INTERNATIONAL STANDARD ISO/IEC 14492
RECOMMENDATION ITU-T T.88
Information technology – Lossy/lossless coding of bi-level images

Summary
Rec. ITU-T T.88 | ISO/IEC 14492, commonly known as JBIG2, defines a coding method for bi-level images (e.g., black
and white printed matter). These are images consisting of a single rectangular bit plane, with each pixel taking on one of
just two possible colours. This Recommendation | International Standard has been explicitly prepared for a lossy,
lossless, and lossy-to-lossless image compression.

History
*
Edition Recommendation Approval Study Group Unique ID
1.0 ITU-T T.88 2000-02-10 8 11.1002/1000/4845
1.1 ITU-T T.88 (2000) Amd. 1 2003-06-29 16 11.1002/1000/6388
1.2 ITU-T T.88 (2000) Amd. 2 2003-06-29 16 11.1002/1000/6389
1.3 ITU-T T.88 (2000) Amd. 3 2011-05-14 16 11.1002/1000/11312
2.0 ITU-T T.88 2018-08-29 16 11.1002/1000/13688

Keywords
Bi-level images; image compression; lossy image compression; lossless image compression; lossy-to-lossless image
compression; JBIG.

*
To access the Recommendation, type the URL http://handle.itu.int/ in the address field of your web browser, followed by the
Recommendation's unique ID. For example, http://handle.itu.int/11.1002/1000/11830-en.
© ISO/IEC 2019 – All rights reserved
Rec. ITU-T T.88 (08/2018) i
FOREWORD
The International Telecommunication Union (ITU) is the United Nations specialized agency in the field of
telecommunications, information and communication technologies (ICTs). The ITU Telecommunication
Standardization Sector (ITU-T) is a permanent organ of ITU. ITU-T is responsible for studying technical,
operating and tariff questions and issuing Recommendations on them with a view to standardizing
telecommunications on a worldwide basis.
The World Telecommunication Standardization Assembly (WTSA), which meets every four years,
establishes the topics for study by the ITU-T study groups which, in turn, produce Recommendations on
these topics.
The approval of ITU-T Recommendations is covered by the procedure laid down in WTSA Resolution 1.
In some areas of information technology which fall within ITU-T's purview, the necessary standards are
prepared on a collaborative basis with ISO and IEC.

NOTE
In this Recommendation, the expression "Administration" is used for conciseness to indicate both a
telecommunication administration and a recognized operating agency.
Compliance with this Recommendation is voluntary. However, the Recommendation may contain certain
mandatory provisions (to ensure, e.g., interoperability or applicability) and compliance with the
Recommendation is achieved when all of these mandatory provisions are met. The words "shall" or some
other obligatory language such as "must" and the negative equivalents are used to express requirements. The
use of such words does not suggest that compliance with the Recommendation is required of any party.

INTELLECTUAL PROPERTY RIGHTS
ITU draws attention to the possibility that the practice or implementation of this Recommendation may
involve the use of a claimed Intellectual Property Right. ITU takes no position concerning the evidence,
validity or applicability of claimed Intellectual Property Rights, whether asserted by ITU members or others
outside of the Recommendation development process.
As of the date of approval of this Recommendation, ITU had received notice of intellectual property,
protected by patents, which may be required to implement this Recommendation. However, implementers
are cautioned that this may not represent the latest information and are therefore strongly urged to consult the
TSB patent database at http://www.itu.int/ITU-T/ipr/.

 ITU 2019
All rights reserved. No part of this publication may be reproduced, by any means whatsoever, without the
prior written permission of ITU.
ii Rec. ITU-T T.88 (08/2018)
© ISO/IEC 2019 – All rights reserved

