SPECIFICATIONS FOR PARTICULAR
TYPES OF WINDING WIRES –
Part 58: Polyamide-imide enamelled
rectangular copper wire, class 220

1 Scope
This part of IEC 60317 specifies the requirements of enamelled rectangular copper winding
wire of class 220 with a sole coating based on polyamide-imide resin, which may be modified
providing it retains the chemical identity of the original resin and meets all specified wire
requirements.
Class 220 is a ther
...
