Designation: C1765 − 19 C1765 − 24
Standard Specification for
Steel Fiber Reinforced Concrete Culvert, Storm Drain, and
Sewer Pipe
This standard is issued under the fixed designation C1765; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope*
1.1 This specification covers steel fiber reinforced concrete pipe (SFRCP) of internal diameters 12 - 48 in., intended to be used
for the conveyance of sewage, industrial wastes, and storm water and for the construction of culverts.
NOTE 1—Experience has shown that the successful performance of this product depends upon the proper selection of the pipe strength, the type of bedding
and backfill, the care that the installation conforms to the construction specifications, and provision for adequate inspection at the construction site. This
specification does not include requirements for bedding, backfill, the relation ship between field load conditions and the strength designation of pipe, or
durability under unusual environmental conditions. These requirements should be included in the project specification.
1.2 The values stated in inch-pound units are to be regarded as standard. No other units of measurement are included in this
standard.
1.3 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2.1 ASTM Standards:
A820/A820M Specification for Steel Fibers for Fiber-Reinforced Concrete
C33/C33M Specification for Concrete Aggregates
C150/C150M Specification for Portland Cement
C260/C260M Specification for Air-Entraining Admixtures for Concrete
C494/C494M Specification for Chemical Admixtures for Concrete
C497 Test Methods for Concrete Pipe, Concrete Box Sections, Manhole Sections, or Tile
C595/C595M Specification for Blended Hydraulic Cements
C618 Specification for Coal Ash and Raw or Calcined Natural Pozzolan for Use in Concrete
C822 Terminology Relating to Concrete Pipe and Related Products
C989/C989M Specification for Slag Cement for Use in Concrete and Mortars
C1017/C1017M Specification for Chemical Admixtures for Use in Producing Flowing Concrete (Withdrawn 2022)
C1602/C1602M Specification for Mixing Water Used in the Production of Hydraulic Cement Concrete
This test method is under the jurisdiction of ASTM Committee C13 on Concrete Pipe and is the direct responsibility of Subcommittee C13.02 on Reinforced Sewer and
Culvert Pipe.
Current edition approved July 15, 2019April 1, 2024. Published July 2019April 2024. Originally approved in 2013. Last previous edition approved in 20182019 as
C1765-18. DOI: 10.1520/C1765-19.-19. DOI: 10.1520/C1765-24.
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
The last approved version of this historical standard is referenced on www.astm.org.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
C1765 − 24
E105 Guide for Probability Sampling of Materials
3. Terminology
3.1 Definitions—For definitions of terms relating to concrete pipe not defined in this specification, see Terminology C822.
3.2 D —the D test load divided by a factor of safety of 1.5.
Service Test
3.3 D —the load the pipe is required to support in the three-edge bearing test expressed as a D-load.
Test
4. Classification
4.1 Pipe furnished under this specification shall be designated as Class I, II, III, IV, or V. The corresponding strength requirements
are prescribed in Table 1. Special designs for pipe strengths not designated in Table 1 are permitted, provided all other requirements
of this specification are met.
TABLE 1 Pipe Strength Requirements
Pipe Class D (lb/linear foot/ D (lb/linear foot/foot
Service Test
foot of diameter) of diameter)
I 800 1200
II 1000 1500
III 1350 2025
IV 2000 3000
V 3000 4500
C1765 − 24
4.2 Current industry practices have provided proof testing for sizes and classes shown in Table 1a and can be considered
commonly available. Additional sizes and classes meeting test requirements of this standard may be possible but must be verified
with local producers prior to specification on a project.
TABLE Table 1a—Commonly Available Sizes/Classes
Class 1 – 12” through 48”
Class 2 – 12” through 48”
Class 3 – 12” through 42”
Class 4 – 12” through 36”
Class 5 – 12” through 36”
5. Basis of Acceptance
5.1 The acceptability of the pipe design shall be in accordance with Section 9.
5.2 Unless designated by the owner at the time of, or before placing an order, the pipe shall be accepted on the basis of Sections
10 and 11, and such material tests as are required in 7.2, 7.3, and 7.5.
5.3 Age for Acceptance—Pipe shall be considered ready for acceptance when they conform to the requirements of this
specification.
