DRAFTEUROPEANprETS 300 267-4TELECOMMUNICATIONApril 1997STANDARDSource: ETSI TC-SPSReference: DE/SPS-05048-4ICS:33.020Key words:ISDN, DSS1, teleservice, 7 kHz, video, telephony, testing, ATS, PIXIT, userIntegrated Services Digital Network (ISDN);Telephony 7 kHz and videotelephony teleservices;Digital Subscriber Signalling System No. one (DSS1) protocol;Part 4: Abstract Test Suite (ATS) and partial ProtocolImplementation eXtra Information for Testing (PIXIT) proformaspecification for the userETSIEuropean Telecommunications Standards InstituteETSI SecretariatPostal address: F-06921 Sophia Antipolis CEDEX - FRANCEOffice address: 650 Route des Lucioles - Sophia Antipolis - Valbonne - FRANCEX.400: c=fr, a=atlas, p=etsi, s=secretariat - Internet: secretariat@etsi.frTel.: +33 4 92 94 42 00 - Fax: +33 4 93 65 47 16Copyright Notification: No part may be reproduced except as authorized by written permission. The copyright and theforegoing restriction extend to reproduction in all media.© European Telecommunications Standards Institute 1997. All rights reserved.SIST ETS 300 267-4:1998



Page 2Draft prETS 300 267-4: April 1997Whilst every care has been taken in the preparation and publication of this document, errors in content,typographical or otherwise, may occur. If you have comments concerning its accuracy, please write to"ETSI Editing and Committee Support Dept." at the address shown on the title page.SIST ETS 300 267-4:1998



Page 3Draft prETS 300 267-4: April 1997ContentsForeword.71Scope.92Normative references.93Definitions and abbreviations.103.1Definitions.103.2Abbreviations.104Introduction.115Abstract Test Method (ATM).115.1Description of ATM used.115.2Conventions for test components and PCOs.115.3Description of PCOs.125.3.1D-channel PCO.125.3.2B-channels PCOs.135.4Naming conventions.135.4.1Test cases.135.4.2Variables and parameters.145.4.3Trees and subtrees.146Untestable test purposes.147ATS conventions.147.1Declarations part.147.1.1Type definitions.147.1.1.1Simple type definitions.147.1.1.2Structured type definitions.147.1.1.2.1TTCN structured type definitions.147.1.1.2.2ASN.1 structured type definitions.157.1.1.3ASP type definitions.157.1.1.3.1TTCN ASP type definitions.157.1.1.3.2ASN.1 ASP type definitions.157.1.1.4PDU type definitions.157.1.1.4.1TTCN PDU type definitions.157.1.1.4.2ASN.1 PDU type definitions.167.1.2Test suite constants.167.1.3Test suite parameters.167.1.4Variables.167.1.4.1Test suite variables.167.1.4.2Test case variables.167.1.5Test suite operation definitions.167.2Constraints part.177.2.1Structured type constraint declaration.177.2.2ASN.1 type constraint declaration.177.2.3ASP type constraint declaration.177.2.3.1ASN.1 ASP type constraint declaration.177.2.3.2TTCN ASP type constraint declaration.177.2.4PDU type constraint declaration.177.2.4.1ASN.1 PDU type constraint declaration.177.2.4.2TTCN PDU type constraint declaration.177.2.5Derived constraints.177.2.6Parameterized constraints.18SIST ETS 300 267-4:1998



Page 4Draft prETS 300 267-4: April 19977.2.7Value assignment.187.2.7.1Specific values.187.2.7.2Matching values.187.3Dynamic part.187.3.1Test cases.187.3.2Test steps.187.3.3Defaults.187.3.4Synchronization.188ATS to TP map.209PCTR conformance.2010PIXIT conformance.2011ATS conformance.20Annex A (normative):Protocol Conformance Test Report (PCTR) proforma.21A.1Identification summary.21A.1.1Protocol conformance test report.21A.1.2IUT identification.21A.1.3Testing environment.21A.1.4Limits and reservations.22A.1.5Comments.22A.2IUT Conformance status.22A.3Static conformance summary.22A.4Dynamic conformance summary.22A.5Static conformance review report.23A.6Test campaign report.23A.7Observations.24Annex B (normative):Partial PIXIT proforma.25B.1Identification summary.25B.2Abstract test suite summary.25B.3Test laboratory.25B.4Client (of the test laboratory).26B.5System Under Test (SUT).26B.6Protocol information.27B.6.1Protocol identification.27B.6.2Configuration to be tested.27B.6.3Actions required to stimulate IUT.28B.6.4Test management timers.28B.6.5Parameter values.29SIST ETS 300 267-4:1998



