0,4 m from a
horizontal reference ground plane and the light output (optical window) is directed
upwards. See Figure 8a;
b) As a) but rotated 90° around the main axis of the luminaire, the light output directed
horizontally away from the reference ground plane. See Figure 8b;
c) The luminaire shall be placed on an insulating table, such that the base of the luminaire is
on the insulating table at least 0,8 m from the floor. The longest side of the luminaire is

positioned in parallel with a vertical reference ground plane at a distance of 0,4 m. The
light output is directed upwards. See Figure 8c.
For all three arrangements in addition the following applies.
All conductive surfaces other than the reference ground plane shall be separated by at least
0,8 m from the EUT. The reference ground plane shall have dimensions of at least 2 m × 2 m.
The reference ground plane shall be bonded to the reference earth of the artificial V-network
by a low impedance connection (see CISPR 16-2-1). The cables that run from the AMN and
the AAN to the EUT shall be separated 10 cm ± 5 cm except close to the EUT connector.
Delete the sixth existing paragraph starting with "If the measurement is made…".

– 8 – CISPR 15:2013/AMD1:2015
© IEC 2015
8.3.1 Directly operating devices

Replace the first existing sentence of the first paragraph by the following new sentence:

The measuring circuit of the regulating device is given in Figure 5 and the measuring

arrangement is shown in Figure 8.

Replace the second existing paragraph of this subclause by the following new paragraph:

Unless otherwise specified by the manufacturer, the regulating device shall be measured with

one of the following maximum load conditions:

• independent directly operating light regulating devices (e.g. wall dimmers) which are
suitable for incandescent lamps and other types of lighting equipment (e.g. self-ballasted
lamps) shall be tested with incandescent lamps, or
• independent directly operating light regulating devices which are only suitable for lighting
equipment other than incandescent lamps, shall be tested with the appropriate lighting
equipment as provided by the manufacturer.

Add, at the end of the existing Subclause 8.9, the following new subclauses:
8.10 Rope lights
The rope lights (not the mains cord, if applicable) are folded on the insulating support as
depicted in Figure 9. The support consists of a square insulating plate with dimensions
1 250 mm × 1 250 mm and two rows of 24 circular insulating sticks and positioned as shown
in Figure 9. The starting point (mains connection) of the rope is in the middle between the two
rows on the left side of the plate.
The insulating support with the rope lights shall be considered a luminaire and shall be
arranged as specified in 8.1 and 8.2.
8.11 Extra-low voltage lamps
ELV lamps with active circuit shall be tested as follows:
a) ELV lamps with active circuit: The extra-low voltage terminals of the ELV lamp shall be
connected to the AMN. The mains input side of the AMN is connected to the output of a
suitable power supply. See Figure 10.
b) Restricted ELV lamps with active circuit: The ELV lamp shall be connected to the power

supply of the same model/type as specified by the manufacturer. The combination shall be
measured using the arrangement as shown in Figure 11.
In both cases, the ELV lamp is mounted in a conical metal housing as described in Figure 7.

Add, at the end of the existing Subclause 9.8, the following new subclauses:
9.9 Rope lights
Rope lights are arranged on the insulating support as specified in 8.10 and Figure 9.
The insulating support with the rope lights shall be considered a luminaire and shall be
arranged as specified in 9.1 and 9.2 or Annex B.

© IEC 2015
9.10 Extra-low voltage lamps
Radiated disturbance measurements of an ELV lamp (if applicable; see 5.14) shall be

performed in accordance with 9.1, 9.2 and 9.6. However the lamp shall not be mounted in a

conical metal housing.
For any assessment method of the radiated disturbances, the following applies:

• for ELV lamps, only the lamp shall be assessed;

• for restricted ELV lamps, both the lamp and the specific power source shall be assessed.

11 Measurement uncertainty
Replace the existing text of this clause by the following new text:
Where guidance for the calculation of the instrumentation uncertainty of a measurement is
specified in CISPR 16-4-2 this shall be followed, and for these measurements the
determination of compliance with the limits in this standard shall take into consideration the
measurement instrumentation uncertainty in accordance with CISPR 16-4-2. Calculations to
determine the measurement result and any adjustment of the test result required when the
test laboratory uncertainty is larger than the value for U given in CISPR 16-4-2 shall be
CISPR
included in the test report.
– 10 – CISPR 15:2013/AMD1:2015

© IEC 2015
Figure 5 – Measuring arrangements for an independent light regulating device,
transformer or convertor
Replace the existing figure, including the key and the title as follows:

Dimensions in centimetres
to M
20 ±5
AAN
CT
RC
LT
10 ±5
10 ±5
10 ±5
IDUT
Load
AMN
MS
MT
Cable length 80 ±5
to M
P
d
c
to M
E
b
Two terminal devices
a
AAN
IDUT
AMN
Load
IEC
Key
MS Mains supply
AMN 50 Ω/50 µH + 5 Ω (or 50 Ω/50 µH) artificial mains V-network as specified in CISPR 16-1-2
AAN Asymmetric artificial network

M  CISPR measuring receiver (replaced by 50 Ω if not connected)
MT Mains terminals   IDUT Independent device under test
LT Load terminals   CT Control terminals
P Probe (R ≥ 1 500 Ω and C ≥ 0,005 µF)  RC Remote control (if any)
a – b Supply terminals c – d Control terminals
E Earth terminal
The earth of the measuring receiver shall be connected to the artificial mains V-network.
For load terminal voltage measurement the length of the coaxial cable between the probe and the measuring
receiver shall not exceed 2 m.
Where a two-terminal device is inserted in only one lead of the supply, measurements shall be made by connecting
the second supply lead as indicated in the lower figure.
See Figure 8 for details on the arrangement.
Figure 5 – Measuring circuits for an independent
light regulating device, transformer or convertor

© IEC 2015
Figure 6 – Measuring arrangements for measuring a luminaire (Figure 6a), an
independent ballast (Figure 6b) and a self-ballasted lamp (Figure 6c)

Replace the existing figure, including the key and the title as follows:

Dimensions in centimetres
d
c
E
to M b
a
20 ±5
AAN
10 ±5
RC
10 ±5
Figure 6a
AMN
MS
DUT = Luminaire
Cable length 80 ±5
to M
Figure 6b
DUT
IP
DUT = Independent electronic control gear
Figure 6c
DUT = Self ballasted lamp
(measured inside the
conical housing)
IEC
Key
AMN 50 Ω/50 µH + 5 Ω (or 50 Ω/50 µH) artificial mains V-network as specified in CISPR 16-1-2
AAN Asymmetric artificial network
MS Mains supply M Measuring receiver

RC Remote light control C Conical metal housing
IP Piece of insulating material
a – b Supply terminals c – d Control terminals
E Earth terminal
See Figure 8 for details on the arrangement.
For cable lengths of the mains terminals refer to 8.1.1.
Figure 6 – Measuring circuits for measuring a luminaire (Figure 6a),
an independent ballast (Figure 6b) and a self-ballasted lamp (Figure 6c)

– 12 – CISPR 15:2013/AMD1:2015

© IEC 2015
Add, after the existing Figure 7, the following new figures:

Dimensions in centimetres
AAN
EUT
≥ 80
EUT
AMN
Cable length 80
RGP RGP
Top view Side view (of EUT only)
IEC
Figure 8a – Horizontal RGP setup (option 1)
Dimensions in centimetres
RGP
RGP
EUT
AAN
AMN
EUT
Cable length 80
Top view Side view (of EUT only)
IEC
Figure 8b – Vertical RGP setup (option 2)
Dimensions in centimetres
RGP RGP
EUT
AAN
AMN
EUT
Cable length 80
Top view Side view (of EUT only)
IEC
Figure 8c – Vertical RGP setup (option 3)
Figure 8 – Measuring arrangements for conducted disturbances
≥ 80
≥ 80
© IEC 2015
Dimensions in millimetres
24 insulating cable supports with a diameter of 20

Insulating plate
24 insulating cable supports with a diameter of 20
1 250
IEC
NOTE All dimensions have a 5 % tolerance.
Figure 9 – Detail of the support plate for the rope lights

Direction of rope light
1 250
– 14 – CISPR 15:2013/AMD1:2015

© IEC 2015
TOP VIEW
Arrangement to be located 0,4 m above the RGP by applying a non-conductive table

M
26 dB attenuator
Lamp
ELV
under Test
Mains Cable length 0,8 m
L L
PS
AMN
N
N
PE
PE
Flexible, unshielded
Metal Cone ( see
three core cable
Figure 7 ); optical
Electrical bonding to RGP
window directed
away from the RGP
Reference ground plane (RGP)
IEC
NOTE This arrangement shows a top view and applies a horizontal reference ground plane. The same setup can
also be applied at a distance of 40 cm aside of a vertical reference ground plane (see CISPR 16-2-1 and Clause 8
and Figure 8 of this standard for details of the arrangement).
Key
PS  Power Supply (Appropriate power supply e.g. magnetic transformer or universal power supply)
L Line
N Neutral
PE Protective earth
AMN Artificial mains network
ELV Extra low voltage
M CISPR measuring receiver
Figure 10 – Measuring arrangements for ELV lamps (see 8.11)

