(Main)Aerospace series - Pipe couplings, 60°, spherical, in titanium alloy TI-P64001 - Elbows 90°, welded
Aerospace series - Pipe couplings, 60°, spherical, in titanium alloy TI-P64001 - Elbows 90°, welded
This standard specifies the characteristics of welded elbows 90° for pipe couplings, 60°, spherical, in TI-P64001, for aerospace applications.
NOTE Assembly in accordance with TR 4052
Luft- und Raumfahrt - Rohrverschraubungen mit Kugelbuchsen, 60 ° , aus Titanlegierung TI-P64001 - Winkelverschraubungen 90 ° , zum Anschweißen
Diese Norm legt die Eigenschaften von Winkelverschraubungen 90° zum Anschweißen für Rohrverschraubungen 60° mit Kugelbuchse, aus TI P64001, für Anwendungen in der Luft- und Raumfahrt fest.
ANMERKUNG Montage nach TR 4052.
Aerospace series - Pipe couplings, 60°, spherical, in titanium alloy TI-P64001 - Elbows 90°, welded
General Information
- Status
- Published
- Publication Date
- 12-Nov-2002
- Withdrawal Date
- 30-May-2003
- Technical Committee
- ASD-STAN - Aerospace
- Drafting Committee
- ASD-STAN/D 3 - Mechanical
- Current Stage
- 9093 - Decision to confirm - Review Enquiry
- Start Date
- 30-Jun-2017
- Completion Date
- 28-Jan-2026
Relations
- Effective Date
- 28-Jan-2026
- Refers
EN 2656:2001 - Aerospace series - Pipe coupling - Coupling end, welded - Geometric configuration - Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
Overview
EN 3857:2002 specifies the characteristics of welded 90° elbows for aerospace pipe couplings, 60° spherical, manufactured in titanium alloy TI‑P64001. Intended for aerospace fluid systems and components, the standard covers configuration, dimensional requirements, material reference, designation, marking and quality assurance for these welded elbows. Assembly guidance is given by TR 4052.
Keywords: EN 3857:2002, aerospace pipe couplings, titanium TI‑P64001, welded 90° elbows, spherical 60°, aerospace standards.
Key topics and requirements
- Scope: Defines welded elbows 90° for 60° spherical pipe couplings in TI‑P64001 for aerospace use (assembly per TR 4052).
- Configuration, dimensions and tolerances: Detailed geometrical configuration, dimensions and tolerances are specified (figures and Table 1 in the standard). Dimensions and tolerances are given in millimetres.
- Material: Base material is titanium alloy TI‑P64001, with material properties referenced to EN 2530.
- Fitting ends: Welding and fitting-end geometry are covered; fitting ends follow EN 2656 requirements where applicable.
- Designation: Example format provided (e.g. ELBOW 90° EN3857‑100080) including a dimensional code per Table 1.
- Marking: Marking requirements reference EN 2424, style F, and are illustrated in the standard.
- Quality assurance: Conformity and supplier quality-system approval follow EN 2000 (aerospace quality assurance for EN aerospace products).
- Normative references: EN 2000, EN 2424, EN 2530, EN 2656, and TR 4052 are cited and apply as indicated.
Applications and users
Practical uses:
- Specification and procurement of welded 90° elbows for aircraft and spacecraft fluid systems.
- Design and engineering of aerospace tubing and fluid distribution assemblies requiring spherical 60° pipe couplings.
- Manufacturing and welding processes for titanium‑alloy piping components.
- Vendor qualification, inspection, and acceptance of aerospace pipe fittings.
Who uses EN 3857:2002:
- Aerospace OEMs and airframe suppliers specifying fluid‑system components.
- Mechanical and systems engineers designing tubing runs and fittings.
- Manufacturing and welding teams working with TI‑P64001 titanium alloy.
- Quality assurance managers and procurement specialists ensuring standards compliance.
- Maintenance and MRO organizations replacing or inspecting fittings.
Related standards
- EN 2530 - Titanium alloy TI‑P63 material specification (material reference context)
- EN 2656 - Pipe coupling, coupling end welded - geometrical configuration
- EN 2424 - Marking of aerospace products
- EN 2000 - Aerospace quality assurance (approval of manufacturer quality systems)
- TR 4052 - Assembly recommendations for 60° spherical pipe couplings
EN 3857:2002 is a targeted European aerospace standard useful for anyone specifying, manufacturing or inspecting welded 90° elbows in titanium TI‑P64001 for critical aerospace fluid systems.