Page 5Draft prETS 300 267-4: April 1997Annex C (normative):Abstract Test Suite (ATS).30C.1The TTCN Graphical form (TTCN.GR).30C.2The TTCN Machine Processable form (TTCN.MP).30Annex D (informative):General structure of ATS.31History.32SIST ETS 300 267-4:1998



Page 6Draft prETS 300 267-4: April 1997Blank pageSIST ETS 300 267-4:1998



Page 7Draft prETS 300 267-4: April 1997ForewordThis draft European Telecommunication Standard (ETS) has been produced by the Signalling Protocolsand Switching (SPS) Technical Committee of the European Telecommunications Standards Institute(ETSI), and is now submitted for the Public Enquiry phase of the ETSI standards approval procedure.This ETS is part 4 of a multi-part standard covering the Digital Subscriber Signalling System No. one(DSS1) protocol specification for the Integrated Services Digital Network (ISDN) telephony 7 kHz andvideotelephony teleservices, as described below:Part 1:"Protocol specification";Part 2:"Protocol Implementation Conformance Statement (PICS) proforma specification";Part 3:"Test Suite Structure and Test Purposes (TSS&TP) specification for the user";Part 4:"Abstract Test Suite (ATS) and partial Protocol Implementation eXtra Information forTesting (PIXIT) proforma specification for the user";Part 5:"TSS&TP specification for the network";Part 6:"ATS and partial PIXIT proforma specification for the network".Proposed transposition datesDate of latest announcement of this ETS (doa):3 months after ETSI publicationDate of latest publication of new National Standardor endorsement of this ETS (dop/e):6 months after doaDate of withdrawal of any conflicting National Standard (dow):6 months after doaSIST ETS 300 267-4:1998



Page 8Draft prETS 300 267-4: April 1997Blank pageSIST ETS 300 267-4:1998



Page 9Draft prETS 300 267-4: April 19971ScopeThis fourth part of ETS 300 267 specifies the Abstract Test Suite (ATS) and partial ProtocolImplementation eXtra Information for Testing (PIXIT) proforma for the User side of the T reference pointor coincident S and T reference point (as defined in ITU-T Recommendation I.411 [17]) ofimplementations conforming to the stage three standard of the telephony 7 kHz and videotelephonyteleservices for the pan-European Integrated Services Digital Network (ISDN) by means of the DigitalSubscriber Signalling System No. one (DSS1) protocol, ETS 300 267-1 [6].ETS 300 267-3 [8] specifies the Test Suite Structure and Test Purposes (TSS&TP) related to this ATSand partial PIXIT proforma specification. Other parts specify the TSS&TP and the ATS and partial PIXITproforma for the Network side of the T reference point or coincident S and T reference point ofimplementations conforming to ETS 300 267-1 [6].2Normative referencesThis ETS incorporates by dated and undated reference, provisions from other publications. Thesenormative references are cited at the appropriate places in the text and the publications are listedhereafter. For dated references, subsequent amendments to or revisions of any of these publicationsapply to this ETS only when incorporated in it by amendment or revision. For undated references the latestedition of the publication referred to applies.[1]ETS 300 102-1: "Integrated Services Digital Network (ISDN); User-networkinterface layer 3; Specifications for basic call control".[2]ETS 300 143: "Integrated Services Digital Network (ISDN); Audiovisual services;Inband signalling procedures for audiovisual terminals using digital channels upto 2 048 kbit/s".[3]ETS 300 144: "Integrated Services Digital Network (ISDN); Audiovisual services;Frame structure for a 64 kbit/s to 1 920 kbit/s channel and associated syntax forinband signalling" (equivalent to ITU-T Recommendation H.221).[4]ETS 300 145: "Integrated Services Digital Network (ISDN); Audiovisual services;Videotelephone systems and terminal equipment operating on one or two64 kbit/s channels".[5]ETS 300 196-1: "Integrated Services Digital Network (ISDN); Generic functionalprotocol for the support of supplementary services; Digital Subscriber SignallingSystem No. one (DSS1) protocol; Part 1: Protocol specification".[6]ETS 300 267-1 (1994) including A1 (1996): "Integrated Services Digital Network(ISDN); Telephony 7 kHz and videotelephony teleservices; Digital SubscriberSignalling System No. one (DSS1) protocol; Part 1: Protocol specification".[7]ETS 300 267-2 (1996): "Integrated Services Digital Network (ISDN); Telephony7 kHz and videotelephony teleservices; Digital Subscriber Signalling System No.one (DSS1) protocol; Part 2: Protocol Implementation Conformance Statement(PICS) proforma specification".[8]ETS 300 267-3: "Integrated Services Digital Network (ISDN); Telephony 7 kHzand videotelephony teleservices; Digital Subscriber Signalling System No. one(DSS1) protocol; Part 3: Test Suite Structure and Test Purposes (TSS&TP)specification for the user".[9]ETS 300 403-1 (1995): "Integrated Services Digital Network (ISDN); DigitalSubscriber Signalling System No. one (DSS1) protocol; Signalling network layerfor circuit-mode basic call control; Part 1: Protocol specification [ITU-TRecommendation Q.931 (1993), modified]".SIST ETS 300 267-4:1998



