EN 3660-027:2013
(Main)Aerospace series - Cable outlet accessories for circular and rectangular electrical and optical connectors - Part 027: Cable outlet, style A, 45°, unsealed, with cable tie strain relief for EN 3646 - Product standard
Aerospace series - Cable outlet accessories for circular and rectangular electrical and optical connectors - Part 027: Cable outlet, style A, 45°, unsealed, with cable tie strain relief for EN 3646 - Product standard
This product standard defines a range of cable outlets, 45°, style A, for use under the following conditions:
Associated electrical connector(s) : EN 3660-002
Temperature range, Class A : - 65 °C to 200 °C
Class N : - 65 °C to 200 °C
Class W : - 65 °C to 175 °C
Luft- und Raumfahrt - Endgehäuse für elektrische und optische Rund- und Rechtecksteckverbinder - Teil 027: Endgehäuse, Bauform A, 45°, nicht abgedichtet, mit Arm für Kabelbinder für EN 3646 - Produktnorm
Série aérospatiale - Accessoires arrière pour connecteurs circulaires et rectangulaires électriques et optiques - Partie 027: Raccord, type A, coudé 45°, non étanche, avec tenue du câble par frettage pour EN 3646 - Norme de produit
La présente Norme Européenne définit une gamme de raccord coudé à 45°, type A, à utiliser dans les conditions suivantes :
Connecteur(s) électrique(s) associé(s) : EN 3660-002
Plage de température, Classe A : 65 °C à 200 °C
Classe N : 65 °C à 200 °C
Classe W : 65 °C à 175 °C
Aeronavtika - Dodatki za okrogle in pravokotne električne in optične konektorje - 027. del: Kabelska spojka, tip A, 45°, netesnjena, z držalom za spojko za EN 3646 - Standard za izdelek
Ta evropski standard določa različne vrste kabelskih spojk, 45°, tipa A, za uporabo pod naslednjimi pogoji: Povezani električni konektorji: EN 3660-002 Temperaturni razpon, razred A: – 65 °C do 200 °C razred N: – 65 °C do 200 °C razred W: – 65 °C do 175 °C.
General Information
- Status
- Published
- Publication Date
- 08-Jan-2013
- Withdrawal Date
- 30-Jul-2013
- Technical Committee
- ASD-STAN - Aerospace
- Drafting Committee
- ASD-STAN/D 2 - Electrical
- Current Stage
- 9093 - Decision to confirm - Review Enquiry
- Start Date
- 21-Jan-2024
- Completion Date
- 21-Jan-2026
Relations
- Effective Date
- 16-Jan-2013
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
Overview
EN 3660-027:2013 is a CEN product standard in the Aerospace series that specifies a range of cable outlets, style A, 45° (unsealed) with cable-tie strain relief intended for use with the connector family referenced by EN 3660-002 / EN 3646. The standard defines physical characteristics, material/finish classes, interface dimensions, identification/marking and the testing regime required to qualify these rear accessories for aerospace electrical and optical connectors.
Key facts:
- Title: Cable outlet, style A, 45°, unsealed, with cable tie strain relief - Product standard
- Applicable connector index: EN 3660-002
- Temperature ranges:
- Class A: −65 °C to 200 °C
- Class N: −65 °C to 200 °C
- Class W: −65 °C to 175 °C
- Shell sizes covered include standard aerospace sizes (e.g., 08 to 24)
Key topics and technical requirements
- Dimensions & mass: Detailed dimensional drawings and mass data are provided (Figure 1, Table 1) for each shell size; interface profiles and tooth details are specified (Figures 2–3, Table 2).
- Materials & finishes: Material/finish is specified by class:
- Class A: aluminium, black anodized
- Class N: aluminium, electroless nickel plated
- Class W: aluminium, olive drab cadmium plated
- Component parts: Provision for spacer pad per EN 3660-036; wire-lock holes and cable-tie/lacing cord areas are defined.
- Assembly and test requirements: Assembly torque and coupling thread strength torque values are specified for installation and test purposes. A comprehensive test matrix (environmental, mechanical and electrical) references EN 2591-100 and EN 3660-001, covering shock, vibration, salt mist, temperature cycling, fluid resistance, flammability, ozone, and mechanical strength of rear accessories.
- Identification & marking: Part-numbering conventions and example identifiers (e.g., EN3660-027N08A) are provided to indicate shell size, material/finish class and spacer pad option.
Applications and users
Who uses EN 3660-027:2013:
- Aerospace connector manufacturers designing compliant rear cable outlets and accessories
- Design and systems engineers specifying connector interfaces and cable strain-relief solutions for aircraft and spacecraft
- Procurement and quality teams verifying part conformity and supplier documentation
- Test laboratories performing qualification and acceptance tests per aerospace standards Practical applications include cable outlet selection for avionics, electrical harness terminations and optical/electrical connector back-ends where 45° routing and cable-tie strain relief are required.
Related standards
- EN 3660-001 - Technical specification (cable outlet accessories)
- EN 3660-002 - Index of product standards / associated connectors
- EN 3660-036 - Spacer pad for cable outlet, style Z
- EN 2591-100 - Aerospace test methods (general)
This standard is essential for ensuring dimensional compatibility, environmental performance and mechanical robustness of 45° cable outlets used in aerospace connector assemblies.
