ASTM D7960-21

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: D7960 − 18 D7960 − 21 An American National Standard
Standard Specification for
Unleaded Aviation Gasoline Test Fuel Containing Non-
hydrocarbon Components
This standard is issued under the fixed designation D7960; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope*
1.1 This specification covers formulating specifications for purchases of a UL102 unleaded aviation gasoline test fuel under
contract and is intended solely for use by purchasing agencies for testing purposes.
1.2 This specification defines a specific type of aviation gasoline for use as an aviation spark-ignition engine test fuel. It does not
include all gasolines satisfactory for reciprocating aviation engines. Certain equipment or conditions of use may permit a wider,
or require a narrower, range of characteristics than is shown by this specification.
1.3 The D7960 test fuel defined by this specification may not exhibit identical performance to those leaded fuels with which the
existing aircraft and ground-based fuel handling equipment have been designed to operate. Therefore, the suitability of this fuel
for use on any specific aircraft, aircraft engine, or ground-based fuel handling equipment should be evaluated before use on that
equipment.
1.4 Issuance of this specification does not constitute approval to operate certificated aircraft with this fuel. Fuels used in certified
engines and aircraft are ultimately approved by the certifying authority subsequent to formal submission of evidence to the
authority as part of the certification program for that aircraft and engine model.
1.5 This specification, unless otherwise provided, prescribes the required properties of unleaded D7960 test fuel at the time and
place of delivery.
1.6 The values stated in SI units are to be regarded as standard. No other units of measurement are included in this standard.
1.7 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of
regulatory limitations prior to use.
1.8 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
This specification is under the jurisdiction of ASTM Committee D02 on Petroleum Products, Liquid Fuels, and Lubricants and is the direct responsibility of Subcommittee
D02.J0.02 on Spark and Compression Ignition Aviation Engine Fuels.
Current edition approved Oct. 1, 2018May 1, 2021. Published October 2018June 2021. Originally approved in 2014. Last previous edition approved in 20172018 as
D7960 – 17.D7960 – 18. DOI: 10.1520/D7960-18.10.1520/D7960-21.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
D7960 − 21
2. Referenced Documents
2.1 ASTM Standards:
D86 Test Method for Distillation of Petroleum Products and Liquid Fuels at Atmospheric Pressure
D93 Test Methods for Flash Point by Pensky-Martens Closed Cup Tester
D130 Test Method for Corrosiveness to Copper from Petroleum Products by Copper Strip Test
D323 Test Method for Vapor Pressure of Petroleum Products (Reid Method)
D357 Method of Test for Knock Characteristics of Motor Fuels Below 100 Octane Number by the Motor Method; Replaced by
D 2700 (Withdrawn 1969)
D381 Test Method for Gum Content in Fuels by Jet Evaporation
D614 Method of Test for Knock Characteristics of Aviation Fuels by the Aviation Method; Replaced by D 2700 (Withdrawn
1970)
D873 Test Method for Oxidation Stability of Aviation Fuels (Potential Residue Method)
D909 Test Method for Supercharge Rating of Spark-Ignition Aviation Gasoline
D910 Specification for Leaded Aviation Gasolines
D1094 Test Method for Water Reaction of Aviation Fuels
D1298 Test Method for Density, Relative Density, or API Gravity of Crude Petroleum and Liquid Petroleum Products by
Hydrometer Method
D1948 Method of Test for Knock Characteristics of Motor Fuels Above 100 Octane Number by the Motor Method; Replaced
by D 2700 (Withdrawn 1968)
D2386 Test Method for Freezing Point of Aviation Fuels
D2392 Test Method for Color of Dyed Aviation Gasolines
D2622 Test Method for Sulfur in Petroleum Products by Wavelength Dispersive X-ray Fluorescence Spectrometry
D2624 Test Methods for Electrical Conductivity of Aviation and Distillate Fuels
D2700 Test Method for Motor Octane Number of Spark-Ignition Engine Fuel
D3338 Test Method for Estimation of Net Heat of Combustion of Aviation Fuels
D4052 Test Method for Density, Relative Density, and API Gravity of Liquids by Digital Density Meter
D4057 Practice for Manual Sampling of Petroleum and Petroleum Products
D4171 Specification for Fuel System Icing Inhibitors
D4177 Practice for Automatic Sampling of Petroleum and Petroleum Products
D4294 Test Method for Sulfur in Petroleum and Petroleum Products by Energy Dispersive X-ray Fluorescence Spectrometry