Page 10Draft prETS 300 267-4: April 1997[10]ETS 300 403-5: "Integrated Services Digital Network (ISDN); Digital SubscriberSignalling System No. one (DSS1) protocol; Signalling network layer for circuit-mode basic call control; Part 5: Abstract Test Suite (ATS) and partial ProtocolImplementation eXtra Information for Testing (PIXIT) proforma specification forthe user".[11]I-ETS 300 763-2: "Integrated Services Digital Network (ISDN); Audiovisualservices in-band signalling testing; Part 2: Abstract Test Suite (ATS) and partialProtocol Implementation eXtra Information for Testing (PIXIT) proforma".[12]ISO/IEC 9646-1: "Information technology - OSI Conformance TestingMethodology and Framework; Part 1: General Concepts".[13]ISO/IEC 9646-2: "Information technology - OSI Conformance TestingMethodology and Framework; Part 2: Abstract Test Suite Specification".[14]ISO/IEC 9646-3: "Information technology - OSI Conformance TestingMethodology and Framework; Part 3: The Tree and Tabular CombinedNotation".[15]ISO/IEC 9646-4: "Information technology - OSI Conformance TestingMethodology and Framework; Part 4: Test realization".[16]ISO/IEC 9646-5: "Information technology - OSI Conformance TestingMethodology and Framework; Part 5: Requirements on test laboratories andclients for the conformance assessment process".[17]ITU-T Recommendation I.411 (1993): "ISDN user-network interfaces -Reference configurations".3Definitions and abbreviations3.1DefinitionsFor the purposes of this ETS, the definitions given in ETS 300 267-1 [6] and ISO/IEC 9646, parts 1 [12]to 5 [16] and the following definitions apply:additional B-channel: The second or subsequent B-channel established in a videotelephony call.initial B-channel: The first channel established in a videotelephony call.3.2AbbreviationsFor the purposes of this ETS, the following abbreviations apply:ASPAbstract Service PrimitiveATMAbstract Test MethodATSAbstract Test SuiteBASBit rate Allocation SignalCESConnection Endpoint SuffixCMCo-ordination MessageCPCo-ordination PointCRCCyclic Redundancy CheckExTSExecutable Test SuiteFAWFrame Alignment WordIUTImplementation Under TestLTLower TesterSIST ETS 300 267-4:1998



