EN 61068-2:1997
(Main)Specification for polyester fibre woven tapes - Part 2: Methods of test
Specification for polyester fibre woven tapes - Part 2: Methods of test
Gives methods of test to demonstrate compliance with the general requirements of Part 1 and the specific requirements of Part 3 of the standard.
Bestimmung für gewebte Bänder aus Polyesterfilamenten - Teil 2: Prüfverfahren
Spécification pour rubans tissés en fibres de polyester - Partie 2: Méthodes d'essai
Donne les méthodes d'essai pour démontrer la conformité aux prescriptions générales de la partie 1 et aux prescriptions particulières de la partie 3 de la norme.
Specification for polyester fibre woven tapes - Part 2: Methods of test (IEC 61068-2:1991)
General Information
- Status
- Published
- Publication Date
- 27-Aug-1997
- Withdrawal Date
- 31-May-1998
- Technical Committee
- CLC/SR 15 - Insulating materials
- Drafting Committee
- IEC/TC 15 - IEC_TC_15
- Parallel Committee
- IEC/SC 15C - IEC_SC_15C
- Current Stage
- 6060 - Document made available - Publishing
- Start Date
- 28-Aug-1997
- Completion Date
- 28-Aug-1997
Relations
- Effective Date
- 03-Feb-2026
Overview
EN 61068-2:1997 (Specification for polyester fibre woven tapes - Part 2: Methods of test) specifies laboratory test procedures used to demonstrate compliance with the general requirements of Part 1 and the material-specific requirements of Part 3. Published by CLC and aligned with IEC 61068-2:1991, this standard defines repeatable methods for measuring physical and mechanical properties of continuous-filament polyester woven tapes used in electrical insulation and related applications.
Key topics and technical requirements
The standard sets out detailed test methods and conditions, including:
- General scope - Applies to tapes woven on shuttleless looms from continuous-filament polyester fibres; Part 2 provides the test methods to verify Parts 1 and 3.
- Normative references - Incorporates relevant international test standards such as ISO 5081 (breaking strength/elongation) and ISO 5084 (thickness).
- Count and structure measurements
- Determination of number of warp ends (ends per 10 mm).
- Determination of picks (weft threads) using defined sample lengths and averaging.
- Dimensional tests
- Thickness measured to ISO 5084 with specified conditioning (relative humidity 45–75%, temperature 15–35 °C) and presser-foot pressure (nominally 100 kPa).
- Width measured on un-tensioned tape with steel rule; multiple measurements averaged.
- Thermal shrinkage
- Oven test at 155 ± 5 °C for 60 ± 10 minutes, cooling for 1 hour at 15–35 °C; shrinkage reported as percentage and in mm.
- Mechanical strength
- Tensile strength determined using ISO 5081 methodology (modified): five specimens, unstretched gauge length 200 mm, test temperature 15–35 °C; results expressed in N/mm width.
- Heat-activated force (shrink-force)
- Method to determine maximum force developed when tape is heated to approximately 150–155 °C: 100 mm jaw spacing, nominal preload ~5% of estimated breaking load, temperature ramp in 10–15 minutes; central value of three measurements reported.
Applications and users
This methods standard is practical for:
- Manufacturers of polyester filament woven tapes for quality control and product specification verification.
- Independent test laboratories performing acceptance testing, supplier audits, and certification testing.
- Procurement and specification writers who need standardized test results for contracts and technical datasheets.
- Design engineers in electrical insulation, wire and cable harnessing, and industrial strapping who require validated mechanical and thermal performance data.
Useful SEO keywords: polyester fibre woven tapes, EN 61068-2:1997, methods of test, tensile strength, shrinkage test, thickness measurement, ISO 5084, ISO 5081, insulating materials.
Related standards
- EN/IEC 61068-1 - Definitions, designation and general requirements (Part 1)
- EN/IEC 61068-3 - Specifications for individual materials (Part 3)
- ISO 5081, ISO 5084 - Referenced test methods for tensile and thickness measurements
For compliance testing and product development, EN 61068-2 provides the standardized test procedures necessary to produce reliable, comparable data on polyester woven tape performance.
Get Certified
Connect with accredited certification bodies for this standard
Intertek Testing Services NA Inc.
Intertek certification services in North America.
UL Solutions
Global safety science company with testing, inspection and certification.
ANCE
Mexican certification and testing association.
Sponsored listings
Frequently Asked Questions
EN 61068-2:1997 is a standard published by CLC. Its full title is "Specification for polyester fibre woven tapes - Part 2: Methods of test". This standard covers: Gives methods of test to demonstrate compliance with the general requirements of Part 1 and the specific requirements of Part 3 of the standard.
Gives methods of test to demonstrate compliance with the general requirements of Part 1 and the specific requirements of Part 3 of the standard.
EN 61068-2:1997 is classified under the following ICS (International Classification for Standards) categories: 29.035.20 - Plastics and rubber insulating materials. The ICS classification helps identify the subject area and facilitates finding related standards.
