ASTM D5077-90(2021)

This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation: D5077 − 90 (Reapproved 2021)
Standard Terminology Relating to
Electrostatic Discharge (ESD) Packaging Materials
This standard is issued under the fixed designation D5077; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
which it is in contact along with the means of surface separation. The
1. Scope
antistatic property is not a dependent function of material resistivity.
1.1 The terms and definitions in this standard are related to
Material resistivity is an intrinsic property used to define its degree of
Electrostatic Discharge (ESD) Packaging Materials and ESD
conductivity without regard to other materials.”
Protective Materials.
conductor, n—a substance or body that allows a flow of
1.2 This international standard was developed in accor-
electric current to pass continuously along it or through it
dance with internationally recognized principles on standard-
when a sufficient voltage is applied across any two points.
ization established in the Decision on Principles for the
Development of International Standards, Guides and Recom- dielectric breakdown, n—a threshold effect in a dielectric
mendations issued by the World Trade Organization Technical medium where, at some electric field strength across the
Barriers to Trade (TBT) Committee. medium, bound electrons become unbound and travel
through the medium as a current. In solid media, the region
2. Referenced Documents
of the current path is permanently damaged. The unit of
measurement is usually volts per unit of thickness.
2.1 ASTM Standards:
D996 Terminology of Packaging and Distribution Environ-
electrically continuous surface, n—a surface that is electri-
ments
cally conductive in that current can be passed at an applied
2.2 EIA Standard:
voltage between any two points of its physical surface.
EIA-541 Packaging Material Standards for ESD, Sensitive
Items electrical overstress (EOS), n—overstress which may be due
to ESD or the operation of items beyond their electrical
3. Terminology
specifications.
antistatic agent, n—a chemical compound which, when im-
electromagnetic shield, n—a screen or other housing placed
pregnated or formulated into or topically applied to a
around a device or circuit to reduce the effects on them from
primary material or substrate, gives the primary material
both electric and magnetic fields.
antistatic properties. See antistatic property.
electrostatic discharge, n—the transfer of electrostatic charge
antistatic property, n—the prevention of triboelectric charge
between bodies at different electrostatic potentials.
generation by effectively minimizing the production of a
electrostatic discharge (ESD) protective, n—a property of
static charge when materials are separated from another
materials capable of one or more of the following:
surface.
preventing the generation of static electricity.
DISCUSSION—The forword of EIA-541 states, “'Antistatic’ no longer
refers to a resistivity range . 'Antistatic’ refers to a material’s ability to
dissipatingelectrostaticchangesoveritssurfaceorvolume.
resist triboelectric charge generation. A material’s antistatic propensity
providing shielding from ESD or electrostatic fields.
depends upon the nature of the material itself and the material with
electrostatic discharge sensitive (ESDS), n—a property of
items in which they are inherently sensitive (ESDS) suscep-
This terminology is under the jurisdiction of ASTM Committee D10 on
tible to either catastrophic failure or latent damage when
Packaging and is the direct responsibility of Subcommittee D10.11 on Terminology
exposed to sources of ESD. Items are often categorized as to
(definitions).
Current edition approved Oct. 1, 2021. Published November 2021. Originally their levels of sensitivity but in all cases require some means
approved in 1990. Last previous edition approved in 2015 as D5077 – 90(2015).
of ESD protective packagi
...