© IEC 2015
TOP VIEW
Arrangement to be located 0,4 m above the RGP by applying a non- conductive table

M
Lamp
Cable length
under Test
0,1 m
0,8 m
Mains
L
L
PS
AMN
N AMN
N
PE
PE
ELV
Metal Cone ( see
Flexible, unshielded
Electrical bonding to RGP
Figure 7); optical
cable
window directed
away from the RGP
Reference ground plane (RGP)
IEC
NOTE 1 This arrangement shows a top view and applies a horizontal reference ground plane. The same setup
can also be applied at a distance of 40 cm aside of a vertical reference ground plane (see CISPR 16-2-1 and
Clause 8 and Figure 8 of this standard for details of the arrangement).
NOTE 2 The distances in the figure are geometrical distances between devices. The cable length involved should
be minimized.
Key
PS Appropriate power supply specified by the manufacturer
L Line
N Neutral
PE Protective Earth
AMN Artificial Mains Network
ELV Extra Low Voltage
M CISPR measuring receiver
Figure 11 – Measuring arrangements for restricted ELV lamps (see 8.11)

– 16 – CISPR 15:2013/AMD1:2015
© IEC 2015
Table D.1 – Application of measurement methods and limits to lamps (references to Tables or Subclauses)
Add, below the existing line "Self-ballasted lamp" of this table the following new lines:
Lamps without active
n.a.
circuit
Table 2a
Lamps with active
plus
circuit, intended for
26 dB
connection to n.a.  8.11   Table 3a 9.10 Table 3b 9.10
(apply at
ELV lamps
symmetrical ELV
the ELV
networks terminal of
the lamp)
Table 2a
(apply at
Restricted ELV
the mains
lamps with active n.a.  terminal of 8.11   Table 3a 9.10 Table 3b 9.10
the specific
circuit
power
source)
Table D.2 – Application of measurement methods and limits to luminaires (references to Tables or Subclauses)
Add, below the existing line "Transport lighting" of this table the following new lines:
Without active electronic
n.a.
components
Electronic components with
Rope lights n.a.  Table 2a 8.10
switching frequency ≤ 100 Hz
Electronic components with
n.a.  Table 2a 8.10   Table 3a 9.1, 9.9 Table 3b 9.9
switching frequency > 100 Hz
© IEC 2015
Table D.3 – Application of measurement methods and limits to independent auxiliaries exclusively
for use with lighting equipment (references to Tables or Subclauses)
Add, below the existing line "Semi-luminaires (adapters)" of this table the following new lines:
Without active switching electronic
n.a.
components
Double capped
8.1.1,
lamp adapters Electronic components with
Table 2a 8.1.4,
n.a.
and semi- switching frequency ≤ 100 Hz
8.2
luminaires (see
5.13)
8.1.1,
Electronic components with
n.a.  Table 2a 8.1.4,   Table 3a 9.1 Table 3b 9.2
switching frequency > 100 Hz
8.2
– 18 – CISPR 15:2013/AMD1:2015

© IEC 2015
Add, at the end of the existing Annex D, the following new annex:

Annex E
(normative)
Requirements and test arrangements for double-capped lamp adapters,

double-capped self-ballasted lamps, double-capped semi-luminaires and

double-capped retrofit lamps used in linear fluorescent lamp luminaires

E.1 Overview
This annex applies to the emission (radiated and conducted) of radiofrequency disturbances
from double-capped lamp adapters, double-capped self-ballasted lamps, double-capped semi-
luminaires and double-capped retrofit lamps used in luminaires with magnetic control gear for
linear fluorescent lamps. The existing magnetic lamp control gear is short-circuited if specified
by the manufacturer.
This Annex does not cover double-capped lamp adapters, double-capped self-ballasted
lamps, double-capped semi-luminaires and double-capped retrofit lamps for application in
luminaires with electronic control gear in operation. For such applications, the requirements
are to be verified using a host luminaire compliant with this standard.
E.2 Reference documents
The following documents, in whole or in part, are normatively referenced in this document and
are indispensable for its application. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any
amendments) applies.
IEC 60081, Double-capped fluorescent lamps – Performance specifications
IEC 60155, Glow-starters for fluorescent lamps
IEC 61195, Double-capped fluorescent lamps – Safety specifications
E.3 Terms and definitions
The terms and definitions given in Clause 3 apply together with the following:

E.3.1
double-capped lamp adapter
component used to be installed into luminaires which are constructed for lamps of one tube
diameter (according IEC 60081 and IEC 61195) and to receive lamps of another tube
diameter or another tube length instead
Note 1 to entry: A lamp adaptor may incorporate a switch or a fuse or a electronic lamp control gear for HF lamp
operation.
E.3.2
double-capped self-ballasted lamp
unit which cannot be dismantled without being permanently damaged, provided with one or
more light sources and two lamp caps and any additional elements necessary for starting and
stable operation
© IEC 2015
E.3.3
double-capped semi-luminaire
unit similar to a self-ballasted lamp but designed to utilize a replaceable light source and/or

starting device
Note 1 to entry: Semi-luminaires for compact fluorescent lamps and for incandescent lamps, sometimes called
adaptors, are devices equipped, on the one side, with an Edison screw or an bayonet or similar cap to allow
mounting in a standard incandescent lampholder and, on the other side, with a lampholder to allow the insertion of

a replaceable light source.
Note 2 to entry: The light source component and/or starting device of a semi luminaire is readily replaceable.

Note 3 to entry: The ballast component is not replaceable and is not disposed of each time a light source is

replaced.
Note 4 to entry: A lampholder is required for a supply connection.
E.3.4
double-capped retrofit lamp
double-capped lamp which can be used as a replacement of another type of lamp without
requiring any modification in the luminaire and which, after installation, maintain the same
level of safety of the replaced lamp in the luminaire.
Note 1 to entry: The replacement of the glow starter according to IEC 60155 with other devices for the correct
functioning of the retrofit lamp is not considered as modification in the luminaire.
E.4 Limits
The limits are given in Clause 4.
E.5 Application of the limits and the measurement set-up
Double-capped lamp adapter, double-capped self-ballasted lamp, double-capped semi-
luminaire and double-capped retrofit lamp shall be measured with the test set-up described in
Figure E.1. The height of the lamp holders shall be such that the distance between the
exterior of the lamp and the metal plate is 9 mm ± 1 mm for lamps having a nominal tube
diameter lower or equal to 25 mm and 20 mm ± 1 mm for lamps having a nominal tube
diameter greater than 25 mm. The units under test (EUT) shall be measured as manufactured.
For double-capped lamp adapter and double-capped semi-luminaire suitable lamps having the
maximum power allowed for it shall be used.
The measurement set-up of Figure E.1 shall be used for both the measurement of the
disturbance voltages described in Clause 8 and for the measurement of the radiated
electromagnetic disturbances described in Clause 9.

If the EUT contains active switching electronic components it shall comply with the terminal
voltage limits given in Table 2a, else no requirements apply.
Where the operating frequency of the active switching electronic components exceeds
100 Hz, the EUT shall also comply with the radiated disturbance limits given in Tables 3a and
3b.
Tests in the frequency range 30 MHz to 300 MHz shall be conducted by the test specified in
Annex B with the limits of Table B.1.

– 20 – CISPR 15:2013/AMD1:2015

© IEC 2015
Dimensions in millimeters
Isolating material
Metal plate
Lamp holder
DUT
Reflector fixing screw
(at least 4 screws)
“Z”
Movable reflector
(unsheathed aluminum)
Starter holder: apply starter as
supplied by the manufacturer,
or short circuit
Magnetic Control Gear
(MCG) or short circuit
Typical Connector
“Z”:
d
h = 9 ±1 for d ≤ 25, or
h = 20 ±1 for d > 25
movable reflector
IEC
Figure E.1 – Measurement set-up for double-capped lamp adapter, double-capped self-
ballasted lamp, double-capped semi-luminaire and double-capped retrofit lamp

h
a
L = a + 180
Neutral
Line
Ground
© IEC 2015
The measurement set-up of Figure E.1 shall be used. If the use of a magnetic control gear is

required by the manufacturer, the magnetic control gear shall fulfil IEC 60921 and the

parasitic capacity between line and earth shall be less than 2 nF, and measured at or below

1 kHz. The magnetic lamp control gear in the measurement set-up of Figure E.1 shall be hot-

wired if the use of the magnetic control gear is not required by the manufacturer. The cable

connecting the terminals at the measurement board to the V-network shall comply with the

requirements given in 8.1.1. The measurement board shall be connected to the earth terminal
of the V-network.
E.6 Operating conditions for the EUT

The requirements of Clause 6 of this standard apply.
E.7 Interpretation of CISPR radio disturbance limits
The requirements of Clause 10 of this standard apply.
E.8 Measurement uncertainty
The requirements of Clause 11 of this standard apply.

