SIST EN 125500:2002

SIST EN 125500:2002 is a standard published by the Slovenian Institute for Standardization (SIST). Its full title is "Sectional Specification: Magnetic oxide ring cores for interference suppression and low level signal transformer applications". This standard covers: This Sectional Specification prescribes the characteristics, ratings and inspection requirements of assessed quality for ring cores made of soft magnetic oxides and iron powders. Such cores are intended for chokes for interference suppression and also for low level signam transformers for professional and industrial applications (see note below). In order to increase winding ease and to improve voltage breakdown, the cores are often provded with protective coatings. In annex A methods for testing voltage breakdown are given; in annex B a standard series of ring cores is listed. NOTE: Ring cores used for power application are covered by CECC 25 300. Ring cores used for other applications (e.g. pulse, memory storage) are not considered here. It selects from the Generic Specification CECC 25 000, the appropriate methods of test to be used in Detail Specifications derived from this specification, and contans the test schedules to be used in the preparation of such specifications. Each test schedule, referenced by a CECC number, when taken with the appropriate information in clause 5 of this specification, forms a Blank Detail Specification.

This Sectional Specification prescribes the characteristics, ratings and inspection requirements of assessed quality for ring cores made of soft magnetic oxides and iron powders. Such cores are intended for chokes for interference suppression and also for low level signam transformers for professional and industrial applications (see note below). In order to increase winding ease and to improve voltage breakdown, the cores are often provded with protective coatings. In annex A methods for testing voltage breakdown are given; in annex B a standard series of ring cores is listed. NOTE: Ring cores used for power application are covered by CECC 25 300. Ring cores used for other applications (e.g. pulse, memory storage) are not considered here. It selects from the Generic Specification CECC 25 000, the appropriate methods of test to be used in Detail Specifications derived from this specification, and contans the test schedules to be used in the preparation of such specifications. Each test schedule, referenced by a CECC number, when taken with the appropriate information in clause 5 of this specification, forms a Blank Detail Specification.

SIST EN 125500:2002 is classified under the following ICS (International Classification for Standards) categories: 29.100.10 - Magnetic components. The ICS classification helps identify the subject area and facilitates finding related standards.
