OPTICAL AMPLIFIERS – TEST METHODS –
Part 5-2: Reflectance parameters –
Electrical spectrum analyser method
1 Scope and object
This part of IEC 61290 applies to optical fibre amplifiers (OFAs) using active fibres, containing
rare-earth dopants, presently commercially available.
The object of this part of IEC 61290 is to establish uniform requirements for accurate and
reliable measurements, by means of the electrical spectrum analyser test method, of the
following OFA parameters, as defined in IEC 61291-1:
a) input reflectance;
b) output reflectance.
NOTE 1 All numerical values followed by (‡) are currently under study.
NOTE 2 The measurement uncertainty should be better than ±1 dB.
2 Normative references
The following referenced documents are indispensable for the application of this document. For
dated references, only the edition cited applies. For undated references, the latest edition of
the referenced document (including any amendments) applies.
IEC 61291-1, Optical fibre amplifiers – Part 1: Generic specification
3 Abbreviated terms
For the purposes of this document, the following abbreviations apply:
ASE Amplified spontaneous emission
DFB Distributed feedback (laser diode)
EA Electro-absorption
ESA Electrical spectrum analyser
MZ Mach-Zehnder
OFA Optical fibre amplifier
OSA Optical spectrum analyser
61290-5-2  IEC:2003 – 11 –
4 Apparatus
The measurement set-ups are shown in Figure 1.
Optical branching
device
Frequency Polarization
Tx dB OA
synthesizer
controller
Terminated port
Variable
attenuator
Rx
ESA
Terminated port
Isolator
Receiver
IEC  2207/03
Figure 1a – OFA input reflectance
Frequency
synthesizer
f1
Polarization
Tx
controller
Optical branching
device
Polarization
Tx
dB OA
controller
Isolator
Frequency
Terminated port
synthesizer
f2
X
Optical
spectrum dB
analyser
Isolator
Polarization
Y
beam splitter
Electrical
spectrum
Rx
analyser
Receiver
IEC  2208/03
Figure 1b – OFA o
...
