EN 2817:2009
(Main)Aerospace series - Steel FE-PM1802 (X5CrNiCu15-5) - Consumable electrode remelted - Solution treated and precipitation treated - Bar for machining - a or D ≤ 200 mm - Rm ≥ 1 070 MPa
Aerospace series - Steel FE-PM1802 (X5CrNiCu15-5) - Consumable electrode remelted - Solution treated and precipitation treated - Bar for machining - a or D ≤ 200 mm - Rm ≥ 1 070 MPa
This European Standard specifies the requirements relating to:
Steel FE-PM1802 (X5CrNiCu15-5)
Consumable electrode remelted
Solution treated and precipitation treated
Bar for machining
a or D <= 200 mm
Rm >= 1 070 MPa
for aerospace applications.
Luft- und Raumfahrt - Stahl FE-PM1802 (X5CrNiCu15-5) - Mit selbstverzehrender Elektrode umgeschmolzen - Lösungsgeglüht und ausgelagert - Stangen zur spanenden Bearbeitung - a oder D ≤ 200 mm - Rm ≥ 1 070 MPa
Diese Norm legt die Anforderungen an
Stahl FE-PM 1802 (X5CrNiCu15-5)
mit selbstverzehrender Elektrode umgeschmolzen
lösungsgeglüht und ausgehärtet
Stangen zur spanenden Bearbeitung
a oder D ≤ 200 mm
Rm ≥ 1 070 MPa
für Anwendungen in der Luft- und Raumfahrt fest.
Série aérospatiale - Acier FE-PM1802 (X5CrNiCu15-5) - Refondu à l'électrode consommable - Mis en solution et vieilli - Barres pour usinage - a ou D ≤ 200 mm - Rm ≥ 1 070 MPa
Aeronavtika - Jeklo FE-PM1802 (X5CrNiCu15-5) - Pretaljeno s talilno elektrodo - Žarjeno v topilu in utrjeno - Palice za obdelavo - a ali D ≤ 200 mm - Rm ≥ 1070 MPa
Ta evropski standard opredeljuje zahteve, ki se nanašajo na: Jeklo FE-PM1802 (X5CrNiCu15-5), pretaljeno s talilno elektrodo, žarjeno v topilu in utrjeno, palice za obdelavo a ali D ≤ 200 mm - Rm ≥ 1070 MPa za uporabo v aeronavtiki.
General Information
- Status
- Published
- Publication Date
- 17-Nov-2009
- Withdrawal Date
- 30-May-2010
- Technical Committee
- ASD-STAN - Aerospace
- Drafting Committee
- ASD-STAN/D 4 - Metallic
- Current Stage
- 9093 - Decision to confirm - Review Enquiry
- Start Date
- 21-Jan-2025
- Completion Date
- 09-Feb-2026
Relations
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
Overview
EN 2817:2009 defines material and delivery requirements for steel FE-PM1802 (X5CrNiCu15-5) intended for aerospace bars for machining. The standard specifies that the material shall be consumable electrode remelted, supplied as bars with a or D ≤ 200 mm, and be solution treated and/or precipitation treated to achieve high mechanical strength (Rm ≥ 1 070 MPa). EN 2817 is part of the aerospace metallic material series and is prepared in accordance with EN 4500-5.
Key Topics
- Material designation: Steel FE-PM1802 (X5CrNiCu15-5).
- Melting method: Consumable electrode remelted.
- Form & dimension: Bars for machining; maximum a or D ≤ 200 mm.
- Delivery conditions:
- Solution treated (W code): heat treated at 1 025 °C to 1 055 °C for t ≥ 30 min, air cooled or oil quenched to ≤ 30 °C.
- Solution treated and precipitation treated (U code): above solution treatment plus ageing at 535 °C to 565 °C for t ≥ 4 h, air cooled.
- Mechanical requirements:
- Tensile strength (Rm): ≥ 1 070 MPa.
- Proof stress (Rp0,2): ≥ 1 000 MPa (in specified ranges of section).
- Hardness: typical limits given (e.g., 331 ≤ HB ≤ 401 depending on section and condition).