Page 11Draft prETS 300 267-4: April 1997MOTMeans Of TestingMTCMain Test ComponentPCOPoint of Control and ObservationPCTRProtocol Conformance Test ReportPDUProtocol Data UnitPICSProtocol Implementation Conformance StatementPIXITProtocol Implementation eXtra Information for TestingPTCParallel Test ComponentSUTSystem Under TestTPTest PurposeTSSTest Suite StructureTTCNTree and Tabular Combined NotationUTUpper Tester4IntroductionImplementations Under Test (IUTs) which are to be tested using this ATS are required to have previouslybeen tested for conformity against and passed the test suites for ETS 300 102-1 [1] or ETS 300 403-1 [9],and the ATS related to ETS 300 143 [2], ETS 300 144 [3] and ETS 300 145 [4] which is contained inI-ETS 300 763-2 [11]].Any messages or fields within messages which are introduced by ETS 300 403-1 [9] are included in thisATS. Behaviours in test cases have been described in such a way to be able to take into account bothETS 300 102-1 [1] and ETS 300 403-1 [9] basic call standards. This ATS also takes into accountmessages defined for the supplementary services, in particular ETS 300 196-1 [5]. When such messagesare received, they are ignored by the ATS as this is not within the scope of this ETS.5Abstract Test Method (ATM)5.1Description of ATM usedThis ATS describes the testing specification of the protocol procedures and switching functions needed tosupport the videotelephony and telephony 7 kHz teleservices at T or coincident S and T reference pointsfor the user.Testing activity will take place on the D-channel and on one or two B-channels depending on whichteleservice is supported and where the service is provided. The videotelephony teleservice can imply up totwo B-channels and telephony 7 kHz teleservice up to one B-channel. Only S and T reference point hasan associated in-band protocol entity and has to follow requirements on B-channels.As a consequence of testing multiple channels simultaneously, the concurrent testing method is used. Atest configuration includes at least a master test component, a Parallel Test Component (PTC) for theD-channel and eventually one or two PTCs for each involved B-channel. No actual testing is performed bythe Main Test Component (MTC), as all Points of Control and Observation (PCOs) are on the PTCs. Theremote test method as defined in ISO/IEC 9646-2 [13] is applied in each PTC.5.2Conventions for test components and PCOsFigure 1 shows a logical view of the complete configuration of the MTC, PTCs, and PCOs. TheCo-ordination Point (CP) relationships between the various components are also indicated. The testmethod used is very close to the test method used in I-ETS 300 763-2 [11].SIST ETS 300 267-4:1998



Page 12Draft prETS 300 267-4: April 1997TC_MasterTC_DTC_B1TC_B2B2LB1LS/T busB-channelsD-channelCP_B1_D CP_Master_DCP_Master_B1CP_Master_B2MTCPTCsPCOsDLIUTTESTERFigure 1: Multi-party test methodIn a master/slave arrangement, the MTC is considered to be the master while the PTCs are the slaves.There are communication paths or CPs between the MTC and each PTC, and also between D-channelPTC and the initial B-channel PTC. The MTC handles all scheduling of test components and exchangesmessages with PTCs to start or to stop the running of their associated tree. Messages between TC_D andTC_B1 concern more functional synchronization like advising the initial B-channel that it can expand themode on two B-channels when the additional B-channel is set up by the TC_D.5.3Description of PCOsThe PCOs are used to control and observe the behaviour of the IUT. Preliminary test case verdicts areassigned depending on the behaviour observed at those points. The final verdict is set by the MTC at theend of the test.5.3.1D-channel PCOFor the D-channel, the PCO resides at the service access point between layers 2 and 3. This PCO isnamed "DL" (L for Lower). The same Abstract Service Primitives (ASPs) as defined in ETS 300 403-5 [10]are used.LTSUTLayer 3IUTPCO DLLayer 2Layer 2Layer 1Layer 1Service providerFigure 2: Remote test methodSIST ETS 300 267-4:1998



