Aerospace series - Steel FE-PM3801 (X5CrNiCu17-4) - Air melted, solution treated and precipitation treated, bar a or D ≤ 200 mm, Rm ≥ 1 310 MPa

This standard specifies the requirements relating to:
Steel FE-PM3801 (X5CrNiCu17-4) — Air melted, solution treated and precipitation treated, bar a or D  200 mm Rm  1 310 MPa
for aerospace applications.

Luft- und Raumfahrt - Stahl FE-PM3801 (X5CrNiCu17-4) - Lufterschmolzen - lösungsgeglüht und ausgehärtet - Stangen - a oder D ≤ 200 mm - Rm ≥ 1 310 MPa

Diese Norm legt die Anforderungen an
Stahl FE PM3801 (X5CrNiCu17 4)
Lufterschmolzen
Lösungsgeglüht und ausgehärtet
Stangen
a oder D  200 mm
Rm ≥ 1 310 MPa
für Anwendungen in der Luft- und Raumfahrt fest.

Série aérospatiale - Acier FE-PM3801 (X5CrNiCu17-4) - Élaboré à l'air, mis en solution et vieilli, barres a ou D ≤ 200 mm, Rm ≥ 1 310 MPa

Aeronavtika - Jeklo FE-PM3801 (X5CrNiCu17-4) - Palice a ali D <= 200 mm, Rm >= 1 310 MPa, taljene, žarjene v topilu in utrjene

General Information

Status
Published
Publication Date
21-Aug-2007
Withdrawal Date
28-Feb-2008
ICS
49.025.10 - Steels
Technical Committee
ASD-STAN - Aerospace
Drafting Committee
ASD-STAN/D 4 - Metallic
Current Stage
6060 - Definitive text made available (DAV) - Publishing
Start Date
22-Aug-2007
Completion Date
22-Aug-2007
Ref Project
SIST EN 3160:2007 - Aerospace series - Steel FE-PM3801 (X5CrNiCu17-4) - Air melted, solution treated and precipitation treated, bar a or D <= 200 mm, Rm >= 1 310 MPa

Relations

Refers
EN 4258:2024 - Aerospace series - Metallic materials - General organization of standardization - Link between types of European Standards and their use
Effective Date
28-Jan-2026
Referred By
EN 4632-004:2012 - Aerospace series - Weldability and brazeability of materials in aerospace constructions - Part 004: Welding and brazing of homogeneous assemblies of high alloyed steels
Effective Date
28-Jan-2026
Revised
FprEN 3160 - Aerospace series - Steel X5CrNiCu17-4 (1.4542) - Air melted - Solution treated and precipitation treated - Bars - a or D ≤ 200 mm - Rm ≥ 1 310 MPa
Effective Date
18-Jan-2023

Overview

EN 3160:2007 is a CEN aerospace material standard that specifies requirements for high-strength stainless-type steel FE-PM3801 (X5CrNiCu17-4) supplied as bars (a or D ≤ 200 mm) that are air melted, solution treated and precipitation treated for aerospace use. The standard sets chemical composition limits, heat treatment regimes, mechanical property minima and acceptance criteria appropriate to critical aerospace semi‑finished products. It is part of the EN aerospace metallic materials series and is intended for suppliers, purchasers and quality laboratories in the aerospace sector.

Key topics and requirements

  • Material designation: FE‑PM3801 (X5CrNiCu17‑4) - air melted.
  • Form and size: Bar form, maximum cross dimension or diameter ≤ 200 mm.
  • Chemical composition limits (examples given in the standard): C ≤ 0.07%, Si ≤ 1.00%, Mn ≤ 1.00%, P ≤ 0.040%, S ≤ 0.030%, Cr ≈ 15–17.5%, Mo ≤ 0.50%, Ni ≤ 5.0%, Cu ≤ 5.0%, Nb+Ta ≤ 0.45%.
  • Heat treatment: Solution treatment 1 025–1 055 °C for ≥ 30 min with air or oil quench to ≤ 30 °C; precipitation ageing 470–490 °C for ≥ 1 h (where required) followed by air cooling.
  • Mechanical properties:Tensile strength Rm ≥ 1 310 MPa and proof stress Rp0.2 ≥ 1 170 MPa (with diameter-dependent elongation and hardness limits described in the standard).
  • Microstructure and quality: δ‑ferrite content ≤ 5%, grain size G ≥ 4, inclusion/cleanliness Category 2, internal defects Class 2. Specific inspection, test-piece and sampling rules follow EN 4700‑2.
  • Delivery and test rules: Delivery conditions, test pieces, dimensional, marking and acceptance inspections are aligned with EN 4700‑2 and EN 2043.