Table of Contents
Page
0 Introduction . v
0.1 Interpretation and use of the requirements . v
0.2 Lossy coding . ix
1 Scope . 1
2 Normative references. 1
3 Definitions . 1
4 Symbols and abbreviations . 3
4.1 Abbreviations . 3
4.2 Symbol definitions . 4
4.3 Operator definitions . 11
5 Conventions . 11
5.1 Typographic conventions . 11
5.2 Binary notation . 11
5.3 Hexadecimal notation . 11
5.4 Integer value syntax . 11
5.5 Array notation and conventions . 12
5.6 Image and bitmap conventions . 12
6 Decoding Procedures . 13
6.1 Introduction to decoding procedures . 13
6.2 Generic region decoding procedure . 14
6.3 Generic Refinement Region Decoding Procedure . 21
6.4 Text Region Decoding Procedure . 25
6.5 Symbol Dictionary Decoding Procedure . 33
6.6 Halftone Region Decoding Procedure . 41
6.7 Pattern Dictionary Decoding Procedure . 44
6.8 Colour palette decoding procedure . 46
7 Control Decoding Procedure . 47
7.1 General description . 47
7.2 Segment header syntax . 48
7.3 Segment t ypes . 52
7.4 Segment syntaxes . 54
8 Page Make-up . 82
8.1 Decoder model . 82
8.2 Page image composition . 83
9 Encoding procedures (informative) . 85
10 Control encoding procedures (informative) . 85
11 Page break-up (informative) . 85
11.1 Page break-up architecture . 86
11.2 Page image decomposition. 86
11.3 Multi-page document composition . 88
Annex A – Arithmetic integer decoding procedure . 89
A.1 General description . 89
A.2 Procedure for decoding values (except IAID). 89
A.3 The IAID decoding procedure . 91
Annex B – Huffman table decoding procedure . 93
B.1 General description . 93
B.2 Code table structure . 93
B.3 Assigning the prefix codes . 94
B.4 Using a Huffman table . 95
B.5 Standard Huffman tables . 96
Rec. ITU-T T.88 (08/2018) iii
© ISO/IEC 2019 – All rights reserved

Page
Annex C – Gray-scale image decoding procedure . 103
C.1 General description . 103
C.2 Input parameters. 103
C.3 Return value . 103
C.4 Variables used in decoding . 103
C.5 Decoding the gray-scale image . 103
Annex D – File formats . 105
D.1 Sequential organization . 105
D.2 Random-access organization . 105
D.3 Embedded organization . 106
D.4 File header syntax . 106
Annex E – Arithmetic coding . 108
E.1 Binary encoding . 108
E.2 Description of the arithmetic encoder . 109
E.3 Arithmetic decoding procedure . 116
Annex F – Profiles . 124
Annex G – Arithmetic decoding procedure (software conventions). 127
Annex H – Datastream example and test sequence . 129
H.1 Datastream example . 129
H.2 Test sequence for arithmetic coder . 150
Annex I – Patents . 156
I.1 List of patents . 156
I.2 Contact addresses for patent information . 157
Annex J – Compliant example encoding methods . 158
J.1 List of JBIG2 encoding components and corresponding algorithms . 158
J.2 Method references . 159
Annex K – Electronic conformance data and sample software . 161
K.1 Attached electronic data (informative) . 161
K.2 Working environments of the released sample software (informative) . 162
K.3 How to use the sample software (informative) . 162
Bibliography . 165

Electronic attachments:
1. Reference source code implementation
2. Test bitstreams
iv Rec. ITU-T T.88 (08/2018)
© ISO/IEC 2019 – All rights reserved