6. Design and Manufacturing
6.1 The manufacturer shall provide the following information regarding the pipe unless waived by the owner:
6.1.1 Pipe design strength (D ).
Service
6.1.2 Physical Characteristics—Diameter, wall thickness, laying length, and joint details.
6.1.3 Steel Fiber Concrete Compressive Strength—Minimum steel fiber concrete compressive strength equal to 4000 psi.
6.1.4 Admixtures.
6.1.5 Reinforcement:
6.1.5.1 Type of reinforcement, applicable reinforcement specification, and grade.
6.1.5.2 Percentage of steel fiber reinforcing by volume.
6.1.6 Manufacturing and curing process.
7. Materials and Manufacture
7.1 Materials:
7.1.1 Steel Fiber Reinforced Concrete—The steel fiber reinforced concrete shall consist of cementitious materials, mineral
aggregates, admixtures, if used, and water, in which steel fibers have been mixed in such a manner that the steel and concrete act
together to resist stresses.
7.2 Cementitious Materials:
7.2.1 Cement—Cement shall conform to the requirements for portland cement of Specification C150/C150M or shall be portland
blast-furnace slag cement, portland-limestone cement, or portland-pozzolan cement conforming to the requirements of
Specification C595/C595M, except that the pozzolan constituent in the Type IP portland-pozzolan cement shall be fly ash.
7.2.2 Fly Ash—Fly ash shall conform to the requirements of Class F or Class C of Specification C618.
7.2.3 Slag Cement—Slag cement shall conform to the requirements of Grade 100 or 120 of Specification C989/C989M.
C1765 − 24
7.2.4 Allowable Combinations of Cementitious Materials—The combination of cementitious materials used in the cement shall be
one of the following:
7.2.4.1 Portland cement only,
7.2.4.2 Portland blast-furnace slag cement only,
7.2.4.3 Portland-pozzolan cement only,
7.2.4.4 Portland-limestone cement only,
7.2.4.5 A combination of portland cement or portland-limestone cement and fly ash,
7.2.4.6 A combination of portland cement or portland-limestone cement and slag cement,
7.2.4.7 A combination of portland cement or portland-limestone, slag cement and fly ash, or
7.2.4.8 A combination of portland pozzolan cement and fly ash.
7.3 Aggregates—Aggregates shall conform to the requirements of Specification C33/C33M, except that the requirement for
gradation shall not apply.
7.4 Admixtures and Blends—The following admixtures and blends are allowable.
7.4.1 Air-entraining admixture conforming to Specification C260/C260M;
7.4.2 Chemical admixture conforming to Specification C494/C494M;
7.4.3 Chemical admixture for use in producing flowing concrete conforming to Specification C1017/C1017M; and
7.4.4 Chemical admixture or blend approved by the owner.
7.5 Steel Reinforcement—Reinforcement shall consist of steel fibers conforming to Specification A820/A820M.
7.6 Water—Water used in the production of concrete shall be potable or nonpotable water that meets the requirements of
Specification C1602/C1602M.
7.7 Manufacture:
7.7.1 Mixture—The aggregates shall be sized, graded, proportioned, and mixed with such proportions of cementitious materials,
steel fibers, admixtures, and water as will produce a thoroughly mixed steel fiber concrete of such quality that the pipe will conform
to the test and design requirements of this specification. All concrete shall have a water-cementitious materials ratio not exceeding
0.53 by weight. Cementitious materials shall be as specified in 7.2.
7.7.2 Reinforcement—Steel reinforcing fibers shall be thoroughly mixed throughout the concrete amalgam. No restriction is placed
on the combination or proportion of steel fibers in the finished product, except that pipes manufactured using these materials and
mixture shall comply with the performance requirements of this standard.
7.7.3 Joints—The joints shall be of such design and the ends of the concrete pipe sections so formed that when the sections are
laid together they will make a continuous line of pipe with a smooth interior free of appreciable irregularities in the flow line, all
compatible with the permissible variations given in Section 11.
8. Design
8.1 Design—The wall thickness, compressive strength of the concrete, and percentage of steel fibers by volume shall be sufficient
to pass the D requirements in Table 1.
