– 6 – IEC 60317-74:2018 © IEC 2018
SPECIFICATIONS FOR PARTICULAR TYPES
OF WINDING WIRES –
Part 74: Polyesterimide enamelled
rectangular aluminium wire, class 180

1 Scope
This part of IEC 60317 specifies the requirements of enamelled rectangular aluminium
winding wire of class 180 with a sole coating based on polyesterimide resin, which can be
modified providing it retains the chemical identity of the original resin and meets all specified
wire requirements.
NOTE A modified resin is a resin that has undergone a chemical change, or contains one or more additives to
enhance certain performance or application characteristics.
The range of nominal conductor dimensions covered by this standard is:
– width: min. 2,0 mm max. 16,0 mm;
– thickness: min. 0,80 mm max. 5,60 mm.
Wires of grade 1 and grade 2 are included in this specification and apply to the complete
range of conductors.
The specified combinations of width and thickness as well as the specified width/thickness
ratio are given in IEC 60317-0-9:2015.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their
content constitutes requirements of this document. For dated references, only the edition
cited applies. For undated references, the latest edition of the referenced document (including
any amendments) applies.
IEC 60317-0-9:2015, Specifications for particular types of winding wires – Part 0-9: General
requirements – Enamelled rectangular aluminium wire
3 Terms, definitions, general notes and appearance
...
