61300-2-33 © IEC:2012 – 5 –
FIBRE OPTIC INTERCONNECTING DEVICES
AND PASSIVE COMPONENTS –
BASIC TEST AND MEASUREMENT PROCEDURES –

Part 2-33: Tests – Assembly and disassembly of fibre optic
mechanical splices, fibre management systems and closures

1 Scope
This part of the IEC 61300 series, evaluates the assembly and reassembly of a fibre optic
mechanical splice, a fibre management system or a closure for a specified number of times.
The test procedures simulate the following conditions which may be encountered during the
component's service lifetime:
– the ability of an optical mechanical splice to be re-installed after disassembly;
– the ability to re-enter fibre management systems and closures, by accessing fibres and
optical components and making reconfigurations without disturbing transmission in adjacent
fibre circuits;
– verification of the sealing performance after frequent opening and closing of enclosures.
2 Normative references
The following documents, in whole or in part, are normatively referenced in this document and
are indispensable for its application. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments)
applies.
IEC 61300-2-22, Fibre optic interconnecting devices and passive components – Basic test and
measurement procedures – Part 2-22: Tests – Change of temperature
IEC 61300-3-28, Fibre optic interconnecting devices and passive components – Basic test and
measurement procedures – Part 3-28: Examinations and measurements – Transient loss
IEC 61753-1, Fibre optic interconnecting devices and passive components – Part 1: General
and guidance for performance standards
3 Terms and definitions
For the purpose of this document, the following terms and definitions apply.
3.1
closure
all external housings except outdoor cabinets
3.2
fibre management system
system to control fibre routing from the incoming to the outgoing fibres

– 6 – 61300-2-33 © IEC:2012
3.3
re-entry
access to the fibre management system after initial installation
3.4
mechanical splice
a fibre splice accomplished by fixtures or materials, rather than by thermal fusion
Note 1 to entry: Index matching material may be applied between the two fibre ends.
4 General description
Three test procedures are described. Procedure A tests the ability of optical mechanical splices
to be re-installed after disassembly. Procedure B tests the ability to re-enter fibre management
systems and closures, by accessing fibres and optical components and making
reconfigurations without disturbing transmission in adjacent fibre circuits. Procedure C verifies
the sealing performance after frequent opening and closing of enclosures.
The mechanical splice, fibre management system or (en)closure shall be assembled and
reassembled a specified number of times following the manufacturer's instructions, including
any specified cleaning or recovery procedure.
The test shall be done according to requirements referenced in IEC 61753-1. Assembly and
disassembly of the mechanical splice, fibre management system or closure shall be carried out
at room temperature, unless otherwise specified.
5 Procedure
5.1 Preparation of the specimen
Assembly tools and consumable materials, as specified by the manufacturer, shall be used.
5.2 Test procedures
5.2.1 Procedure A: Re-installation of an optical mechanical splice after disassembly
General description of the steps for Procedure A is defined as follows.
1) Assemble the mechanical splice according to the manufacturer's installation instructions
using the specified fibre or cable.
2) Perform any required examination and measurements as specified in the relevant
performance standard.
3) Perform the temperature ageing cycle as specified in the relevant performance standard.
When not specified, the ageing cycle as defined in Table 1 shall be used. After the
ageing cycle allow the specimen to recover at ambient temperature for at least 2 hours.
4) Disassemble the mechanical splice to the specified extent or to the point that all internal
fibres and devices can be accessed or removed.
5) Perform any specified cleaning and fibre preparation operations.
6) Re-install the mechanical splice according to the manufacturer's instructions.
7) Perform any required examinations and measurements as specified in the relevant
specification.
8) Repeat steps 3 through 7 for the number of cycles specified.
5.2.2 Procedure B: Optical stability during product reconfiguration
General description of the steps for Procedure B is defined as follows.