Test
C1765 − 24
8.2 Special Classes:
8.2.1 If permitted by the owner, the manufacturer may request approval by the owner of a special class of pipe having D values
Test
that differ from those shown in Table 1.
8.2.2 Such special classes of pipe shall be based on the same design/testing requirements as required for those classes found in
Table 1.
9. Proof of Design Testing
9.1 Test Equipment and Facilities—The manufacturer shall furnish without charge all samples, facilities, and personnel necessary
to carry out the tests required by this specification.
9.2 Proof of Design—When testing for proof of design, the pipe tests shall be conducted in accordance with Test Methods C497.
Prior to loading, measure the vertical internal diameter of each end of the pipe. Load on the pipe shall increase continuously until
it reaches the ultimate load without collapse due to residual strength provided by the steel-fiber matrix. The D value shall be
ult
recorded. recorded and shall not be less than the D value prescribed in Table 1 for each respective class of pipe.
ult
9.3 Proof of Bond/Ductility/Toughness—After the proof of design test, the pipe shall be immediately unloaded and reloaded in
accordance with Test Methodcontinue to be subjected to increased loading and/or deflection until the inside C497. diameter has
reduced vertically at either end by at least 2 % of the internal diameter. As a verification of bond, ductility, and toughness, the pipe
shall be loaded until it reaches the specified service load,2 % deflection. Record the peak load (D D) between . 1 % and 2 %
p Service
deflection as follows:
D = the peak load applied over a range of 1 % to 2 % deflection (lb/ft/ft). D shall exceed the required service load (D ).
p p service
NOTE 2—This test ensures the fibers have both the anchorage and tensile strength to continue to behave in a ductile, not brittle manner.manner to a
performance level sufficient to guarantee the long-term performance of the pipe throughout the 1 % to 2 % deflection according to typical rigid design
assumptions.
9.4 Establishment of Pipe Strength:
9.4.1 Three to seven representative specimens, of standard production pipe, shall be tested to their ultimate load, and the results
recorded. Using the values obtained in 9.2, compute the values in 9.4.2 and 9.4.3.
NOTE 3—It is necessary that samples be selected at random. For guidance see Practice E105.
9.4.2 Compute the estimated standard deviation, s, by Eq 1 or Eq 2, which equations yield identical values.
¯
=
s 5 @Σ ~X 2 X! #□⁄□ n 2 1 (1)
~ !
i
2 2
s 5= Σ X 2 Σ X ⁄ n □⁄□ n 2 1 (2)
@ ~ ! # ~ !
i i
where:
X = observed value of the load to develop the ultimate strength,
i
X¯ = average (arithmetic mean) of the values of X , and
i
n = number of observed values.
9.4.3 Compute the minimum allowable arithmetic mean, X¯ . by Eq 3. In Eq 3, the value of the estimated standard deviation, s,
s
shall be as calculated by Eq 1, or Eq 2, or equal to 0.07 L, whichever is greater.
¯
X 5 L1S (3)
s m
L = specification limit (specified D-load) and
S = modified standard deviation dependent upon sample size (see Table 2).
m
C1765 − 24
9.4.4 The pipe shall be deemed acceptable if the arithmetic mean X¯ for the D strength value is equal to or greater than X¯ .
ult s
9.5 Sample Testing of Pipe Strength—If any part of the material or manufacture of the pipe are modified, then the ability of the
pipe to meet the required D value and D values shall be reestablished in accordance with 9.4. Provided there is no change in
Test p
material or manufacture of the pipe used to establish the pipe class, pipe shall be periodically tested in accordance with Section
10 for quality assurance.
10. Physical Requirements
10.1 The proof of design is as required in accordance with 9.2. The test requirements of this section apply to the quality assurance
of pipe production with the pipe being tested to D (150 % of the D ). ) and D .
Test Service p
10.2 Test Specimens—The pipe required for tests shall be furnished by the manufacturer, selected at random, and shall be pipe that
would otherwise not be rejected under this specification.
10.3 External Load Test Strength—The load to produce the D Load as determined by the three-edge-bearing method described
Test
in the Test Methods C497 shall not be less than that prescribed in Table 1 for each respective class of pipe. It is not a requirement
of this section that the pipe be loaded to its D strength. Section
...