EN 61068-2:1997 has the following relationships with other standards: It is inter standard links to EN 61068-3-1:1995. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
EN 61068-2:1997 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
Standards Content (Sample)
SLOVENSKI STANDARD
01-junij-1998
Specification for polyester fibre woven tapes - Part 2: Methods of test (IEC 61068-
2:1991)
Specification for polyester fibre woven tapes -- Part 2: Methods of test
Bestimmung für gewebte Bänder aus Polyesterfilamenten -- Teil 2: Prüfverfahren
Spécification pour rubans tissés en fibres de polyester -- Partie 2: Méthodes d'essai
Ta slovenski standard je istoveten z: EN 61068-2:1997
ICS:
29.035.20 3ODVWLþQLLQJXPHQLL]RODFLMVNL Plastics and rubber insulating
PDWHULDOL materials
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
NORME
CEI
INTERNATIONALE
IEC
61068-2
INTERNATIONAL
Première édition
STAN DARD
First edition
1991-05
Spécification pour rubans tissés
en fibres de
polyester
Partie 2:
Méthodes d'essai
Specification for polyester fibre woven tapes
Part 2:
Methods of test
© IEC 1991 Droits de reproduction réservés — Copyright - all rights reserved
Aucune partie de cette publication ne peut être reproduite ni No part of this publication may be reproduced or utilized in
utilisée sous quelque forme que ce soit et par aucun any form or by any means, electronic or mechanical,
procédé, électronique ou mécanique, y compris la photo- including photocopying and microfilm, without permission in
copie et les microfilms, sans l'accord écrit de l'éditeur. writing from the publisher.
International Electrotechnical Commission 3, rue de Varembé Geneva, Switzerland
Telefax: +41 22 919 0300 e-mail: inmail@iec.ch IEC web site http: //www.iec.ch
CODE PRIX
Commission Electrotechnique Internationale
F
PRICE CODE
International Electrotechnical Commission
IEC MemayHapoAHaR 3nenrporexHH4ecKaR HOMHCCHH
Pour prix, voir catalogue en vigueur
• •
For price, see current catalogue
© IEC
1068-2 - 3 -
INTERNATIONAL ELECTROTECHNICAL COMMISSION
SPECIFICATION FOR POLYESTER FIBRE WOVEN TAPES
Part 2: Methods of test
FOREWORD
1) The formal decisions or agreements of the IEC on technical matters, prepared by Technical Committees on
which all the National Committees having a special interest therein are represented, express, as nearly as
possible, an international consensus of opinion on the subjects dealt with.
2) They have the form of recommendations for international use and they are accepted by the National
Committees in that sense.
3) In order to promote international unification, the IEC expresses the wish that all National Committees
should adopt the text of the IEC recommendation for their national rules in so far as national conditions will
permit. Any divergence between the IEC recommendation and the corresponding national rules should, as
far as possible, be clearly indicated in the la tter.
This part of International Standard IEC 1068 has been prepared by Sub-Committee 15C:
Specifications, of IEC Technical Committee No. 15: Insulating materials.
The text of this part is based on the following documents:
Six Months' Rule Report on Voting
15C(CO)235
15C(CO)249
Full information on the voting for the approval of this part can be found in the Voting
Report indicated in the above table.
1068-2 © IEC - 5 -
SPECIFICATION FOR POLYESTER FIBRE WOVEN TAPES
Part 2: Methods of test
1 Scope
This part of IEC 1068 specifies requirements for tapes woven on shuttleless looms for continuous
filament polyester fibres.
rt 1
This part gives methods of test to demonstrate compliance with the general requirements of Pa
and the specific requirements of Pa rt 3 of the standard.
Other parts of IEC 1068 are:
- Pa 1: Definitions, designation and general requirements.
rt
- Part 3: Specifications for individual materials.
2 Normative references
The following standards contain provisions which, through reference in this text, constitute pro-
visions of this part. At the time of publication, the editions indicated were valid. All standards are
are encouraged to investigate the
subject to revision, and parties to agreements based on this part
possibility of applying the most recent editions of the standards listed below. Members of IEC and
ISO maintain registers of currently valid International Standards.
les - Woven fabrics - Determination of breaking strength and elongation
ISO 5081: 1977, Texti
(Strip method).
ISO 5084: 1977, Textiles - Determination of thickness of woven and knitted fabrics (other than
textile floor coverings).
3 Tests
Determination of number of warp ends
3.1
The ends shall be counted across the full width of the tape under ordinary room conditions and
divided by the nominal width to obtain the ends/10 mm of nominal width.
32 Determination of number of picks
The
picks shall be counted over not less than 20 mm length of tape under ordinary room con-
ditions and the average value shall be calculated from not less than three individual tests made at
three different pla
ces along the tape.
NOTE - In most constructions, t
...
