INTRODUCTION
This part of IEC 60317 forms an element of a series of standards which deals with insulated
wires used for windings in electrical equipment. The series has three groups describing:
1) Winding wires – Test methods (IEC 60851 series);
2) Specifications for particular types of winding wires (IEC 60317 series);
3) Packaging of winding wires (IEC 60264 series).

REDLINE VERSION – 6 – IEC 60317-73:2018+AMD1:2024 CSV
© IEC 2024
SPECIFICATIONS FOR PARTICULAR
TYPES OF WINDING WIRES –
Part 73: Polyester or polyesterimide overcoated with polyamide-imide
enamelled rectangular aluminium wire, class 200

1 Scope
This part of IEC 60317 specifies the requirements of enamelled rectangular aluminium
winding wire of class 200 with a dual coating. The underlying coating is based on polyester or
polyesterimide resin, which can be modified providing it retains the chemical identity of the
original resin and meets all specified wire requirements. The superimposed coating is based
on polyamide-imide resin.
NOTE A modified resin is a resin that has undergone a chemical change, or contains one or more additives to
enhance certain performance or application characteristics.
The range of nominal conductor dimensions covered by this standard is:
– width: min. 2,0 mm
...
