EN 60317-0-2:2014

SLOVENSKI STANDARD
01-marec-2014
1DGRPHãþD
SIST EN 60317-0-2:2001
SIST EN 60317-0-2:2001/A1:2001
SIST EN 60317-0-2:2001/A2:2005
Specifikacije za posebne vrste navijalnih žic - 0-2. del: Splošne zahteve - Emajliran
bakren vodnik s pravokotnim prerezom (IEC 60317-0-2:2013)
Specifications for particular types of winding wires - Part 0-2: General requirements -
Enamelled rectangular copper wire
Technische Lieferbedingungen für bestimmte Typen von Wickeldrähten - Teil 0-2:
Allgemeine Anforderungen - Flachdrähte aus Kupfer, lackisoliert
Spécifications pour types particuliers de fils de bobinage - Partie 0-2: Prescriptions
générales - Fil de section rectangulaire en cuivre émaillé
Ta slovenski standard je istoveten z: EN 60317-0-2:2014
ICS:
29.060.10 Žice Wires
77.150.30 Bakreni izdelki Copper products
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

EUROPEAN STANDARD
EN 60317-0-2
NORME EUROPÉENNE
January 2014
EUROPÄISCHE NORM
ICS 29.060.10 Supersedes EN 60317-0-2:1998 + A1:2000 + A2:2005

English version
Specifications for particular types of winding wires -
Part 0-2: General requirements -
Enamelled rectangular copper wire
(IEC 60317-0-2:2013)
Spécifications pour types particuliers de Technische Lieferbedingungen für
fils de bobinage - bestimmte Typen von Wickeldrähten -
Partie 0-2: Exigences générales - Teil 0-2: Allgemeine Anforderungen -
Fil de section rectangulaire en cuivre Lackisolierte Flachdrähte aus Kupfer
émaillé (IEC 60317-0-2:2013)
(CEI 60317-0-2:2013)
This European Standard was approved by CENELEC on 2013-11-11. CENELEC members are bound to comply
with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard
the status of a national standard without any alteration.

Up-to-date lists and bibliographical references concerning such national standards may be obtained on
application to the CEN-CENELEC Management Centre or to any CENELEC member.

This European Standard exists in three official versions (English, French, German). A version in any other
language made by translation under the responsibility of a CENELEC member into its own language and notified
to the CEN-CENELEC Management Centre has the same status as the official versions.

CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus,
the Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany,
Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the Netherlands, Norway, Poland,
Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and the United Kingdom.

CENELEC
European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung

CEN-CENELEC Management Centre: Avenue Marnix 17, B - 1000 Brussels

© 2014 CENELEC - All rights of exploitation in any form and by any means reserved worldwide for CENELEC members.
Ref. No. EN 60317-0-2:2014 E
Foreword
The text of document 55/1410/FDIS, future edition 3 of IEC 60317-0-2, prepared by IEC/TC 55
"Winding wires" was submitted to the IEC-CENELEC parallel vote and approved by CENELEC as
The following dates are fixed:
(dop) 2014-08-11
• latest date by which the document has to be
implemented at national level by
publication of an identical national
standard or by endorsement
• latest date by which the national (dow) 2016-11-11
standards conflicting with the
document have to be withdrawn
This document supersedes EN 60317-0-2:1998.

EN 60317-0-2:1998:
– addition of 3.2.2, transferring general winding wire requirements from the scope;
– correction to Table 7 units;
– change to Clause 15 requirements with a simple reference to EN 60172;
– deletion of Annex E.
This standard is to be read in conjunction with the EN 60851 series. The clause numbers used in this
part of EN 60317 are identical with the respective test numbers of EN 60851 series.

In case of inconsistencies between EN 60851 and this part of EN 60317, the latter prevails.

The numbering of clauses in this standard is not continuous from Clauses 21 and 30 in order to
reserve space for possible future wire requirements prior to those for wire packaging.

Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CENELEC [and/or CEN] shall not be held responsible for identifying any or all such
patent rights.
Endorsement notice
The text of the International Standard IEC 60317-0-2:2013 was approved by CENELEC as a
European Standard without any modification.
In the official version, for Bibliography, the following notes have to be added for the standards indicated:

IEC 60264 Series NOTE Harmonized as EN 60264 Series (not modified).
IEC 60317 Series NOTE Harmonized as EN 60317 Series (not modified).

