INTERNATIONAL STANDARD ISO 9564-1:2017(E)
Financial services — Personal Identification Number (PIN)
management and security —
Part 1:
Basic principles and requirements for PINs in card-
based systems
1 Scope
This document specifies the basic principles and techniques which provide the minimum security
measures required for effective international PIN management. These measures are applicable to
those institutions responsible for implementing techniques for the management and protection of PINs
during their creation, issuance, usage and deactivation.
This document is applicable to the management of cardholder PINs for use as a means of cardholder
verification in retail banking systems in, notably, automated teller machine (ATM) systems, point-
of-sale (POS) terminals, automated fuel dispensers, vending machines, banking kiosks and PIN
selection/change systems. It is applicable to issuer and interchange environments.
The provisions of this document are not intended to cover:
a) PIN management and security in environments where no persistent cryptographic relationship
exists between the transaction-origination device and the acquirer, e.g. use of a browser for online
shopping (for these environments, see ISO 9564-4);
b) protection of the PIN against loss or intentional misuse by the customer;
c) privacy of non-PIN transaction data;
d) protection of transaction messages against alteration or substitution;
e) protection against replay of the PIN or transaction;
f) specific key management techniques;
g) offline PIN verification used in contactless devices;
h) requirements specifically associated with PIN management as it relates to multi-application
functionality in an ICC.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO/IEC 7816 (all parts), Identification cards — Integrated circuit cards
ISO 9564-2, Financial services — Personal Identification Number (PIN) management and security —
Part 2: Approved algorithms for PIN encipherment
ISO 11568 (all parts), Banking — Key management (retail)
© ISO 2017 – All rights reserved 1

---------------------- Page: 7 ----------------------
ISO 9564-1:2017(E)

ISO 13491-1, Financial services — Secure cryptographic devices (retail) — Part 1: Concepts, requirements
and evaluation methods
ISO 13491-2:2017, Financial services — Secure cryptographic devices (retail) — Part 2: Security compliance
checklists for devices used in financial transactions
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at http://www.iso.org/obp
— IEC Electropedia: available at http://www.electropedia.org/
3.1
acquirer
institution (or its agent) that acquires from the card acceptor (3.3) the financial data relating to the
transaction and initiates such data into an interchange system
3.2
algorithm
clearly specified mathematical process for computation
3.3
card acceptor
party accepting the card and presenting transaction data to an acquirer (3.1)
3.4
cardholder PIN
PIN (3.19) known by the cardholder (3.8)
3.5
cipher text
data in their enciphered form
3.6
compromise
breaching of confidentiality and/or integrity
3.7
cryptographic key
mathematical value that is used in an algorithm (3.2) to transform plain text (3.21) into cipher text (3.5)
or vice versa
3.8
customer
cardholder
individual associated with the primary account number (PAN) (3.22) specified in the transaction
3.9
decipherment
reversal of a previous reversible encipherment (3.26) rendering cipher text (3.5) into plain text (3.21)
3.10
dual control
process of utilizing two or more separate entities (usually persons) operating in concert to protect
sensitive functions or information whereby no single entity is able to access or utilize the materials
EXAMPLE A cryptographic key (3.7) is an example of the type of material protected by dual control.
2 © ISO 2017 – All rights reserved

---------------------- Page: 8 ----------------------
ISO 9564-1:2017(E)

3.11
encipherment
rendering of text unintelligible by means of an encoding mechanism
3.12
integrated circuit
IC
microprocessor (typically) embedded in an ICC (3.13)as specified in ISO/IEC 7816 (all parts)
3.13
integrated circuit card
ICC
card with integrated circuits as specified in ISO/IEC 7816 (all parts)
Note 1 to entry: All references to an ICC are understood to be references to the IC (3.12) of the card and not to any
other storage on the card (e.g. magnetic stripe).
3.14
irreversible encipherment
transformation of plain text (3.21) to cipher text (3.5) in such a way that the original plain text cannot be
recovered other than by exhaustive procedures, even if the cryptographic key (3.7) is known
3.15
issuer
institution holding the account identified by the primary account number (PAN) (3.22)
3.16
key component
one of at least two parameters having the format of a cryptographic key (3.7) that is added modulo-2
with one or more like parameters to form a cryptographic key
3.17
modulo-2 addition
exclusive OR-ing
binary addition with no carry
3.18
node
message processing entity through which a transaction passes
3.19
Personal Identification Number
PIN
string of numeric digits established as a shared secret between the cardholder (3.8) and the issuer
(3.15), for subsequent use to validate authorized card usage
3.20
PIN entry device
PED
device providing for the secure entry of PINs (3.19)
Note 1 to entry: Security requirements for PIN entry devices are specified in 5.1.
3.21
plain text
data in its original unenciphered form
© ISO 2017 – All rights reserved 3