0 Introduction
This Recommendation | International Standard, informally called JBIG2, defines a coding method for bi-level images
(e.g., black and white printed matter). These are images consisting of a single rectangular bit plane, with each pixel
taking on one of just two possible colours. Multiple colours are to be handled using an appropriate higher level standard
such as Recommendation ITU-T T.44. It is being drafted by the Joint Bi-level Image Experts Group (JBIG), a
"Collaborative Team", established in 1988, that reports both to ISO/IEC JTC 1/SC29/WG1 and to ITU-T.
Compression of this type of image is also addressed by existing facsimile standards, for example by the compression
algorithms in Recommendations ITU-T T.4 (MH, MR), T.6 (MMR), T.82 (JBIG1), and T.85 (Application profile of
JBIG1 for facsimile). Besides the obvious facsimile application, JBIG2 will be useful for document storage and
archiving, coding images on the World Wide Web, wireless data transmission, print spooling, and even
teleconferencing.
As the result of a process that ended in 1993, JBIG produced a first coding standard formally designated
Recommendation ITU-T T.82 | International Standard ISO/IEC 11544, which is informally known as JBIG or JBIG1.
JBIG1 is intended to behave as lossless and progressive (lossy-to-lossless) coding. Though it has the capability of lossy
coding, the lossy images produced by JBIG1 have significantly lower quality than the original images because the
number of pixels in the lossy image cannot exceed one quarter of those in the original image.
On the contrary, JBIG2 was explicitly prepared for lossy, lossless, and lossy-to-lossless image compression. The design
goal for JBIG2 was to allow for lossless compression performance better than that of the existing standards, and to
allow for lossy compression at much higher compression ratios than the lossless ratios of the existing standards, with
almost no visible degradation of quality. In addition, JBIG2 allows both quality-progressive coding, with the
progression going from lower to higher (or lossless) quality, and content-progressive coding, successively adding
different types of image data (for example, first text, then halftones). A typical JBIG2 encoder decomposes the input bi-
level image into several regions and codes each of the regions separately using a different coding method. Such content-
based decomposition is very desirable especially in interactive multimedia applications. JBIG2 can also handle a set of
images (multiple page document) in an explicit manner.
As is typical with image compression standards, JBIG2 explicitly defines the requirements of a compliant bitstream,
and thus defines decoder behaviour. JBIG2 does not explicitly define a standard encoder, but instead is flexible enough
to allow sophisticated encoder design. In fact, encoder design will be a major differentiator among competing JBIG2
implementations.
Although this Recommendation | International Standard is phrased in terms of actions to be taken by decoders to
interpret a bitstream, any decoder that produces the correct result (as defined by those actions) is compliant, regardless
of the actions it actually takes.
Annexes A, B, C, D, E and F are normative, and thus form an integral part of this Recommendation | International
Standard. Annexes G, H, I, J and K are informative, and thus do not form an integral part of this Recommendation |
International Standard.
0.1 Interpretation and use of the requirements
This section is informative and designed to aid in interpreting the requirements of this Recommendation | International
Standard. The requirements are written to be as general as possible to allow a large amount of implementation
flexibility. Hence the language of the requirements is not specific about applications or implementations. In this section
a correspondence is drawn between the general wording of the requirements and the intended use of this Recom-
mendation | International Standard in typical applications.
0.1.1 Subject matter for JBIG2 coding
JBIG2 is used to code bi-level documents. A bi-level document contains one or more pages. A typical page contains
some text data, that is, some characters of a small size arranged in horizontal or vertical rows. The characters in the text
part of a page are called symbols in JBIG2. A page may also contain "halftone data", that is, gray-scale or colour multi-
level images (e.g., photographs) that have been dithered to produce bi-level images. The periodic bitmap cells in the
halftone part of the page are called patterns in JBIG2. In addition, a page may contain other data, such as line art and
noise. Such non-text, non-halftone data is called generic data in JBIG2.
The JBIG2 image model treats text data and halftone data as special cases. It is expected that a JBIG2 encoder will
divide the content of a page into a text region containing digitized text, a halftone region containing digitized halftones,
and a generic region containing the remaining digitized image data, such as line-art. In some circumstances, it is better
(in image quality or compressed data size) to consider text or halftones as generic data; conversely, in some
circumstances it is better to consider generic data using one of the special cases.
Rec. ITU-T T.88 (08/2018) v
© ISO/IEC 2019 – All rights reserved