- 3 - EN 60317-0-2:2014
Annex ZA
(normative)
Normative references to international publications
with their corresponding European publications

The following documents, in whole or in part, are normatively referenced in this document and are
indispensable for its application. For dated references, only the edition cited applies. For undated
references, the latest edition of the referenced document (including any amendments) applies.

NOTE  When an international publication has been modified by common modifications, indicated by (mod), the relevant EN/HD
applies.
Publication Year Title EN/HD Year

IEC 60172 - Test procedure for the determination of the EN 60172 -
temperature index of enamelled winding
wires
IEC 60851 Series Winding wires - Test methods EN 60851 Series

ISO 3 - Preferred numbers - Series of preferred - -
numbers
IEC 60317-0-2 ®
Edition 3.0 2013-10
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
Specifications for particular types of winding wires –

Part 0-2: General requirements – Enamelled rectangular copper wire

Spécifications pour types particuliers de fils de bobinage –

Partie 0-2: Exigences générales – Fil de section rectangulaire en cuivre émaillé

INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
COMMISSION
ELECTROTECHNIQUE
PRICE CODE
INTERNATIONALE
CODE PRIX T
ICS 29.060.10 ISBN 978-2-8322-1149-6

– 2 – 60317-0-2 © IEC:2013
CONTENTS
FOREWORD . 4
INTRODUCTION . 6
1 Scope . 7
2 Normative references . 7
3 Terms, definitions, general notes and appearance . 7
3.1 Terms and definitions . 7
3.2 General notes . 8
3.2.1 Methods of test . 8
3.2.2 Winding wire . 9
3.3 Appearance . 9
4 Dimensions . 9
4.1 Conductor dimensions . 9
4.2 Tolerance on conductor dimensions . 9
4.3 Rounding of corners . 10
4.4 Increase in dimensions due to the insulation . 12
4.5 Overall dimensions . 12
4.5.1 Nominal overall dimensions. 12
4.5.2 Minimum overall dimensions . 12
4.5.3 Maximum overall dimensions . 12
5 Electrical resistance . 13
6 Elongation . 13
7 Springiness . 13
8 Flexibility and adherence . 13
8.1 Mandrel winding test . 13
8.2 Adherence test . 13
9 Heat shock . 14
10 Cut-through . 14
11 Resistance to abrasion . 14
12 Resistance to solvents . 14
13 Breakdown voltage . 14
14 Continuity of insulation . 14
15 Temperature index . 14
16 Resistance to refrigerants . 15
17 Solderability . 15
18 Heat or solvent bonding . 15
19 Dielectric dissipation factor . 15
20 Resistance to transformer oil . 15
21 Loss of mass . 15
23 Pin hole test . 15
30 Packaging. 15
Annex A (informative) Nominal cross-sectional areas for preferred and intermediate
sizes . 17
Bibliography . 25

60317-0-2 © IEC:2013 – 3 –
Table 1 – Conductor tolerances . 10
Table 2 – Nominal cross-sectional areas of preferred sizes. 11
Table 3 – Corner radii . 12
Table 4 – Increases in dimensions. 12
Table 5 – Elongation . 13
Table 6 – Mandrel winding . 13
Table 7 – Breakdown voltage . 14
Table A.1 – Nominal cross-sectional areas (1 of 7) . 17
Table B.1 – Tolerances for calculating special maximum and minimum dimensions of
grade 2 rectangular wire . 24

– 4 – 60317-0-2 © IEC:2013
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
SPECIFICATIONS FOR PARTICULAR
TYPES OF WINDING WIRES –
Part 0-2: General requirements –
Enamelled rectangular copper wire

FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
in the subject dealt with may participate in this preparatory work. International, governmental and non-
governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
with the International Organization for Standardization (ISO) in accordance with conditions determined by
agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence
between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
the latter.
5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity
assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any
services carried out by independent certification bodies.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of
patent rights. IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 60317-0-2 has been prepared by IEC technical committee 55:
Winding wires.
This third edition cancels and replaces the second edition published in 1997,
Amendment 1:1999 and Amendment 2:2005. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous
edition:
– addition of 3.2.2, transferring general winding wire requirements from the scope;
– correction to Table 7 units;
– change to Clause 15 requirements with a simple reference to IEC 60172;
– deletion of Annex E.
60317-0-2 © IEC:2013 – 5 –
The text of this standard is based on the following documents:
FDIS Report on voting
55/1410/FDIS 55/1431/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 2.
This International standard is to be read in conjunction with the IEC 60851 series. The clause
numbers used in this part of IEC 60317 are identical with the respective test numbers of
IEC 60851 series.
In case of inconsistencies between IEC 60851 and this part of IEC 60317, the latter prevails.
The numbering of clauses in this standard is not continuous from Clauses 21 and 30 in order to
reserve space for possible future wire requirements prior to those for wire packaging.
A list of all parts in the IEC 60317 series, published under the general title Specifications for
particular types of winding wires, can be found on the IEC website.
The committee has decided that the contents of this publication will remain unchanged until the
stability date indicated on the IEC web site under "http://webstore.iec.ch" in the data related to
the specific publication. At this date, the publication will be
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.
– 6 – 60317-0-2 © IEC:2013
INTRODUCTION
This part of IEC 60317 is one of a series which deals with insulated wires used for windings in
electrical equipment. The series has three groups describing:
1) Winding wires – Test methods (IEC 60851);
2) Specifications for particular types of winding wires (IEC 60317);
3) Packaging of winding wires (IEC 60264).

60317-0-2 © IEC:2013 – 7 –
SPECIFICATIONS FOR PARTICULAR
TYPES OF WINDING WIRES –
Part 0-2: General requirements –
Enamelled rectangular copper wire

1 Scope
This part of IEC 60317 specifies the general requirements of enamelled rectangular copper
winding wires.
The range of nominal conductor dimensions is given in the relevant specification sheet.
2 Normative references
The following documents, in whole or in part, are normatively referenced in this document and
are indispensable for its application. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments)
applies.
IEC 60172, Test procedure for the determination of the temperature index of enamelled winding
wires
IEC 60851 (all parts), Winding wires – Test methods
ISO 3, Preferred numbers – Series of preferred numbers
3 Terms, definitions, general notes and appearance
3.1 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
3.1.1
class
thermal performance of a wire expressed by the temperature index and the heat shock
temperature
3.1.2
coating
material which is deposited on a conductor or wire by a suitable means and then dried and/or
cured
3.1.3
conductor
bare metal after removal of the insulation
3.1.4
crack
opening in the insulation which exposes the conductor to view at the stated magnification

– 8 – 60317-0-2 © IEC:2013
3.1.5
dual coating
insulation composed of two different materials, an underlying and a superimposed coating
3.1.6
enamelled wire
wire coated with an insulation of cured resin
3.1.7
grade
range of thickness of the insulation of a wire
3.1.8
insulation
coating or covering on the conductor with the specific function of withstanding voltage
3.1.9
nominal conductor dimension
designation of the conductor size in accordance with the IEC 60317 series
3.1.10
normal vision
20/20 vision, with corrective lenses, if necessary
3.1.11
winding wire
wire used for winding a coil to provide a magnetic field
3.1.12
wire
conductor coated or covered with an insulation
3.2 General notes
3.2.1 Methods of test
All methods of test to be used for this standard are given in IEC 60851.
The clause numbers used in this standard are identical to the corresponding test numbers in
the IEC 60851 series of standards.
In case of inconsistencies between the publication on methods of test and this standard,
IEC 60317-0-2 shall prevail.
Where no specific range of nominal conductor dimensions is given for a test, the test applies to
all nominal conductor dimensions covered by the specification sheet.
Unless otherwise specified, all tests shall be carried out at a temperature from 15 °C to 35 °C
and a relative humidity from 45 % to 75 %. Before measurements are made, the specimens
shall be preconditioned under these atmospheric conditions for a time sufficient to allow the
specimens to reach stability.
The wire to be tested shall be removed from the packaging in such a way that the wire will not
be subjected to tension or unnecessary bends. Before each test, sufficient wire should be
discarded to ensure that any damaged wire is not included in the test specimens.

60317-0-2 © IEC:2013 – 9 –
3.2.2 Winding wire
When reference is made to a winding wire according to a standard of the IEC 60317 series
mentioned under Clause 2, the following information is given in the description:
– reference to IEC specification;
– nominal conductor dimensions in millimetres (width × thickness);
– grade.
EXAMPLE: IEC 60317-17 – 4,00 × 1,00 Grade 1
...