D4306 Practice for Aviation Fuel Sample Containers for Tests Affected by Trace Contamination
D4529 Test Method for Estimation of Net Heat of Combustion of Aviation Fuels
D4809 Test Method for Heat of Combustion of Liquid Hydrocarbon Fuels by Bomb Calorimeter (Precision Method)
D4865 Guide for Generation and Dissipation of Static Electricity in Petroleum Fuel Systems
D5006 Test Method for Measurement of Fuel System Icing Inhibitors (Ether Type) in Aviation Fuels
D5059 Test Methods for Lead and Manganese in Gasoline by X-Ray Fluorescence Spectroscopy
D5191 Test Method for Vapor Pressure of Petroleum Products and Liquid Fuels (Mini Method)
D5972 Test Method for Freezing Point of Aviation Fuels (Automatic Phase Transition Method)
D6227 Specification for Unleaded Aviation Gasoline Containing a Non-hydrocarbon Component
D6469 Guide for Microbial Contamination in Fuels and Fuel Systems
D7220 Test Method for Sulfur in Automotive, Heating, and Jet Fuels by Monochromatic Energy Dispersive X-ray Fluorescence
Spectrometry
D7719 Specification for High Aromatic Content Unleaded Hydrocarbon Aviation Gasoline
D7826 Guide for Evaluation of New Aviation Gasolines and New Aviation Gasoline Additives
E29 Practice for Using Significant Digits in Test Data to Determine Conformance with Specifications
2.2 Other Documents:
MIL-PRF-25017 Lubricity Improver, Fuel Soluble
GOST 1012–72 Aviation Petrols, Specifications
3. Terminology
3.1 Definitions:
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
The last approved version of this historical standard is referenced on www.astm.org.
Available from Standardization Documents Order Desk, DODSSP, Bldg. 4, Section D, 700 Robbins Ave., Philadelphia, PA 19111-5098, http://dodssp.daps.dla.mil.
Available from Technormativ LLC (Runorm), 19 Shosse Entuziastov, Moscow, 111024, Russia, http://www.runorm.com.
D7960 − 21
3.1.1 unleaded aviation gasoline, n—gasoline intended for use in aircraft powered by reciprocating spark ignition engines, where
lead is not intentionally added for the purpose of enhancing octane performance.
3.1.1.1 Discussion—
Principal properties include volatility limits, stability, detonation-free performance in the engine for which it is intended, and
suitability for low temperature performance.
3.2 Definitions of Terms Specific to This Standard:
3.2.1 non-hydrocarbon, adj—compound composed of carbon and hydrogen and one or more of the elements oxygen, nitrogen, and
sulfur, and any combination of these elements.
3.2.1.1 Discussion—
Some examples of non-hydrocarbon components that may be used in D7960 aviation gasoline are aniline, t-butyl acetate, 2,6
ditertiarybutyl phenol, 2,4-dimethyl-6-tertiarybutylphenol.
4. General
4.1 This specification, unless otherwise provided, prescribes the required properties of unleaded aviation gasoline test fuel at the
time and place of delivery.
5. Classification
5.1 One grade of unleaded aviation gasoline is described, UL102 aviation gasoline test fuel.
NOTE 1—The above grade name is based on the fuel’s motor octane as measured by Test Method D2700.
6. Materials and Manufacture
6.1 D7960 test fuel, except as otherwise specified in this specification, shall consist of blends of refined hydrocarbons derived from
crude petroleum, natural gasoline, biomass or blends thereof, with synthetic hydrocarbons or aromatic hydrocarbons, or both; with
hetero-molecules such as amines, alcohols, carboxylic acids, esters and ethers.
6.1.1 See Appendix X1 for a representative composition that meets the parameters of Table 1.
6.2 Additives—These may be added to D7960 test fuel in the amount and of the composition specified in the following list of
approved materials:
6.2.1 Other Additives—These may be added in the amount and of the composition specified in the following list of approved
materials. The quantities and types shall be declared by the manufacturer. Additives added after the point of manufacture shall also
be declared.
6.2.1.1 Antioxidants—The following oxidation inhibitors may be added to the fuel separately, or in combination, in total
concentration not to exceed 12 mg of inhibitor (not including mass of solvent) per liter of fuel.
(1) 2,6-ditertiary butyl-4-methylphenol.
(2) 2,4-dimethyl-6-tertiary butylphenol.
(3) 2,6-ditertiary butylphenol.
(4) 75 % minimum 2,6-ditertiary butylphenol plus 25 % maximum mixed tertiary and tritertiary butylphenols.
(5) 75 % minimum di- and tri-isopropyl phenols plus 25 % maximum di- and tri-tertiary butylphenols.
(6) 72 % minimum 2,4-dimethyl-6-tertiary butylphenol plus 28 % maximum monomethyl and dimethyl tertiary butylphenols.
(7) N,N’-di-isopropyl-para-phenylenediamine.