An encoder is permitted to divide a single page into any number of regions, but often three regions will be sufficient,
one for textual symbols, one for halftone patterns, and the third for the generic remainder. In some cases, not all types of
data may be present, and the page may consist of fewer than three regions.
The various regions may overlap on the physical page. JBIG2 provides the means to specify how the overlapping
regions are recombined to form the final page image.
A text region consists of a number of symbols placed at specified locations on a background. The symbols usually
correspond to individual text characters. JBIG2 obtains much of its effectiveness by using individual symbols more than
once. To reuse a symbol, an encoder or decoder must have a succinct way of referring to it. In JBIG2, the symbols are
collected into one or more symbol dictionaries. A symbol dictionary is a set of bitmaps of text symbols, indexed so that
a symbol bitmap may be referred to by an index number.
A halftone region consists of a number of patterns placed along a regular grid. The patterns usually correspond to gray-
scale values. Indeed, the coding method of the pattern indices is designed as a gray-scale coder. Compression can be
realized by representing the binary pixels of one grid cell by a single integer, the halftone index (which is usually a
rendered gray-scale value). This many-to-one mapping (the pattern in a cell into a gray-scale value) may have the effect
that edge information present in the original bitmap is lost by halftone coding. For this reason, lossless or near-lossless
coding of halftones will often be better in image quality (though larger in size) if the halftone is coded with generic
coding rather than halftone coding.
0.1.2 Relationship between segments and documents
A JBIG2 file contains the information needed to decode a bi-level document. A JBIG2 file is composed of segments. A
typical page is coded using several segments. In a simple case, there will be a page information segment, a symbol
dictionary segment, a text region segment, a pattern dictionary segment, a halftone region segment, and an end-of-page
segment. The page information segment provides general information about the page, such as its size and resolution.
The dictionary segments collect bitmaps referred to in the region segments. The region segments describe the
appearance of the text and halftone regions by referencing bitmaps from a dictionary and specifying where they should
appear on the page. The end-of-page segment marks the end of the page.
0.1.3 Structure and use of segments
Each segment contains a segment header, a data header, and data. The segment header is used to convey segment
reference information and, in the case of multi-page documents, page association information. A data header gives
information used for decoding the data in the segment. The data describes an image region or a dictionary, or provides
other information.
Segments are numbered sequentially. A segment may refer to a lower-numbered, or earlier, segment. A region segment
is always associated with one specific page of the document. A dictionary segment may be associated with one page of
the document, or it may be associated with the document as a whole.
A region segment may refer to one or more earlier dictionary segments. The purpose of such a reference is to allow the
decoder to identify symbols in a dictionary segment that are present into the image.
A region segment may refer to an earlier region segment. The purpose of such a reference is to combine the image
described by the earlier segment with the current representation of the page.
A dictionary segment may refer to earlier dictionary segments. The symbols added to a dictionary segment may be
described directly, or may be described as refinements of symbols described previously, either in the same dictionary
segment or in earlier dictionary segments.
A JBIG2 file may be organized in two ways, sequential or random access. In the sequential organization, each segment's
segment header immediately precedes that segment's data header and data, all in sequential order. In the random access
organization, all the segment headers are collected together at the beginning of the file, followed by the data (including
data headers) for all the segments, in the same order. This second organization permits a decoder to determine all
segment dependencies without reading the entire file.
A third way of encapsulating of JBIG2-encoded data is to embed it in a non-JBIG2 file – this is sometimes called the
embedded organization. In this case a different file format carries JBIG2 segments. The segment header, data header,
and data of each segment are stored together, but the embedding file format may store the segments in any order, at any
set of locations within its own structure.
0.1.4 Internal representations
Decoded data must be stored before printing or display. While this Recommendation | International Standard does not
specify how to store it, its decoding model presumes certain data structures, specifically buffers and dictionaries.
vi Rec. ITU-T T.88 (08/2018)
© ISO/IEC 2019 – All rights reserved

Figure 1 illustrates major decoder components and associated buffers. In this figure, decoding procedures are outlined
in bold lines, and memory components are outlined in non-bold lines. Also, bold arrows indicate that one decoding
procedure invokes another decoding procedure; for example, the symbol dictionary decoding procedure invokes the
generic region decoding procedure to decode the bitmaps for the symbols that it defines. Non-bold arrows indicate flow
of data: the text region decoding procedure reads symbols from the symbol memory and draws them into the page
buffer or an auxiliary buffer. Although it is not shown in Figure 1, the encoded data stream flows to the decoding
procedures, and the block labelled "Page and auxiliary buffers" produces the final decoded page images.