---------------------- Page: 9 ----------------------
ISO 9564-1:2017(E)

3.22
primary account number
PAN
assigned number, composed of an issuer identification number, an individual account identification
and an accompanying check digit as specified in ISO/IEC 7812-1, which identifies the card issuer and
cardholder (3.8)
3.23
primary account number token
PAN Token
surrogate value used in place of the original PAN (3.22) in certain, well-defined situations, but that is
not used in place of the original PAN in every way that the original PAN is used
3.24
pseudo-random number
number that is statistically random and essentially unpredictable although generated by an
algorithmic process
3.25
reference PIN
value of the PIN (3.19) used to verify the transaction PIN (3.30)
3.26
reversible encipherment
transformation of plain text (3.21) to cipher text (3.5) in such a way that the original plain text can be
recovered
3.27
sensitive state
device condition that provides access to the secure operator interface such that it can only be entered
when the device is under dual or multiple control
3.28
split knowledge
condition under which two or more parties separately and confidentially have custody of components
of a single key that individually convey no knowledge of the resultant cryptographic key (3.7)
3.29
terminal
acquirer-sponsored device that accepts ISO/IEC 7813 and ISO/IEC 7816 compliant cards and initiates
transactions into a payments system
Note 1 to entry: It can also include other components and interfaces, such as host communications.
3.30
transaction PIN
PIN (3.19) as entered by the customer (3.8) at the time of the transaction and subsequently transmitted
to an issuer system or submitted to the ICC (3.13) for verification
Note 1 to entry: Verification means comparison to the reference PIN (3.25).
3.31
true random number generator
device that utilizes an unpredictable and non-deterministic physical phenomenon to produce a stream
of bits, where the ability to predict any bit is no greater than 0,5 given knowledge of all preceding and
following bits
4 © ISO 2017 – All rights reserved

---------------------- Page: 10 ----------------------
ISO 9564-1:2017(E)

4 Basic principles of PIN management
4.1 General
The term “PIN” is used to describe any string of numeric digits established as a shared secret between
the cardholder and the issuer, for subsequent use to validate authorized card usage. The term PIN may
be qualified as “cardholder PIN”, “reference PIN” and “transaction PIN” in the following ways.
a) Issuance:
1) the PIN
i) is generated by the issuer and delivered to the cardholder (as the cardholder PIN), or
ii) is selected by the cardholder and conveyed to the issuer;
2) the issuer stores the PIN as the reference PIN or stores data such that the reference PIN can be
recalculated; the reference PIN may be stored in the issuer system and/or an ICC.
b) Usage:
1) the cardholder enters their PIN into a PED. The PIN, once entered into a PED, is the
transaction PIN;
2) the transaction PIN is transmitted to the issuer or sent to the ICC for comparison with the
reference PIN.
Some requirements pertain to all PINs while other requirements are specific to cardholder PINs,
reference PINs, and/or transaction PINs. Where requirements apply to all PINs, the term PIN is used
without qualification.
4.2 Principles
PIN management shall be governed by the following basic principles.
a) Fraudulent modification or access to the hardware and software used for all PIN management
functions shall be prevented or detected (see 6.1.1).
b) For different accounts, encipherment of the same PIN value under a given encipherment key shall
not produce the same cipher text (see 6.2) except by chance.
c) Security of an enciphered PIN shall not rely on the secrecy of the encipherment design or algorithm,
but on the security of the cryptographic key (se
...