Page 13Draft prETS 300 267-4: April 19975.3.2B-channels PCOsFor the in-band signalling protocol there is no explicit layered structure. However, there is an implicitlydefined structure: a lower layer dealing with frame and multiframe structure, bit encoding of BAS codesand their corresponding CRC codes, FAW etc., and a higher layer dealing with the various sequences andprocedures which make use of BAS codes to control the communication.Lower layer PCOs and the corresponding declarations have been reused from the ATS specified inI-ETS 300 763-2 [11]. When a test case needs description behaviour at a higher layer which cannot beeasily expressed at a lower layer, e.g. a complete initialization procedure, and because it is not thepurpose of this ATS to check in-band signalling, references to the test step included in the ATS specifiedin I-ETS 300 763-2 [11] are made instead of importing all of the ASN.1 descriptions.The audio and video signal contents in the frames and multiframes are ignored. Audio encoding/decodingis out of scope of this ETS and requires specific test tools. As it is not possible to analyse the unframedmode, this is not described in this ETS.In the B-channel, frames or multiframes are required to be sent and received continuously to maintainframe alignment and this is achieved by looping until the expected frame or multiframe is received or thetimer expires.A procedure for the detection of incorrect CRC4 is described in this ATS. This depends on the detection ofan ASP which is generated when the tester implements CRC4 and detects incorrect bit values in bitsC1-C4.5.4Naming conventions5.4.1Test casesTest cases have exactly the same reference as the corresponding combined test purpose, seeETS 300 267-3 [8].The structure of a test case identifier is as follows:CT_test case covering a telephony 7 kHz requirement;CV_test case covering a videotelephony requirement.The digits correspond to the digits of the first Test Purpose (TP) included in the combined TP. The TPsare ordered:a)by type of requirement (i.e. generic, telephony 7 kHz or videotelephony);b)by a three digit number which specifies the relevant position in the Test Suite Structure (TSS):-the first digit refers to the second test group level:1for Calling user interface (ORIG);2for Called user interface (DEST);-the second digit refers to the third test group level:1Valid behaviour (BV);2Invalid behaviour (BI);3Inopportune behaviour (BO);-the third digit refers to the fifth test group level:1Fallback allowed (FBA);2Fallback not allowed (FBN);3Connection management (CMN);c)by a two digit sequence number:the sequence number follows the order in which the TPs appear in the third level of the TSS.SIST ETS 300 267-4:1998



Page 14Draft prETS 300 267-4: April 19975.4.2Variables and parametersVariables used in PTCs associated to B-channels are prefixed by the letter B.TC_Dcall referenceCREFchannel nrB_CHN1call referenceCREF2channel nrB_CHN25.4.3Trees and subtreesTest case trees and subtrees are prefixed by "d_" when they describe the behaviour at PTC TC_D, by"b1_" for PTC TC_B1 and "b2_" for PTC TC_B2.Test step names use upper case letters and local subtrees use lower case letters.Preamble subtrees are prefixed by "PR_" and postamble subtrees by "PO_".6Untestable test purposesCombined TPs correspond only to testable TPs and are all covered by the ATS.TPs for generic protocol requirements do not correspond to specific protocol behaviour and only describeparts of ETS 300 267-1 [6] which support the telephony 7 kHz and videotelephony teleservices. TheseTPs have been considered as untestable. Furthermore, TPs which test an unframed mode in theB-channel or an internal behaviour of the IUT have also been considered as untestable.7ATS conventionsThis clause is structured similarly to the structure of a TTCN ATS. However, the names of the subclausesare arranged in a way more suitable to this ETS.7.1Declarations part7.1.1Type definitions7.1.1.1Simple type definitionsWhere appropriate, simple types have a length, a value list or a range restriction attached.Simple types defined as being of some string type (e.g. BITSTRING, OCTETSTRING), have a lengthrestriction or a value list attached.Simple types, defined as being of INTEGER type, have a value list or a range restriction attached.7.1.1.2Structured type definitions7.1.1.2.1TTCN structured type definitionsAll structured type definitions are provided with a full name.All elements in every structured type definition, defined as being of some string type (e.g. BITSTRING,OCTETSTRING), have a length restriction attached.If an element in a structured type definition is defined as being of a referenced type, the (possible)restriction is defined in that referenced type.SIST ETS 300 267-4:1998