Applications and users

  • Intended for aerospace manufacturers, material suppliers, procurement and quality teams, and testing laboratories.
  • Typical uses include aerospace structural and mechanical components requiring very high tensile strength in bar form where controlled heat treatment and material cleanliness are essential.
  • Useful in procurement specifications, qualifying suppliers and confirming compliance for critical semi‑finished components in aircraft and aerospace systems.

Related standards

  • EN 2043 - General requirements for semi‑finished product qualification
  • EN 4700‑2 - Wrought steel technical specification (bar & section)
  • EN 4436 - δ‑ferrite determination
  • EN 4258, EN 4500‑5 - Organization and drafting rules for aerospace metallic material standards

Keywords: EN 3160, FE‑PM3801, X5CrNiCu17‑4, aerospace steel, precipitation treated, solution treated, air melted, Rm ≥ 1310 MPa, high‑strength bar.

Get Certified

Connect with accredited certification bodies for this standard

DEKRA North America

DEKRA certification services in North America.

ANAB United States Verified
Visit Website

Eagle Registrations Inc.

American certification body for aerospace and defense.

ANAB United States Verified
Visit Website

Element Materials Technology

Materials testing and product certification.

UKAS United Kingdom Verified
Visit Website

Sponsored listings

Frequently Asked Questions

EN 3160:2007 is a standard published by the European Committee for Standardization (CEN). Its full title is "Aerospace series - Steel FE-PM3801 (X5CrNiCu17-4) - Air melted, solution treated and precipitation treated, bar a or D ≤ 200 mm, Rm ≥ 1 310 MPa". This standard covers: This standard specifies the requirements relating to: Steel FE-PM3801 (X5CrNiCu17-4) — Air melted, solution treated and precipitation treated, bar a or D  200 mm Rm  1 310 MPa for aerospace applications.

This standard specifies the requirements relating to: Steel FE-PM3801 (X5CrNiCu17-4) — Air melted, solution treated and precipitation treated, bar a or D  200 mm Rm  1 310 MPa for aerospace applications.

EN 3160:2007 is classified under the following ICS (International Classification for Standards) categories: 49.025.10 - Steels. The ICS classification helps identify the subject area and facilitates finding related standards.

EN 3160:2007 has the following relationships with other standards: It is inter standard links to EN 4258:2024, EN 4632-004:2012, FprEN 3160. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.

EN 3160:2007 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.

Standards Content (Sample)


2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Aerospace series - Steel FE-PM3801 (X5CrNiCu17-4) - Air melted, solution treated and precipitation treated, bar a or D <= 200 mm, Rm >= 1 310 MPaAeronavtika - Jeklo FE-PM3801 (X5CrNiCu17-4) - Palice a ali D <= 200 mm, Rm >= 1 310 MPa, taljene, žarjene v topilu in utrjeneSérie aérospatiale - Acier FE-PM3801 (X5CrNiCu17-4) - Élaboré a l'air, mis en solution et vieilli, barres a ou D <= 200 mm, Rm >= 1 310 MPaLuft- und Raumfahrt - Stahl FE-PM3801 (X5CrNiCu17-4) - Lufterschmolzen, lösungsgeglüht und ausgehärtet, Stangen a oder D <= 200 mm, Rm >= 1 310 MPaTa slovenski standard je istoveten z:EN 3160:2007SIST EN 3160:2007en49.025.10JeklaSteelsICS:SLOVENSKI
STANDARDSIST EN 3160:200701-november-2007

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 3160
August 2007 ICS 49.025.10 English Version
Aerospace series - Steel FE-PM3801 (X5CrNiCu17-4) - Air melted, solution treated and precipitation treated, bar a or D ≤ 200 mm, Rm ≥ 1 310 MPa
Série aérospatiale - Acier FE-PM3801 (X5CrNiCu17-4) - Élaboré à l'air, mis en solution et vieilli, barres a ou D ≤200 mm, Rm ≥ 1 310 MPa
Luft- und Raumfahrt - Stahl FE-PM3801 (X5CrNiCu17-4) - Lufterschmolzen, lösungsgeglüht und ausgehärtet, Stangena oder D ≤ 200 mm, Rm ≥ 1 310 MPa This European Standard was approved by CEN on 24 February 2007.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre: rue de Stassart, 36
B-1050 Brussels © 2007 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 3160:2007: E
...