- Impact performance: specified minimum KV values for temperature and notch directions.
- Microstructure and cleanliness: δ ferrite content ≤ 2 %; grain size and inclusion class per referenced EN documents.
Practical value: The standard ensures consistent high-strength, traceable bar stock suitable for critical aerospace components where predictable heat-treatment response and mechanical performance are required.
Applications
- Machined aerospace structural and mechanical parts requiring high tensile strength and toughness.
- Components that demand controlled microstructure and low inclusion content for fatigue-sensitive applications.
- Use where bar stock must meet defined delivery conditions (solution or solution + precipitation treated) and section limits (D ≤ 200 mm).
Related Standards
EN 2817 cross-references and aligns with several aerospace material standards and test methods, including:
- EN 2043 - General requirements for semi-finished product qualification.
- EN 4258 - Organization of standardization for aerospace metallic materials.
- EN 4436 - Test method for δ ferrite content.
- EN 4500-5 - Rules for drafting/presentation of steels.
- EN 4700-002 - Technical specification for bars and sections.
For procurement and qualification, manufacturers and purchasers should agree qualification programmes per EN 2043 and follow marking, dimensional and inspection rules referenced in EN 4700-002. EN 2817:2009 provides the specification baseline for selecting FE-PM1802 bars intended for machining in aerospace applications.
Get Certified
Connect with accredited certification bodies for this standard
DEKRA North America
DEKRA certification services in North America.
Eagle Registrations Inc.
American certification body for aerospace and defense.
Element Materials Technology
Materials testing and product certification.
Sponsored listings
Frequently Asked Questions
EN 2817:2009 is a standard published by the European Committee for Standardization (CEN). Its full title is "Aerospace series - Steel FE-PM1802 (X5CrNiCu15-5) - Consumable electrode remelted - Solution treated and precipitation treated - Bar for machining - a or D ≤ 200 mm - Rm ≥ 1 070 MPa". This standard covers: This European Standard specifies the requirements relating to: Steel FE-PM1802 (X5CrNiCu15-5) Consumable electrode remelted Solution treated and precipitation treated Bar for machining a or D <= 200 mm Rm >= 1 070 MPa for aerospace applications.
This European Standard specifies the requirements relating to: Steel FE-PM1802 (X5CrNiCu15-5) Consumable electrode remelted Solution treated and precipitation treated Bar for machining a or D <= 200 mm Rm >= 1 070 MPa for aerospace applications.
EN 2817:2009 is classified under the following ICS (International Classification for Standards) categories: 49.025.10 - Steels. The ICS classification helps identify the subject area and facilitates finding related standards.
EN 2817:2009 has the following relationships with other standards: It is inter standard links to EN 4258:2024, EN 4700-002:2025, EN 4632-004:2012, EN 4834:2018. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
EN 2817:2009 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
Standards Content (Sample)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.YHU]HKUHQGHUpOHFWURGH49.025.10JeklaSteelsICS:Ta slovenski standard je istoveten z:EN 2817:2009SIST EN 2817:2010en,de01-januar-2010SIST EN 2817:2010SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 2817
November 2009 ICS 49.025.10 English Version
Aerospace series - Steel FE-PM1802 (X5CrNiCu15-5) - Consumable electrode remelted - Solution treated and precipitation treated - Bar for machining - a or D ≤ 200 mm - Rm ≥ 1 070 MPa
Série aérospatiale - Acier FE-PM1802 (X5CrNiCu15-5) - Refondu à l'électrode consommable - Mis en solution et vieilli - Barres pour usinage - a ou D ≤ 200 mm - Rm ≥ 1 070 MPa
Luft- und Raumfahrt - Stahl FE-PM1802 (X5CrNiCu15-5) - Mit selbstverzehrender Elektrode umgeschmolzen - Lösungsgeglüht und ausgelagert - Stangen zur spanenden Bearbeitung - a oder D ≤ 200 mm - Rm ≥ 1 070 MPa This European Standard was approved by CEN on 8 August 2009.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2009 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 2817:2009: ESIST EN 2817:2010
EN 2817:2
...
