Resistance welding - Destructive tests of welds - Pressure test of resistance seam welds (ISO 17654:2011)

ISO 27654:2011 specifies the pressure test method to be applied to resistance-seam-welded specimens of different types of materials with single sheet thicknesses ranging from 0,3 mm to 3,2 mm.
The purpose of this pressure test is to determine the suitability of the material, welding equipment, welding parameters and of other factors on a tank, a vessel or a container for liquids or gases, which are manufactured by resistance seam welding.

Widerstandsschweißen - Zerstörende Prüfungen von Schweißverbindungen - Druckprüfung an Widerstandsrollennahtschweißverbindungen (ISO 17654:2011)

Diese Internationale Norm legt die Druckprüfung von rollennahtgeschweißten Proben aus verschiedenen
Werkstoffen mit Einzelblechdicken im Bereich von 0,3 mm bis 3,2 mm fest.
Der Zweck dieser Druckprüfung ist das Bestimmen der Eignung des Werkstoffes, der Schweißeinrichtung, der
Schweißparameter und anderer Faktoren an einem Tank, einem Kessel oder einem Behälter für Flüssigkeiten
oder Gase, die durch Widerstandsrollennahtschweißen hergestellt werden.

Soudage par résistance - Essais destructifs des soudures - Essai de pression des soudures par résistance à la molette(ISO 17654:2011)

L'ISO 17654:2011 spécifie la méthode d'essai sous pression à appliquer à des éprouvettes soudées par résistance à la molette constituées de différents types de matériaux, sous forme de tôles minces, d'épaisseur comprise entre 0,3 mm et 3,2 mm.
L'objet de cet essai sous pression est de déterminer la compatibilité du matériau, du matériel de soudage, des paramètres de soudage et d'autres facteurs vis-à-vis d'un réservoir, d'un récipient ou d'un conteneur destinés à recevoir des liquides ou des gaz, fabriqués par soudage par résistance à la molette.

Uporovno varjenje - Porušitveni preskusi zvarov - Tlačni preskus uporovnih kolutnih zvarov (ISO 17654:2011)

Ta mednarodni standard določa metodo tlačnega preskusa, ki se uporablja na vzorcih uporovnih kolutnih zvarov raznovrstnih materialov z debelino ene plošče med 0,3 mm in 3,2 mm. Namen tega tlačnega preskusa je določiti ustreznost materiala, opreme za varjenje, parametrov varjenja in drugih dejavnikov na cisterni, posodi ali vsebniku za tekočine in pline, narejenih z uporovnim kolutnim varjenjem.

General Information

Status
Published
Publication Date
14-Sep-2011
Withdrawal Date
30-Mar-2012
ICS
25.160.40 - Welded joints and welds
Technical Committee
CEN/TC 121 - Welding
Drafting Committee
CEN/TC 121/WG 21 - Testing of welds
Current Stage
6060 - Definitive text made available (DAV) - Publishing
Start Date
15-Sep-2011
Completion Date
15-Sep-2011
Ref Project
SIST EN ISO 17654:2011 - Resistance welding - Destructive tests of welds - Pressure test of resistance seam welds (ISO 17654:2011)

Relations

Replaces
EN ISO 17654:2003 - Destructive tests on welds in metallic materials - Resistance welding - Pressure test on resistance seam welds (ISO 17654:2003)
Effective Date
08-Jun-2022

Overview

EN ISO 17654:2011 is an international standard developed by the International Organization for Standardization (ISO) and adopted by the European Committee for Standardization (CEN). It specifies a pressure test method for evaluating resistance-seam-welded specimens. The standard applies to single sheet thicknesses ranging from 0.3 mm to 3.2 mm and is essential for assessing the integrity of welds in tanks, vessels, or containers designed to hold liquids or gases.

This destructive pressure test ensures the suitability of materials, welding equipment, and welding parameters used in resistance seam welding processes. EN ISO 17654:2011 supersedes the previous 2003 edition and is fundamental for quality control and compliance in manufacturing sectors relying on resistance welding techniques.

Key Topics

  • Scope and Purpose
    The standard defines a pressure test for seam weld specimens to verify the strength and leak-tightness of welded joints, crucial for components under pressure such as tanks and containers.

  • Test Specimens
    Specimens must be prepared from the same materials and under similar conditions as actual production components, using identical welding equipment and parameters.
    Two specimen types are described:

    • Type A: Specimen with four seams
    • Type B: Specimen with one seam
      Dimensions and edge distances are regulated for test consistency.

  • Test Procedure
    The pressure test is conducted by applying compressed air or water to the welded specimen mounted in a restraining fixture that limits expansion during testing. Leakage detection is performed visually for bubble presence. Test pressure can be set at 0.15 MPa or pressure causing 20 mm deformation, depending on the product specification.
    Higher pressure tests require safety precautions, including performing the test in air with internal water pressure.

  • Test Reporting
    Comprehensive test reports must include:

    • Standard reference
    • Material properties and sheet thickness
    • Welding process details and parameters
    • Weld dimensions and test conditions
    • Results and any deviations from the standard

Applications

EN ISO 17654:2011 is widely used in industries where pressure-retaining welded assemblies are critical, including:

  • Manufacture of pressure vessels, tanks, and containers for liquids and gases
  • Automotive and aerospace sectors, where resistance seam welding is common for structural components
  • Pipeline and fluid handling systems, requiring leak-proof welded joints
  • Industrial equipment fabrication where weld integrity ensures safety and longevity

By following this pressure test method, manufacturers can validate welding quality, reduce failure risks, certify product compliance, and maintain high safety standards.

Related Standards

To fully implement EN ISO 17654:2011, familiarity with related ISO standards is beneficial:

  • ISO 14329 - Resistance welding destructive tests: failure types and geometric measurements for resistance spot, seam, and projection welds
  • ISO 17677-1 - Resistance welding vocabulary: definitions related to spot, projection, and seam welding processes

Compliance with these standards helps ensure a comprehensive understanding of testing procedures, welding terminology, and quality evaluation criteria within resistance welding practices.

Keywords: EN ISO 17654:2011, resistance welding, resistance seam welds, destructive weld tests, pressure test method, welded joints, pressure vessels, welding quality control, seam weld pressure testing, resistance welding standards.

Frequently Asked Questions

EN ISO 17654:2011 is a standard published by the European Committee for Standardization (CEN). Its full title is "Resistance welding - Destructive tests of welds - Pressure test of resistance seam welds (ISO 17654:2011)". This standard covers: ISO 27654:2011 specifies the pressure test method to be applied to resistance-seam-welded specimens of different types of materials with single sheet thicknesses ranging from 0,3 mm to 3,2 mm. The purpose of this pressure test is to determine the suitability of the material, welding equipment, welding parameters and of other factors on a tank, a vessel or a container for liquids or gases, which are manufactured by resistance seam welding.

ISO 27654:2011 specifies the pressure test method to be applied to resistance-seam-welded specimens of different types of materials with single sheet thicknesses ranging from 0,3 mm to 3,2 mm. The purpose of this pressure test is to determine the suitability of the material, welding equipment, welding parameters and of other factors on a tank, a vessel or a container for liquids or gases, which are manufactured by resistance seam welding.

EN ISO 17654:2011 is classified under the following ICS (International Classification for Standards) categories: 25.160.40 - Welded joints and welds. The ICS classification helps identify the subject area and facilitates finding related standards.

EN ISO 17654:2011 has the following relationships with other standards: It is inter standard links to EN ISO 17654:2003. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.

EN ISO 17654:2011 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