Figure 1 – Block diagram of major decoder components
The resources required to decode any given JBIG2 bitstream depend on the complexity of that bitstream. Some
techniques such as striping can be used to reduce decoder memory requirements. It is estimated that a full-featured
decoder may need two full-page buffers, plus about the same amount of dictionary memory, plus about 100 kilobytes of
arithmetic coding context memory, to decode most bitstreams.
A buffer is a representation of a bitmap. A buffer is intended to hold a large amount of data, typically the size of a page.
A buffer may contain the description of a region or of an entire page. Even if the buffer describes only a region, it has
information associated with it that specifies its placement on the page. Decoding a region segment modifies the contents
of a buffer.
There is one special buffer, the page buffer. It is intended that the decoder accumulate region data directly in the page
buffer until the page has been completely decoded; then the data can be sent to an output device or file. Decoding an
immediate region segment modifies the contents of the page buffer. The usual way of preparing a page is to decode one
or more immediate region segments, each one modifying the page buffer. The decoder may output an incomplete page
buffer, either as part of progressive transmission or in response to user input. Such output is optional, and its content is
not specified by this Recommendation | International Standard.
All other buffers are auxiliary buffers. It is intended that the decoder fill an auxiliary buffer, then later use it to refine
the page buffer. In an application, it will often be unnecessary to have any auxiliary buffers. Decoding an intermediate
region segment modifies the contents of an auxiliary buffer. The decoder may use auxiliary buffers to output pages
other than those found in a complete page buffer, either as part of progressive transmission or in response to user input.
Such output is optional, and its content is not specified by this Recommendation | International Standard.
A symbol dictionary consists of an indexed set of bitmaps. The bitmaps in a dictionary are typically small,
approximately the size of text characters. Unlike a buffer, a bitmap in a dictionary does not have page location
information associated with it.
Rec. ITU-T T.88 (08/2018) vii
© ISO/IEC 2019 – All rights reserved

0.1.5 Decoding results
Decoding a segment involves invocation of one or more decoding procedures. The decoding procedures to be invoked
are determined by the segment type.
The result of decoding a region segment is a bitmap stored in a buffer, possibly the page buffer. Decoding a region
segment may fill a new buffer, or may modify an existing buffer. In typical applications, placing the data into a buffer
involves changing pixels from the background colour to the foreground colour, but this Recommendation | International
Standard specifies other permissible ways of changing a buffer's pixels.
A typical page will be described by one or more immediate region segments, each one resulting in modification of the
page buffer.
Just as it is possible to specify a new symbol in a dictionary by refining a previously specified symbol, it is also possible
to specify a new buffer by refining an existing buffer. However, a region may be refined only by the generic refinement
decoding procedure. Such a refinement does not make use of the internal structure of the region in the buffer being
refined. After a buffer has been refined, the original buffer is no longer available.
The result of decoding a dictionary segment is a new dictionary. The symbols in the dictionary may later be placed into
a buffer by the text region decoding procedure.
0.1.6 Decoding procedures
The generic region decoding procedure fills or modifies a buffer directly, pixel-by-pixel if arithmetic coding is being
used, or by runs of foreground and background pixels if MMR and Huffman coding are being used. In the arithmetic
coding case, the prediction context contains only pixels determined by data already decoded within the current segment.
The generic refinement region decoding procedure modifies a buffer pixel-by-pixel using arithmetic coding. The
prediction context uses pixels determined by data already decoded within the current segment as well as pixels already
present either in the page buffer or in an auxiliary buffer.
The text region decoding procedure takes symbols from one or more symbol dictionaries and places them in a buffer.
This procedure is invoked during the decoding of a text region segment. The text region segment contains the position
and index information for each symbol to be placed in the buffer; the bitmaps of the symbols are taken from the symbol
dictionaries.
The symbol dictionary decoding procedure creates a symbol dictionary, that is, an indexed set of symbol bitmaps. A
bitmap in the dictionary may be coded directly; it may be coded as a refinement of a symbol already in a dictionary; or
it may be coded as an aggregation of two or more symbols already in dictionaries. This decoding procedure is invoked
during the decoding of a symbol dictionary segment.
The halftone region decoding procedure takes patterns from a pattern dictionary and places them in a buffer. This
procedure is invoked during the decoding of a halftone region segment. The halftone region segment contains the
position information for all the patterns to be placed in the buffer, as well as index information for the patterns
themselves. The patterns, the fixed-size bitmaps of the halftone, are taken from the halftone dictionaries.
The pattern dictionary decoding procedure creates a dictionary, that is, an indexed set of fixed-size bitmaps (patterns).
The bitmaps in the dictionary are coded directly and jointly. This decoding procedure is invoked during the decoding of
a pattern dictionary segment.
The control decoding procedure decodes segment headers, which include segment type information. The segment type
determines which decoding procedure must be invoked to decode the segment. The segment type also determines where
the decoded output from the segment will be placed. The segment reference information, also present in the segment
header and decoded by the control decoding procedure, determines which other segments must be used to decode the
current segment. The control decoding procedure affects everything shown in Figure 1, and so is not shown there as a
separate block.
Table 1 summarizes the types of data being decoded, which decoding procedure is responsible for decoding them, and
what the final representations of the decoded data are.
viii Rec. ITU-T T.88 (08/2018)
© ISO/IEC 2019 – All rights reserved

