ASTM D3056-23

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: D3056 − 14 (Reapproved 2018) D3056 − 23
Standard Test Method for
Gel Time of Solventless Varnishes
This standard is issued under the fixed designation D3056; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
This standard has been approved for use by agencies of the U.S. Department of Defense.
1. Scope*
1.1 This test method covers the determination of the gel time of a solventless varnish mixed with a catalyst, if required, and
exposed to elevated temperature. There are two methods presented here. New equipment for Method A is no longer available.
1.2 The values stated in SI units are to be regarded as standard. No other units of measurement are included in this standard.
1.3 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of
regulatory limitations prior to use. For a specific precaution statement, see Section 6.
NOTE 1—Although this standard and IEC 60455–2 differ in approach or detail, data obtained using either are technically equivalent.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2.1 ASTM Standards:
D1711 Terminology Relating to Electrical Insulation
2.2 IEC Standard:
IEC 60455–2 Resin Based Reactive Compounds Used for Electrical Insulation—Part 2: Methods of Test
3. Terminology
3.1 Definitions:
3.1.1 gel time, n—of solventless varnish, the time required at a specified temperature for a solventless varnish to be transformed
from a liquid state to a gel as measured with a suitable gel time apparatus.
3.1.2 See Terminology D1711 for definitions of other terms relating to electrical insulation.
This test method is under the jurisdiction of ASTM Committee D09 on Electrical and Electronic Insulating Materials and is the direct responsibility of Subcommittee
D09.01 on Electrical Insulating Products.
Current edition approved Nov. 1, 2018Oct. 1, 2023. Published November 2018October 2023. Originally approved in 1972. Last previous edition approved in 20142018
as D3056 – 14.D3056 – 14 (2018). DOI: 10.1520/D3056-18.10.1520/D3056-23.
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
Available from American National Standards Institute (ANSI), 25 W. 43rd St., 4th Floor, New York, NY 10036, http://www.ansi.org.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
D3056 − 23
4. Significance and Use
4.1 Gel time is important in determining batch uniformity and some processing characteristics. It is indicative of pot life and shelf
life.
5. Apparatus (Method A)
5.1 Gel Time Apparatus.
5.2 Power Supply, 110 V ac variable.
5.3 Balance, with accuracy to the nearest 0.01 g.
5.4 Temperature Controller, capable of maintaining to 61°C.61 °C.
5.5 Magnetic Stirrer, with a magnetized stirring bar coated with a tetrafluoroethylene.
6. Safety Precautions
6.1 It is unsafe to use varnish at temperatures above the flash point without adequate ventilation, especially if the possibility exists
that flames or sparks are present. Store varnish in sealed containers.
7. Procedure (Method A)
7.1 Set up the gel time apparatus as described in the instruction manual supplied by the manufacturer.
7.2 Fill the bath with water or a silicone liquid to completely immerse the test specimen of solventless varnish when the test tube
is placed in the bath. Water is useful up to 100°C.100 °C. Silicone liquids must be used above 100°C100 °C but are suitable for
use at lower temperatures.
NOTE 2—The silicone liquid will be DC-200 or equivalent.
7.3 Place the bath on the magnetic stirrer, and insert the stirring bar into the bath. Connect the heating coil to the temperature
controller. Start the cold water on the bath condenser.
7.4 Adjust the bath to the desired temperature.
7.5 If the varnish requires the addition of catalyst, weigh 100 6 1 g 100 g 6 1 g of solventless varnish into a 150-mL150 mL
beaker and record the mass to the nearest 0.01 g.0.01 g.
7.6 Weigh the desired amount of catalyst to an accuracy of 61 % into the 100 g 100 g of solventless varnish and mix thoroughly.
7.7 Weigh 9.5 to 10.5 g 9.5 g to 10.5 g of catalyzed solventless varnish into a 16 by 150-mm16 mm by 150 mm test tube.
7.8 Insert the glass test rod from the gel time apparatus in the test tube.
7.9 Quickly place the test tube in the bath, connect the glass test rod to the meter, center and start the timer. The timer must be
started within 10 s after the test tube is placed in the bath.
The sole source of supply of the apparatus known to the committee at this time is originally used in Method A was the Sunshine Gel Time Meter, Catalog No. 22,
manufactured by Sunshine Scientific Instruments, 1810 Grant Ave., Philadelphia, PA 19115.Meter. However, the meter and its components were no longer produced as of
early 2017. If you are aware of alternative suppliers, please provide this information to ASTM International Headquarters. Your comments will receive careful consideration
at a meeting of the responsible
...