61300-2-33 © IEC:2012 – 7 –
1) Assemble the (en)closure or fibre management system according to the manufacturer's
instructions using the specified fibre or cable. An optical circuit is built as specified in
the performance standard.
2) Perform any required examination and measurements as specified in the relevant
performance standard. The change in attenuation in the optical circuit shall be
measured with the transient loss procedure, IEC 61300-3-28, when performing steps 3,
4 and 5.
3) The handling operations shall be performed as specified in the performance standard
(see Annex A for a typical example). The (en)closure shall be disassembled to the
specified extent or to the point that the internal fibres and devices can be accessed or
removed.
4) Perform the specified reconfiguration operations.
5) Close and secure the fibre management system and reassemble the (en)closure
according to the manufacturer's instructions.
5.2.3 Procedure C: Sealing performance after frequent opening and closing of the
enclosures
General description of the steps for Procedure C is defined as follows.
1) Assemble the (en)closure according to the manufacturer's installation instructions using
the specified fibre or cable.
2) Perform any required examination and check sealing performance as specified in the
relevant performance standard.
3) When specified in the performance standard, perform the specified temperature ageing
cycle. After the ageing cycle, allow the (en)closure to recover at ambient temperature
for at least 4 hours.
4) Disassemble the (en)closure to the specified extent or to the point that all internal fibres
and devices can be accessed or removed.
5) Re-install the (en)closure according to the manufacturer's installation instructions.
6) Perform any required examinations and check sealing performance as specified in the
relevant specification.
7) Repeat steps 3 through 6 for the number of cycles specified.
5.2.4 Ageing procedure
If specified in the relevant performance standard, the product shall be submitted to an aeging
process between assembly and disassembly operations. The major reason for the ageing
process is to speed up the creep of the polymeric materials in the alignment area or sealing
area after a re-entry is completed.
The purpose of the ageing procedure includes:
– identification of the design failures;
– identification of manufacturing defects;
– impact of product ageing on assembly and disassembly.
Table 1 shows ageing conditions. The ageing conditions are based on the operating
environmental conditions given in IEC 61753-1.

– 8 – 61300-2-33 © IEC:2012
Table 1 – Ageing procedure between two cycles of assembly
and disassembly of fibre optic mechanical splices and closures
Ageing conditions
Operating environment
IEC 61300-2-22
Ageing conditions for Procedure A: Mechanical splices
-10 °C ± 2 °C to +60 °C ± 2 °C
2 h duration at extremes
Controlled C
1 °C/min rate of change
1 cycle
-40 °C ± 2 °C to +70 °C ± 2 °C
2 h duration at extremes
Uncontrolled U
1 °C/min rate of change
1 cycle
-40 °C ± 2 °C to +85 °C ± 2 °C
2 h duration at extremes
Extreme E
1 °C/min rate of change
1 cycle
Ageing conditions for Procedure C: Closures
-10 °C ± 2 °C to +60 °C ± 2 °C
4 h duration at extremes
Controlled C
1 °C/min rate of change
1 cycle
-40 °C ± 2 °C to +65 °C ± 2 °C
4 h duration at extremes
Aerial A
1 °C/min rate of change
1 cycle
-40 °C ± 2 °C to +65 °C ± 2 °C
4 h duration at extremes
Ground G
1 °C/min rate of change
1 cycle
-30 °C ± 2 °C to +60 °C ± 2 °C
4 h duration at extremes
Subterranean S
1 °C/min rate of change
1 cycle
After ageing, allow test specimens to recover at ambient temperature for at least 2 h for
mechanical splices and 4 h for (en)closures

61300-2-33 © IEC:2012 – 9 –
5.3 Severity
The severity for Procedures A and C is determined by the number of assembly and
disassembly cycles as indicated in Table 2.
Table 2 – Number of assembly/disassembly cycles
for different operating environments
Operating environment Number of assembly/ Number of ageing cycles between
disassembly cycles each assembly/disassembly cycle
Procedure A: Mechanical splices
Controlled C 5 1
Uncontrolled U and O 5 1
Extreme E 5 1
Procedure C: Closures
Controlled C 10 1
Aerial A 10 1
Ground G 10 1
Subterranean S 10 1
NOTE The ageing procedure between each disassembly/assembly cycle shall be conducted according to Table 2

6 Details to be specified
The following details, as applicable, shall be specified in the relevant specification:
– test procedure;
– test specimen configuration;
– number of test specimens;
– preconditioning of test specimen;
– number of assembly and disassembly cycles;
– temperature condition for assembly and disassembly;
– ageing process between two assembly/disassembly cycles;
– number of ageing cycles between each assembly/disassembly cycle;
– description of installation and/or intervention operations (see Annex A for example of
closure);
– initial examinations and measurements and performance requirements;
– recovery procedure for the mechanical splice, fibre management system or (en)closure;
– final examinations and measurements and performance requirements;
– deviations from the manufacturer’s assembly/disassembly instructions;
– additional pass/fail criteria.

– 10 – 61300-2-33 © IEC:2012
Annex A
(informative)
Installation and intervention procedure for closure –
Optical stability
When installed in the network, a fibre optic closure may be subjected to a number of
manipulations related to interventions for network repair or maintenance. It is i
...