Table 1 – Entities in the decoding process
JBIG2 JBIG2 Physical
Concept
bitstream entity decoding entity representation
Document JBIG2 file JBIG2 decoder Output medium or device
Page Collection of segments Implicit in control decoding Page buffer
procedure
Region Region segment Region decoding procedure Page buffer or auxiliary
buffer
Dictionary Dictionary segment Dictionary decoding procedure List of symbols
Character Field within a symbol dictionary Symbol dictionary decoding Symbol bitmap
segment procedure
Gray-scale value Field within a halftone dictionary Pattern dictionary decoding Pattern
segment procedure
0.2 Lossy coding
This Recommendation | International Standard does not define how to control lossy coding of bi-level images. Rather it
defines how to perform perfect reconstruction of a bitmap that the encoder has chosen to encode. If the encoder chooses
to encode a bitmap that is different than the original, the entire process becomes one of lossy coding. The different
coding methods allow for different methods of introducing loss in a profitable way.
0.2.1 Symbol coding
Lossy symbol coding provides a natural way of doing lossy coding of text regions. The idea is to allow small
differences between the original symbol bitmap and the one indexed in the symbol dictionary. Compression gain is
effected by not having to code a large dictionary and, afterwards, by having a cheap symbol index coding as a
consequence of the smaller dictionary. It is up to the encoder to decide when two bitmaps are essentially the same or
essentially different. This technique was first described in [1].
The hazard of lossy symbol coding is to have substitution errors, that is, to have the encoder replace a bitmap
corresponding to one character by a bitmap depicting a different character, so that a human reader misreads the
character. The risk of substitution errors can be reduced by using intricate measures of difference between bitmaps
and/or by making sure that the critical pixels of the indexed bitmap are correct. One way to control this, described
in [5], is to index the possibly wrong symbol and then to apply refinement coding to that symbol bitmap. The idea is to
encode the basic character shape at little cost, then correct pixels that the encoder believes alter the meaning of the
character.
The process of beneficially introducing loss in textual regions may also take simpler forms such as removing flyspecks
from documents or regularizing edges of letters. Most likely such changes will lower the code length of the region
without affecting the general appearance of the region – possibly even improving the appearance.
A number of examples of performing this sort of lossy symbol coding with JBIG2 can be found in [7].
NOTE – Although the term "text region" is used for regions of the page coded using symbol coding, other possible uses of
symbol coding include coding line-art and other non-textual data.
0.2.2 Generic coding
To effect near-lossless coding using generic coding, the encoder applies a preprocess to an original image and encodes
the changed image losslessly. The difficulties are to ensure that the changes result in a lower code length and that the
quality of the changed image does not suffer badly from the changes. Two possible preprocesses are given in [11].
These preprocesses flip pixels that, when flipped, significantly lower the total code length of the region, but can be
flipped without seriously impairing the visual quality. The preprocesses provide for effective near-lossless coding of
periodic halftones and for a moderate gain in compression for other data types. The preprocesses are not well-suited for
error diffused images and images dithered with blue noise as perceptually lossless compression will not be achieved at a
significantly lower rate than the lossless rate.
0.2.3 Halftone coding
Halftone coding is the natural way to obtain very high compression for periodic halftones, such as clustered-dot ordered
dithered images. In contrast to lossy generic coding as described above, halftone coding does not intend to preserve the
original bitmap, although this is possible in special cases. Loss can also be introduced for additional compression by not
putting all the patterns of the original image into the dictionary, thereby reducing both the number of halftone patterns
and the number of bits required to specify which pattern is used in which location.
Rec. ITU-T T.88 (08/2018) ix
© ISO/IEC 2019 – All rights reserved

For lossy coding of error diffused images and images dithered with blue noise, it is advisable to use halftone coding
with a small grid size. A reconstructed image will lack fine details and may display blockiness but will be clearly
recognizable. The blockiness may be reduced on the decoder side in a postprocess; for instance, by using other
reconstruction patterns than those that appear in the dictionary. Error diffused images may also be coded losslessly, or
with controlled loss as described above, using generic coding.
More details on performing this halftone coding can be found in [12].
0.2.4 Consequences of inadequate segmentation
In order to obtain optimum coding, both in te
...