(8) N,N’-di-secondary-butyl-para-phenylenediamine.
6.2.1.2 Fuel System Icing Inhibitor (FSII)—One of the following may be used:
(1) Isopropyl Alcohol (IPA, propan-2-ol), in accordance with the requirements of Specification D4171 (Type II). May be used
in concentrations recommended by the aircraft manufacturer when required by the aircraft owner/operator.
D7960 − 21
TABLE 1 Detailed Requirements for UL102 Aviation Gasoline Test Fuel
Property Test Method Min/Max Test Gasoline
A
Motor Octane Number ASTM D2700 Min 102.5
B
Pb, g/L ASTM D5059 Max 0.013
3 C
density @ 15 °C, kg/m ASTM D1298 or D4052 Report Report
IBP, °C ASTM D86 Report Report
10 % by volume at °C ASTM D86 Max 75
40 % by volume at °C ASTM D86 Min 75
50 % by volume at °C ASTM D86 Max 105
90 % by volume at °C ASTM D86 Max 135
Final boiling point, °C ASTM D86 Max 210
Sum of 10 % and 50 % evaporated, °C ASTM D86 Min 135
Recovery, % by volume ASTM D86 Min 97
Residue, % by volume ASTM D86 Max 1.5
Loss, % by volume ASTM D86 Max 1.5
C
Vapor pressure, 38 °C, kPa ASTM D323, ASTM D5191 Min 38.0
Max 49.0
D
Freezing Point, °C
E
Freezing Point, °C ASTM D2386 REPORT
F
Freezing Point, °C ASTM D5972 REPORT
Sulfur, % by mass ASTM D2622, D4294, or D7220 Max 0.05
Net Heat of Combustion, MJ/kg ASTM D4809 Min 42
Corrosion, copper strip, 2 h at 100 °C ASTM D130 Max No. 1
Oxidation stability (5 h aging), potential gum, mg/100 mL ASTM D873 Max 6
Existent Gum, mg/100 mL ASTM D381 Max 1
Water reaction, volume change, mL ASTM D1094 Max ±2
G
Electrical Conductivity, pS/m ASTM D2624 Min 50
G
Max
G
Electrical Conductivity, pS/m ASTM D2624 Min 50
G
Max
A
MON is reported without any corrections applied.
B
Lead content is applicable at the point of manufacture and the point of fit for purpose testing.
C
ASTM Test Methods D4052 and D5191 will be used as referee methods.
D
Caution in the use of this fuel and further investigation may be warranted when results are > –58 °C.
E
This is the standard method used for aviation gasolines; its applicability with this new fuel formulation is under evaluation.
F
This method is currently not applicable for aviation gasolines and is under evaluation for applicability.
G
Applies only when an electrical conductivity additive is used; when a customer specifies fuel containing conductivity additive, the following conductivity limits shall apply
under the condition at point of use:
Minimum 50 pS/m
Maximum 450 600 pS pS/m⁄m
The supplier shall report the amount of additive added.
NOTE 2—Addition of isopropyl alcohol (IPA) may reduce knock ratings below minimum specification values.
(2) Di-Ethylene Glycol Monomethyl Ether (Di-EGME), conforming to the requirements of Specification D4171 (Type III).
May be used in concentrations of 0.10 % to 0.15 % by volume when required by the aircraft owner/operator.
6.2.1.3 Corrosion Inhibitor Additive—Corrosion inhibitors that conform to the latest issue of MIL-PRF-25017 may be added to
the D7960 test fuel in amounts not exceeding the maximum allowable concentrations listed in the latest revision of QPL-25017.
6.2.1.4 Electrical Conductivity Additive—Stadis® 450 in concentrations up to 3 mg ⁄L is permitted. When loss of fuel
conductivity necessitates retreatment with electrical conductivity additive, further addition is permissible up to a maximum
cumulative level of 5 mg ⁄L of Stadis® 450.
7. Detailed Requirements
7.1 The D7960 test fuel shall conform to the requirements prescribed in Table 1.
7.2 Test results shall not exceed the maximum or be less than the minimum values specified in Table 1. No allowance shall be
made for the precision of the test methods. To determine the conformance to the specification requirement, a test result may be
Supporting data have been filed at ASTM International Headquarters and may be obtained by requesting Research Report RR:D02-1526. Contact ASTM Customer
Service at service@astm.org.
Test Method D5006 can be used to determine the concentration of Di-EGME in aviation fuels.
Stadis® 450 is a registered trademark marketed by Innospec, Inc., Innospec Manufacturing Park, Oil Sites Road, Ellesmere Port, Cheshire, CH65 4EY, UK.