– 22 – CISPR 15:2013/AMD1:2015

© IEC 2015
Bibliography
Remove, from the existing list, the existing reference to CISPR 16-2-1.

Add, to the existing list, the following new references:

[2] IEC 60449, Voltage bands for electrical installations of buildings

[3] IEC 61347-1:2007, Lamp controlgear – Part 1: General and safety requirements
IEC 61347-1:2007/AMD1:2010
IEC 61347-1:2007/AMD2:2012
_____________
– 24 – CISPR 15:2013/AMD1:2015

© IEC 2015
AVANT-PROPOS
Cet amendement a été établi par le sous-comité CISPR F: Perturbations relatives aux

appareils domestiques, aux outils, aux appareils d'éclairage et aux appareils analogues.

Le texte de cet amendement est issu des documents suivants:

FDIS Rapport de vote
CIS/F/654/FDIS CIS/F/660/RVD
Le rapport de vote indiqué dans le tableau ci-dessus donne toute information sur le vote ayant
abouti à l'approbation de cet amendement.
Le comité a décidé que le contenu de cet amendement et de la publication de base ne sera
pas modifié avant la date de stabilité indiquée sur le site web de l'IEC sous
"http://webstore.iec.ch" dans les données relatives à la publication recherchée. A cette date,
la publication sera
• reconduite,
• supprimée,
• remplacée par une édition révisée, ou
• amendée.
IMPORTANT – Le logo "colour inside" qui se trouve sur la page de couverture de cette
publication indique qu'elle contient des couleurs qui sont considérées comme utiles à
une bonne compréhension de son contenu. Les utilisateurs devraient, par conséquent,
imprimer cette publication en utilisant une imprimante couleur.

_____________
© IEC 2015
1 Domaine d'application
Ajouter, au début de la deuxième liste existante, le nouveau point suivant:

– auxiliaires destinés à être construits en équipement d'éclairage;

Remplacer le dernier tiret existant de la liste et la note existante par le nouveau texte suivant:

– appareils pour lesquels les exigences relatives à la compatibilité électromagnétique dans

la gamme des radiofréquences sont formulées de manière explicite dans d'autres normes
CISPR, même s'ils intègrent une fonction d'éclairage intégrée.
NOTE 1 À titre d'exemples d'exclusions on peut citer:
– dispositifs à éclairage intégré pour le rétroéclairage et la signalisation;
– hottes de cuisine, réfrigérateurs, congélateurs;
– photocopieurs, projecteurs;
– équipement d'éclairage des véhicules routiers.

Ajouter, après le quatrième alinéa existant de cet article commençant par "Les appareils à
fonctions multiples…", le nouvel alinéa et la nouvelle note suivants:
Pour les équipements en dehors du domaine d'application de la présente norme et qui
incluent l'éclairage comme fonction secondaire, il n'est pas nécessaire d'évaluer séparément
la fonction d'éclairage par rapport à la présente norme, à condition que la fonction d'éclairage
soit opérationnelle lors de l'évaluation conformément à la norme applicable.
NOTE 2 Les exemples d'équipements dotés d'une fonction d'éclairage secondaire peuvent être des hottes de
cuisine, des ventilateurs, des réfrigérateurs, des congélateurs, des fours et des télévisions dotées d'un éclairage
ambiant.
2 Références normatives
Ajouter, à la liste existante, les nouvelle références suivantes:
IEC 60061-1, Culots de lampes et douilles ainsi que calibres pour le contrôle de
l'interchangeabilité et de la sécurité – Partie 1: Culots de lampes

IEC 60921:2004, Ballasts pour lampes tubulaires à fluorescence – Exigences de
performances
CISPR 16-2-1:2014, Spécifications des méthodes et des appareils de mesure des
perturbations radioélectriques et de l'immunité aux perturbations radioélectriques – Partie 2-1:
Méthodes de mesure des perturbations et de l'immunité – Mesures
des perturbations conduites
3 Termes et définitions
Ajouter, après la définition 3.1 existante, les nouveaux termes et définitions suivants:

– 26 – CISPR 15:2013/AMD1:2015

© IEC 2015
3.2
convertisseur
dispositif électrique destiné à transformer les tensions d'alimentation et/ou les niveaux de

courant et/ou la fréquence pour les sources lumineuses

3.3
base du luminaire
côté opposé de la fenêtre optique du luminaire ou surface de montage lors d'une utilisation

normale
3.4
fenêtre optique
côté de l'équipement lumineux duquel émane la lumière
3.5
TBT
très basse tension
tension ne dépassant pas 50 V en courant alternatif ou 1
...