D7960 − 21
rounded to the same number of significant figures as in Table 1 using Practice E29. Where multiple determinations are made, the
average result, rounded according to Practice E29, shall be used.
8. Workmanship, Finish, and Appearance
8.1 The D7960 test fuel specified in this specification shall be free from undissolved water, sediment, and suspended matter. No
substances of known dangerous toxicity under usual conditions of handling and use shall be present except as permitted in this
specification.
9. Sampling
9.1 Because of the importance of proper sampling procedures in establishing fuel quality, use the appropriate procedures in
Practice D4057 or Practice D4177.
9.1.1 Although automatic sampling following Practice D4177 may be useful in certain situations, initial manufacturer/supplier
specification compliance testing shall be performed on a sample taken following procedures in Practice D4057.
9.2 A number of D7960 properties, including copper corrosion, electrical conductivity, and others are very sensitive to trace
contamination which can originate from sample containers. For recommended sample containers, refer to Practice D4306.
10. Reports
10.1 The type and number of reports to ensure conformance with the requirements of this specification shall be mutually agreed
to by the purchaser and the supplier of the D7960 test fuel.
11. Test Methods
11.1 The requirements enumerated in this specification shall be determined in accordance with the following ASTM test methods:
11.1.1 Motor Octane Number—Test Method D2700.
11.1.2 Tetraethyl Lead—Test Method D5059.
11.1.3 Density—Test Methods D1298 or D4052.
11.1.4 Distillation—Test Method D86.
11.1.5 Vapor Pressure—Test Methods D323 or D5191.
11.1.6 Freezing Point—Test Method D5972 and D2386.
11.1.7 Sulfur—Test Method D2622, D4294, or D7220.
11.1.8 Net Heat of Combustion—Test Methods D4809.
11.1.9 Corrosion (Copper Strip)—Test Method D130, 2 h test at 100 °C in pressure vessel.
11.1.10 Potential Gum and Visible Lead Precipitate—Test Method D873 except that wherever the letter X occurs (referring to
oxidation time) insert the number 5, designating the number of hours prescribed in this specification.
11.1.11 Water Reaction—Test Method D1094.
11.1.12 Electrical Conductivity—Test Method D2624.
12. Keywords
12.1 aviation gasoline; unleaded aviation gasoline
D7960 − 21
APPENDIXES
(Nonmandatory Information)
X1. PERFORMANCE CHARACTERISTICS OF UNLEADED AVIATION GASOLINE TEST FUEL
X1.1 Introduction
X1.1.1 This specification was developed to identify distillate range refinery products, including refined hydrocarbons derived from
crude petroleum, or blends thereof, with synthetic hydrocarbons and specific heteroatom containing molecules, suitable for high
octane unleaded aviation gasoline applications. The requirements of Table 1 are quality limits established on the basis of test
development as well as tests performed on airframes and engines specifically designed to use these fuels.
X1.1.2 The performance requirements summarized in Table 1 are quality limits which have as their basis the Specification D910
limits supplemented with additional characterization tests where appropriate, which are themselves the result of long-term industry
experience and extensive scientific and engineering literature, as well as the cooperation of certain petroleum refiners and test
procedure owners. The values given are intended to define unleaded aviation gasoline suitable for most types of spark-ignition
aviation engines; however, certain equipment or conditions of use may require fuels having other characteristics.
X1.2 Composition
X1.2.1 The origin of the fuel lies in balancing the synergistic effects of a number of components and compounds to achieve, as
closely as possible, the performance properties of the historic ASTM D910 fuel. One example of a potential compositional space
in volume percent permitted by this test specification is as follows:
15 % to 20 % isopentane
40 % to 50 % alkylate or alkylate blend
20 % to 30 % aromatic
2 % to 10 % amine
0 % to 10 % hetero-molecules in addition to any amine
X1.2.2 The precise formulation composition of any fuel tested will be recorded within a research report along with testing results
with the aim of more precisely defining the composition and properties of a potential production specification.
X2. PERFORMANCE CHARACTERISTICS OF UNLEADED AVIATION GASOLINE TEST FUEL
X2.1 Introduction
X2.1.1 The unleaded aviation gasoline test fuel (hereafter referred to as “D7960 test fuel”) is a complex mixture of relatively
volatile hydrocarbons that result in a narrow range of physical and chemical properties to assure an appropriate amount of power,
detonation suppression, and volatility for high performance piston-engine aircraft while exhibiting the critical low temperature
properties required for General Aviation (“GA”) applications. The engines and aircraft impose a variety of mechanical, physical,
and chemical environments. The properties of D7960 test fuel (Table 1) must be properly balanced to give satisfactory engine
performance over an extremely wide range of conditions.
X2.1.2 The ASTM requirements summarized in Table 1 are quality limi
...
